AX-SUB28SWC-6V

INSTALL ATION I N STR UCT I ONS

REV. 2/24/20

Integrate • AxxessInterfaces.com

• Pre-wired ASWC-1 harness

(ASWC-1 sold separately)

• Retains the factory backup camera

• Retains the factory AUX-IN jack

• Provides NAV outputs (parking brake,

reverse, speed sense)

• Includes an AX-CAM6V 12-volt

to 6-volt converter

INTERFACE COMPONENTS

• AX-SUB28SWC-6V harness • AX-CAM6V 12-volt to 6-volt converter

Subaru 2015-Up*

Backup Camera Retention Harness with

Pre-Wired ASWC-1 Harness

APPLICATIONS

SUBARU †

BRZ 2016-Up

Crosstrek 2016-2017

Forester 2017-2018

Impreza 2015-2016

WRX (with NAV) 2015

WRX 2016-Up

XV Crosstrek 2015

* Visit AxxessInterfaces.com for more detailed information about the product and up-to-date vehicle speciﬁc applications

INTERFACE FEATURES

† With Base radio, 6.2-inch screen

AX-SUB28SWC-6V

INSTALL ATION I N STR UCT I ONS

REV. 2/24/20

Integrate • AxxessInterfaces.com

K PNOWLEDGE IS OWER

Enhance your inst allation and fa brication skills by

enrolling in the most recognized a nd spect ed re

mobile elect nics school in our industry.ro

Log onto www.insta llerinstit ute.com or call

800-354-6782 for mo informat ion and t ake steps re

towa rd a bett er tomorrow.

Metra r ecommends MECP

certified technicians

Connections to be made

• Connect the

Black

wire to chassis ground, and also to the

Black

wire of the AX-CAM6V.

• Connect the

Red

wire labeled "Camera Power 6V" to the

Blue/Red

wire of the AX-CAM6V.

• If retaining steering wheel controls, connect the unlabeled

Red

wire to accessory power.

• Connect the

Green/Purple

wire to the reverse wire of the aftermarket radio,

and also to the

Blue/White

wire of the AX-CAM6V.

To the aftermarket radio:

• Connect the

Yellow

RCA jack to the backup camera input.

• If retaining the factory AUX-IN jack, connect the

Red

White

RCA jacks to the AUX input.

The following (2) wires are for aftermarket multimedia/navigation radios that require these wires:

• Connect the wire to the parking brake wire.Light Green

• Connect the wire to the speed sense wire.Blue/Pink

Installing the AX-SUB28SWC-6V

With the key in the off position:

• After the radio has been tested and working, connect the AX-SUB28SWC-6V harness to the vehicle,

and then into the ASWC-1.

• Refer to the ASWC-1 instructions for radio connections and programming.

Note:

Disregard the harness that comes with the ASWC-1.
