Side 1/2

Match wires below to the matching function of each wire on your receiver (refer to instructions supplied with receiver).

The wire colors of your new receiver may, or may not, match the wire colors of the adaptor. Match adaptor and receiver

wires by function, disregarding color.

Connect Black wire to Ground wire of new receiver.

Individually tape off any unused wires.

Make final wiring connections following instructions on the next page.

Receiver Wiring Adaptor

120 70-8116

Revision 01/10/11

STEP 1 -- CONNECT WIRES

Plug housings into factory harnesses in vehicle.

Before starting, compare items on your invoice with items

received. Thoroughly check packing materials. If an item

is missing, please call:

Crutchfield

*120708116*



IMPORTANT

STEP 2 -- INSTALL



White - Left Front Speaker Positive

Violet/Black - Right Rear Speaker Negative

Red - 12 Volts Switched Power

Violet - Right Rear Speaker Positive

Green - Left Rear Speaker Positive

Yellow - 12 Volts Constant Power

Gray - Right Front Speaker Positive

Gray/Black - Right Front Speaker Negative

Green/Black - Left Rear Speaker Negative

White/Black - Left Front Speaker Negative

Black - Chassis Ground

Blue - Power Antenna

Green/White - Subwoofer Positive Coil 1

White/Red - Subwoofer Negative Coil 1

Brown/Blue - Subwoofer Negative Coil 2 Brown/Yellow - Subwoofer Positive Coil 2

Wires in this plug are illustrated as

short, but are actually 17 feet long.

Note: The subwoofer wires are not used and should be taped off for the Celica,

Camry, Highlander and Solara. The 2003-04 Avalon uses only the sub coil #1

wires. Both sets of subwoofer wires are used for the Landcruiser.

Note: In order to use the factory subwoofers, we recommend a low-power amp

(50W or less) with a low-pass crossover. Connecting these wires directly to an

aftermarket receiver's speaker leads will produce unsatisfactory results.

at 1-888-955-6000

Tools Required

Soldering

Iron

Solder

(Rosin Core

Suggested)

Electrical

Tape

Receiver Wiring Adaptor Connections

C. Solder:

1. Heat wire.

2. Touch solder to wire, not to iron.

Page 2

Tools Required

Crimp Tool/

Wire Stripper

Crimp Caps

A. Strip wires back 1/2”.

B. Twist wires together and

insert in crimp cap.

C. Squeeze middle of cap

for tight connection.

A. Strip wires back 1/2”.

B. Twist wires together.

D. Tape

CRIMP METHOD SOLDER METHOD

120 70-8116


