Side 1/8

CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

I N S TA L L AT I O N I N S T R U C T I O N S

99-7809B

KIT FEATURES

• ISO DIN radio provision with pocket

• ISO DDIN radio provision

• Painted matte black

KIT COMPONENTS

• A) Radio trim panel • B) Radio brackets • C) Climate control • D) Pocket • E) (8) #8 x 3/8” Phillips screws • F) (2) #10 x 3/4” Phillips screws

• G) (2) #8 Speed clips • H) (8) PC-7871B Panel clips• Wire harness (not shown)

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

• 5/16” socket wrench • Rotary cutting tool

TABLE OF CONTENTS

Dash Disassembly .............................................. 2-4

Kit Assembly

– ISO DIN radio provision with pocket .................5

– ISO DDIN radio provision ....................................6

Wiring Instructions ................................................7

Kit Programming ...................................................8

WIRING & ANTENNA CONNECTIONS

Wiring Harness: Included

Antenna Adapter: Not required

Steering wheel control interface: ASWC-1

(sold separately)

Acura TSX 2004-2008

A B C D E

F G H

1.800.221.0932

MetraOnline.com

DASH DISASSEMBLY

Attention! Turn the fan speed all the way up,

and then turn the recirculation button off,

prior to turning the vehicle off and removing

the radio/climate control assembly.

1. Unclip and remove the (2) trim

panels on either side of the radio. The

driver side trim will have the cabin

temperature sensor attached to it

(Figures A, B)

Note:

Complete removal should not

be necessary. If you do remove this

trim it must be reconnected prior to

programming the new climate controls.

2. Remove (1) Phillips screw on either side

of the radio.

3. Unclip and remove the hazard button

above the factory radio, and remove (1)

Phillips screw exposed between the a/c

vents. (Figure C)

4. Unclip and remove the pocket below the

radio. (Figure D)

Continued on the next page

(Figure A) (Figure C)

(Figure B) (Figure D)
