Side 1/8

REV. 1/6/2016 INST99-6531HG

CAUTION: Metra recommends disconnecting the negative battery

terminal before beginning any installation, unless the vehicle

manufacturer recommends against so. Please check with your

local Dealership for more information. All accessories, switches,

climate controls panels, and especially air bag indicator lights

must be connected before reconnecting the battery or cycling

the ignition. Also, do not remove the factory radio with the key

in the on position, or the vehicle running. It would be best to

remove the key from the ignition and then wait a few seconds

before removing the factory radio.

Installation instructions for part 99-6531HG

• ISO DIN radio provision with pocket

• Painted high gloss black

• A) Radio trim panel • B) Radio brackets • C) Radio mounting brackets • D) Pocket • E) (4) Panel clips

• F) (2) #8 x 3/8” Phillips screws • G) (4) 12 mm x 5 mm Phillips screws

KIT FEATURES

KIT COMPONENTS

WIRING & ANTENNA CONNECTIONS (sold separately)

Wiring Harness: • XSVI-6523-NAV Antenna Adapter: • 40-EU55

• Panel removal tool • Phillips screwdriver

• 86-3528 radio removal tool • Cutting tool

• Torx T-25 driver

TOOLS REQUIRED

ADC E F

Dash Disassembly ................................................. 2

Kit Assembly

– ISO DIN radio provision with pocket 3 ......................

Table of Contents

99-6531HG

Dash Disassembly

1. Using Metra’s 86-3528 radio

removal tools, pull the factory radio

from the dash. (Figure A)

2. Remove (2) T-25 Torx screws from

the top of the factory radio trim

panel opening, and (2) T-25 Torx

screws from the bottom of the

opening. (Figure B)

3. Pull down slightly on the top center

of the panel, and then unclip and

remove the panel. (Figure C)

4. Remove (4) T-10 Torx screws

securing the factory radio clip

brackets to the panel. (Figure D)

5. In the sub-dash cavity of the

vehicle, grind or cut the (2) silver

rivets from the left and right side.

(Figure E)

6. Cut and remove the shaded portion

of the sub-dash cavity as shown.

(Figure F)

Note: Take caution not to cut

the vent ducts.

Continue to kit assembly.

(Figure A) (Figure D)

(Figure C) (Figure F)

(Figure B) (Figure E)

Remove

shaded

area
