REV. 09/16/10 INST70-7304
1-800-221-0932 www.metraonline.com
METRA ELECTRONICS CORPORATION
© COPYRIGHT 2010
70-7304
HYUNDAI/ KIA 2010 AND UP
18 PIN AND 24 PIN
COLOR FUNCTION
RED ACCESSORY
YELLOW BATTERY
BLACK GROUND
BLUE POWER ANTENNA
ORANGE ILLUMINATION
GRAY RIGHT FRONT +
GRAY/BLACK RIGHT FRONT -
WHITE LEFT FRONT +
WHITE/BLACK LEFT FRONT -
VIOLET RIGHT REAR +
VIOLET/BLACK RIGHT REAR -
GREEN LEFT REAR +
GREEN/BLACK LEFT REAR -
BLUE/PINK VSS
Connect these two to the AXXESS
ASWC Steering Wheel Control
Interface:
GREEN/ ORANGE SWC 1
BLACK
near GREEN/ORANGE SWC GROUND
