TROUBLESHOOTING GUIDE ---------------------------------------------------------------------------------------------- 1
REPAIR GUIDE ----------------------------------------------------------------------------------------------------------------- 2
1. Precautions on disassembly and reassembly ------------------------------------------------------------- 2
• Disassembly ----------------------------------------------------------------------------------------------------- 2
• Reassembly ----------------------------------------------------------------------------------------------------- 6
• Type of silicone rubber --------------------------------------------------------------------------------------- 15
• Lubrication points and type of lubricant ------------------------------------------------------------------ 15
• Tightening torque ---------------------------------------------------------------------------------------------- 16
• Checking after reassembly ---------------------------------------------------------------------------------- 16
• No-load current value ---------------------------------------------------------------------------------------- 16
• Wiring diagram ------------------------------------------------------------------------------------------------- 17
2. Precautions on disassembly and reassembly of the charger ---------------------------------------- 17
CONTENTS
Page
W
Overseas Sales Management Dept.
CONFIDENTIAL
Jul. 2022
PRODUCT NAME
18 V Cordless Impact Driver
Models
WH 18DE, WH 18DEX
WH 18DEX: For the USA and Canada
WH 18DE: For other regions
WH 18DE
-1-
When troubleshooting, be sure to wipe off all dust, water, and other foreign matter from the internal parts,
and then dry the parts adequately before conducting the following investigation.
Trouble Cause Check method Corrective action
(1)
Motor does not
run.
• Switch connector
cable poorly inserted
• Check the insertion status of connector
cable. (See "1. Reassembly of the power
supply unit" on page 6.)
• Reinsert connector
cable.
• Rotor pinion ass'y
magnet poorly
adhered
• Check whether the rotor pinion ass'y
magnet is inserted to the same level as
the rotor core edge.
• Replace the rotor
pinion ass'y.
• DC-speed control
switch breakdown
• Check the board surface for any silicon
peelings, device damage, and drop dents.
• Check the metal terminals (pin) in the
switch connectors for corrosion.
• Replace the DC-speed
control switch.
• Wiring ass'y
breakdown
• Check the board surface for any urethane
peelings, device damage, and drop dents.
• Replace the wiring
ass'y.
(2)
Rotor does not
switch
direction.
• Switch connector
cable poorly inserted
• Check the insertion status of connector
cable. (See "1. Reassembly of the power
supply unit" on page 6.)
• Reinsert connector
cable.
• Faulty switch
connectors
• Check the conductor of the connector
cable for corrosion.
• Check the metal terminals (pin) in the
switch connectors for corrosion.
• Replace the DC-speed
control switch and the
wiring ass'y.
• Imperfect contact in
the switch
• If the connector cable of the wiring ass'y
and the switch connector are trouble-free
• Replace the DC-speed
control switch.
(3)
Rotating speed
does not rise
(rotating speed
cannot be
changed).
• Wiring ass'y
breakdown
• Check the board surface for any urethane
peelings, device damage, and drop dents.
• Replace the wiring
ass'y.
• Switch connector
cable poorly inserted
• Check the insertion status of connector
cable. (See "1. Reassembly of the power
supply unit" on page 6.)
• Reinsert connector
cable.
• Faulty switch
connectors
• Check the conductor of the connector
cable for corrosion.
• Check the metal terminals (pin) in the
switch connectors for corrosion.
• Replace the DC-speed
control switch and the
wiring ass'y.
• Imperfect contact in
the switch
• If the connector cable of the wiring ass'y
and the switch connector are trouble-free
• Replace the DC-speed
control switch.
(4)
LED light does
not go on.
• Wiring ass'y
breakdown
• Use a fully charged battery and operate
the light switch to check whether the LED
light goes on.
• Replace the wiring
ass’y.
TROUBLESHOOTING GUIDE
