I N S TA L L AT I O N I N S T R U C T I O N S

70-7307

CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

• Tape • Wire cutter • Zip ties

TABLE OF CONTENTS

Connections ............................................................2

Hyundai/Kia Wiring Harness (with Base radio)

2017-up*

*Visit for up-to-date vehicle speciﬁc applications.MetraOnline.com

APPLICATIONS

Hyundai

Accent† 2018-up

Kia

Rio / Rio 5-door† 2018-up

Sedona† 2017-up

Soul† 2017-up

† Only for models with a Base “non-touchscreen” radio

HARNESS FEATURES

• Wiring harness for installation of an aftermarket radio

• Provides power and four speakers

• Retains balance and fade

• Provides NAV outputs (parking brake, reverse, speed sense)

• Pre-wired ASWC-1 harness (ASWC-1 sold separately)

• Retains the factory AUX-IN jack

• Retains the factory backup camera

• Retains the factory USB

OPTIONAL ACCESSORIES (sold separately)

Steering Wheel Control Interface: ASWC-1

12V TO 6V Step-Down: AX-CAM6V

I N S TA L L AT I O N I N S T R U C T I O N S

70-7307

CONNECTIONS

From the 70-7307 harness to the aftermarket radio:

•

Connect the wire, and also the wire labeled “Camera Ground”, to the ground wireBlack Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the accessory wire.Red

• Connect the wire labeled “Camera Power 6V” to the Red Blue/Red wire from the AX-CAM6V

(sold separately).

• Connect the wire to the power antenna turn-on wire.Blue

• Connect the wire to the illumination wire, if applicable.Orange

• Connect the wire to the right front positive speaker wire.Gray

• Connect the Gray/Black wire to the right front negative speaker wire.

• Connect the wire to the left front positive speaker wire.White

• Connect the wire to the left front negative speaker wire.White/Black

• Connect the wire to the left rear positive speaker wire.Green

• Connect the wire to the left rear negative speaker wire.Green/Black

• Connect the wire to the right rear positive speaker wire.Purple

• Connect the to the right rear negative speaker wire.Purple/Black

The following (3) wires are only for multimedia/navigation radios that require these wires.

• Connect the wire to the parking brake wire.Light Green

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• If retaining the factory AUX-IN jack is desired, connect the & RCA jacks to the Red White

AUX-IN jacks.

• Connect the Yellow RCA jack to the jack designated for a backup camera input.

• If retaining the factory USB is desired, connect the USB cable to USB input.

12-pin pre-wired ASWC-1 harness:

This harness is to be used along with the ASWC-1 (sold separately) to retain steering wheel

audio controls. If the ASWC-1 is not being used, disregard this harness. If it is to be used,

please refer to the ASWC-1 instructions for radio connections and programming. Disregard the

harness that comes with the ASWC-1.
