CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
AX-HYKIA2-SWC
I N S TA L L AT I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 1/15/18 INSTAX-HYKIA2-SWC
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.)
TABLE OF CONTENTS
Connections to be made ....................................2-3
Installing the AX-HYKIA2-SWC ..............................3
Programming the AX-HYKIA2-SWC ......................4
Steering wheel control settings ....................... 4-7
- L.E.D. feedback ...................................................4
- Changing radio type ..........................................5
-
Remapping the steering wheel control buttons
.. 5-6
-
Dual assignment instructions (long button press)
.. 6-7
Troubleshooting .....................................................7
Hyundai Data Interface with SWC 2012-2016
APPLICATIONS
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains BlueLink
• Designed for amplified* and non-amplified models
• Retains the factory backup camera
• Retains balance and fade
• Micro “B” USB updatable
HYUNDAI
Veloster (without NAV) 2016
Veloster 2012-2015
• AX-HYKIA2-SWC interface
• AX-HYKIA2-SWC harness
• 16-pin harness with stripped leads
• Female 3.5mm connector with stripped leads
* Requires the AX-HYKIA-SPDIF (sold separately)
2
CONNECTIONS TO BE MADE
From the 16-pin harness with stripped leads to the aftermarket radio:
• Connect the Red wire to the accessory wire.
• If the vehicle comes equipped with a factory amplifier, connect the Blue/White wire to the
amp turn-on wire.
• If the aftermarket radio has a mute wire, connect the Brown wire to it. If the mute wire is
not connected, the radio will turn off when BlueLink is activated.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Tape off and disregard the following (9) wires, they will not be used in this application:
Blue/Pink Blue/White Green Green/Black Green/Purple Orange/White, *, , , , Light Green, ,
Purple Purple/Black,
* Non-amplified models
From the AX-HYKIA2-SWC harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Blue wire to the power antenna wire.
• If the aftermarket radio has an illumination wire, connect the Orange wire to it.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative output.
The following (3) wires are only for a multimedia/navigation radio that requires these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
• Connect the Red and White RCA jacks to the audio AUX-IN jacks of the aftermarket radio.
• If the vehicle is equipped with a factory backup camera, connect the Yellow RCA jack to the
backup camera input.
• The 14-pin harness will only be used for models that come equipped with a factory
amplifier. Connect the AX-HYKIA-SPDIF (sold separately) to this connector.
Continued on the next page
