axxessinterfaces.com • metraonline.com axxessinterfaces.com • metraonline.com

Axxess Integrate

Installation Instructions for AX-HYKIACAM1-6V

Instrucciones de instalación para AX-HYKIACAM1-6V

INTERFACE FEATURES

• Retains the factory back-up camera to an aftermarket radio

• Allows an aftermarket camera to be added to the factory screen

• Includes the AX-CAM6V 12-volt to 6-volt converter

INTERFACE COMPONENTS

• AX-HYKIACAM1-6V harness • AX-CAM6V 12-volt to 6-volt converter

AX-HYKIACAM1-6V

Hyundai / Kia (with NAV)

2014-2017

HYUNDAI

Elantra 2017

Elantra GT 2016-2017

Genesis Sedan 2016

Santa Fe 2017

Santa Fe Sport 2017

Sonata 2015-2017

HYUNDAI (CONT)

Tucson 2016-2017

Veloster 2016-2017

KIA

Cadenza 2017

Forte 2017

Niro 2017

KIA (CONT)

Optima 2016-2017

Sedona 2015-2017

Sorento 2016-2017

Soul 2014-2017

Sportage 2017

• Wire cutter • Crimping tool • Solder gun • Tape

• Connectors (example: butt connectors, bell caps, etc.)

APPLICATIONS

TOOLS REQUIRED

CAUTION!

All accessories, switches, climate controls panels, and especially air bag indicator lights

must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

K PNOWLEDGE IS OWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certified technicians

Connections to be made

The AX-HYKIACAM1-6V can be connected two different ways

To retain the factory back-up camera to an aftermarket radio:

• Connect the Black wire to chassis ground, and also to the wire of the AX-CAM6V.Black

• Connect the Red Blue/Red wire to the wire of the AX-CAM6V.

• Connect the reverse wire of the aftermarket radio, and the wire of the Blue/White

AX-CAM6V, to a reverse wire.

• Connect the male Yellow RCA jack to the rear camera input of the aftermarket radio.

To allow an aftermarket camera to be added to the OEM screen:

• Connect the Black wire to the aftermarket cameras ground wire.

• Connect the power wire of the aftermarket camera to accessory power.

• Connect the female Yellow RCA jack to the aftermarket camera.

• Tape off and disregard the following (1) wire, it will not be used in this application: Red.

• Disregard the AX-CAM6V, it will not be used in this application.

Note: Disregard the loose wire, it will not be used in this application.Green/Purple
