Side 1/2

Receiver Wiring Adaptor

120 70-1677

Revision 09/05/13

If your receiver does not have an

illumination wire, tape off the Orange wire.

Before starting, compare items on your invoice with items

received. Carefully check through packaging material. If an

item is missing, please call Crutchfield at 1-888-955-6000.

Individually tape off any unused wires.

White - Left Front Speaker Positive

Violet/Black - Right Rear Speaker Negative

Red - 12 Volts Switched Power

Violet - Right Rear Speaker Positive

Green - Left Rear Speaker Positive

Yellow - 12 Volts Constant Power

Gray - Right Front Speaker PositiveGray/Black - Right Front Speaker Negative

Green/Black - Left Rear Speaker Negative

White/Black - Left Front Speaker Negative

Black - Chassis Ground (connect to ground wire of new receiver)

Blue - Power Antenna

Note: The 12 volts constant power plug may

not be present in your particular vehicle. If not,

and your receiver requires a constant 12 volt

lead (memory lead), run wire to an appropriate

fuse in the vehicle.

*120701677*

Orange Illumination-

IMPORTANT

STEP 1 -- MATCH & CONNECT WIRES

Match wires below to the matching function of each wire on your receiver (refer to instructions supplied with receiver). The wire colors of your

new receiver may, or may not, match the wire colors of the adaptor. Match adaptor and receiver wires by function, disregarding color.

If your receiver does not have an Illumination wire, tape off the Orange wire.

Individually tape off any unused wires.

Make final wiring connections following instructions on the next page.

Receiver Wiring Adaptor Connections

120 70-1677

Page 2

STEP 2 -- CONTINUED

A. Strip wires back 1/2”.

B. Twist wires together and

insert in crimp cap.

C. Squeeze middle of cap

for tight connection.

STEP 3 -- APPLICATION

When ready to install the receiver, plug

the Wiring Adaptor from the new receiver

or receiver assembly into the factory

radio harness(es) in the vehicle dash.

D. Complete crimp connections

for all necessary wires.

E. Be sure to wrap any wires from

the Wiring Adaptor that are

not necessary (wires with no

match from the new receiver)

with electrical tape.

STEP 2 -- CRIMP CONNECTIONS

Tools & Parts

Required

Wire Stripper/Crimp Tool Crimp Caps

Unused Wire (tape over bare wires)

Receiver Wiring Adaptor

Generic Illustration
