Match wires below to the matching function of each wire on your receiver (refer to instructions supplied with receiver).

The wire colors of your new receiver may, or may not, match the wire colors of the adaptor. Match adaptor and receiver wires by function,

disregarding color.

Connect Black wire to Ground wire of new receiver.

Individually tape off any unused wires.

Make final wiring connections following instructions on the next page.

Wiring Adaptor

120 70-1856

Revision 06/22/09

STEP 1 -- CONNECT WIRES

Plug connectors into matching inputs.

Before starting, compare items on your invoice with items

received. Thoroughly check packing materials. If an item

is missing, please call:

Crutchfield

*120701856*



IMPORTANT

STEP 2 -- INSTALL



To Receiver

White - Left Front Speaker Positive

Violet/Black - Right Rear Speaker Negative

Red - 12 Volts Switched Power

Violet - Right Rear Speaker Positive

Green - Left Rear Speaker Positive

Gray - Right Front Speaker Positive

Gray/Black - Right Front Speaker Negative

Green/Black - Left Rear Speaker Negative

White/Black - Left Front Speaker Negative

Black - Chassis Ground

Blue - Power Antenna

Yellow - 12 Volts Constant Power

at 1-888-955-6000

Tools Required

Soldering

Iron

Solder

(Rosin Core

Suggested)

Electrical

Tape

Wiring Adaptor Connections

C. Solder:

1. Heat wire.

2. Touch solder to wire, not to iron.

Page 2

Tools Required

Crimp Tool/

Wire Stripper

Crimp Caps

A. Strip wires back 1/2”.

B. Twist wires together and

insert in crimp cap.

C. Squeeze middle of cap

for tight connection.

A. Strip wires back 1/2”.

B. Twist wires together.

D. Tape

CRIMP METHOD SOLDER METHOD

120 70-1856


