Side 1/2

Turn off your computer, unplug the power

cable then remove the case panel.

b. Connect the provided Bluetooth USB cable to

the adapter.

Note: If the Bluetooth USB cable is not correctly connected to

the motherboard, Bluetooth function won’t work even after

driver installation.

2 Connect to a Computer

c. Locate an available slot and remove PCI-E X1

the corresponding slot cover on the rear

panel. Then insert the adapter carefully.

d. Locate an available connector and 9-pin

carefully plug the Bluetooth USB cable into it.

WLAN Bluetooth

PCI Express Adapter

Quick Installation Guide

To continue, ip the page over.

Bluetooth USB cable

Adapter

Images may dier from your actual product.

1 Disable Bluetooth

a. Right-click , select , go My Computer Manage

to Device Manager.

b. Expand the Bluetooth node to nd your

existing Bluetooth device.

c. Right-click the existing Bluetooth device and

select .Disable

Note: Make sure you have disabled all existing Bluetooth

devices (both built-in and third party).

Bluetooth

Device Manager

Disable

Existing Bluetooth Adapter

Before You Start:

If you plan on using Bluetooth and already

have connected Bluetooth devices, proceed

with step 1. Otherwise, skip to step 2.

4 Join a Wireless Network

a. . Click the network icon on the taskbar

5 Pair With Bluetooth Devices

c. Select your Bluetooth device from the list and

follow the onscreen instructions to complete

pairing.

Note: Make sure your device’s Bluetooth is enabled and

discoverable.

3 Install Drivers

a. Autorun.exeInsert the CD and run the .e. Replace the case panel, plug in the power

cable and turn on your computer.

b. Select your Wi-Fi network, click , and Connect

enter the password when prompted.

b. Select Add a Bluetooth Device Add a or

Device to scan for available devices.

b. Install the Wi-Fi and Bluetooth drivers .

Tip: You can also check the new release and download

the driver at www.mercusys.com/support.

① Wi-Fi: Click and follow the onscreen

instructions to complete the Wi-Fi installation.

② Bluetooth: Click and follow the onscreen

instructions to complete the Bluetooth

installation.

a. Right click the (Bluetooth) icon on the

taskbar. If it's not displayed, turn on Bluetooth

in your PC settings rst.

· Keep the device away from water, re, humidity or hot

environments.

· Do not attempt to disassemble, repair, or modify the device. If

you need service, please contact us.

· Do not use the device where wireless devices are not allowed.

Mercusys hereby declares that the device is in compliance with

the essential requirements and other relevant provisions of

directives 2014/53/EU, 2011 /65/EU and (EU) 2015/863. The

original EU Declaration of Conformity may be found at

https://www.mercusys.com/en/ce

Mercusys hereby declares that the device is in compliance with

the essential requirements and other relevant provisions of the

Radio Equipment Regulations 2017. The original UK Declaration

of Conformity may be found at

https://www.mercusys.com/support/ukca/

Support

For technical support, the user guide and more information,

please visit .https://www.mercusys.com/support

Add a device

Mouse

Connect Cancel

Anna’s Phone

Connect

Secured

MERCUSYS_XXXX

Network settings

Notes:

• DO NOT run the driver installations at the same time. When

one driver is being installed, please wait until the installation

is complete and then try to install the other.

• If an unknown publisher message pops up, select Yes to

continue.

• If Windows User Account Control requires admin

credentials, type user name and password of your Windows

administrator account.

Safety Information

Produkt Specifikationer

Mærke:	Mercusys
Kategori:	Ikke kategoriseret
Model:	MA80XE
Bredde:	120.8 mm
Dybde:	226.3 mm
Højde:	21.5 mm
Produktfarve:	Sort
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Forbindelsesteknologi:	Trådløs
Wi-Fi-bånd:	Dual-band (2,4 GHz / 5 GHz)
Bedste Wi-Fi standard:	Wi-Fi 6 (802.11ax)
Netværksstandarder:	IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11n
Værtsgrænseflade:	PCI Express
Grænseflade:	WLAN / Bluetooth
Intern:	Ja
Maksimal dataoverførselshastighed:	2976 Mbit/s
Understøttede WLAN-dataoverførselshastigheder:	574,2402 Mbit/s
Komponent til:	PC/server
