Side 1/3

1990 vehicles and older:

Audis and Volkswagens do not have a switched 12 volts source for the receiver. You can connect to a 12 volts switch source either of these ways:

1. Connect both the switched 12 volts and constant 12 volts of the receiver to the yellow wire on the adaptor. Note: Using this method will

require that the receiver is turned off manually. Otherwise, the receiver will remain on and can drain the battery.

2. Connect to a 12 volts switched source in the vehicle fuse panel.

1994-'98 Saab 900

1995-'98 Saab 9000

2001-'03 Mercedes ML320

1997-'02 Porsche Boxster

2002-'03 Land Rover Freelander

The yellow and red wires of this harness must be reversed for these vehicles. Yellow connects to ignition. Red connects to 12V constant

power.

Pre-1996 vehicles:

Your vehicle may use an amplified (non-motorized) antenna. Even though your antenna does not automatically retract, the wire of blue

the Crutchfield harness must be connected to the power antenna wire of the new receiver.

IMPORTANT NOTES

Before making any connections, please read the notes below that may apply to your vehicle.

Make wiring connections using instructions on the following pages.

Receiver Wiring Adaptor

120 70-1758

IMPORTANT

Before starting, compare items on your invoice with items

received. Thoroughly check packing materials. If an item

is missing, please call Crutchfield at 1-888-955-6000.

Revision 11/27/17

Receiver Wiring Adaptor

120 70-1758

STEP 1 -- MATCH & CONNECT WIRES

IMPORTANT

Before starting, compare items on your invoice with items

received. Thoroughly check packing materials. If an item

is missing, please call Crutchfield at 1-888-955-6000.

Yellow - 12 Volts Constant Power

Red - 12 Volts Switched Power

White - Left Front Speaker Positive

Violet - Right Rear Speaker Positive

Green - Left Rear Speaker Positive

Gray - Right Front Speaker Positive

Gray/Black - Right Front Speaker Negative

White/Black - Left Front Speaker Negative

Black - Chassis Ground

Violet/Black - Right Rear Speaker Negative

Green/Black - Left Rear Speaker Negative

Orange/White - Illumination

Blue - Power Antenna

Match wires below to the matching function of each wire on your receiver (refer to instructions supplied with receiver). The wire colors of your

new receiver may, or may not, match the wire colors of the adaptor. Match adaptor and receiver wires by function, disregarding color.

Your receiver illumination wire could be Orange or Orange/White. As with other wires, match this wire to the illumination wire in this harness

by function, not by color. If your receiver does not have an illumination wire, tape off the illumination wire.

Individually tape off any unused wires.

Make final wiring connections following instructions on the next page.

1994-'98 Saab 900:

This wire is not used.

Cut and tape off both ends.

Page 2
