Installation instructions for part LC-GMRC-04

REV. 9/16/2016 INSTLC-GMRC-04

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

Connections to be made ............................................2

Installing the LC-GMRC-04 ........................................3

Initializing the LC-GMRC-04 ......................................3

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse,

and speed sense)

•

Used in non-amplified models, or when

bypassing a factory amplifier

• Used in models without OnStar

• Retains all warning chimes

• High level speaker input

• Retains balance and fade

• Micro “B” USB updatable

INTERFACE FEATURES

• Cutting tool • Crimp tool • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED

LC-GMRC-04

GM data bus interface

2000-2005

APPLICATIONS

• LC-GMRC-04 interface • LC-GMRC-04 harness

INTERFACE COMPONENTS

Table of Contents

BUICK

LeSabre 2000-2005

OLDSMOBILE

Aurora 2001-2003

PONTIAC

Bonneville 2000-2005

LC-GMRC-04

Connections to be made

From the LC-GMRC-04 harness to the aftermarket radio:

• Connect the Black wire to the ground wire.

• Connect the Yellow wire to the battery wire.

• Connect the Red wire to the accessory wire.

• Connect the Blue wire to the power antenna wire.

• If the aftermarket radio has an illumination wire, connect the Orange

wire to it.

Note: There are (2) wires. If the wire on the 32-pin Orange Orange

harness is populated on the factory side, use that wire. Otherwise, use

the other wire.Orange

• Connect the Gray wire to the right front positive speaker output.

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the White wire to the left front positive speaker output.

• Connect the White/Black wire to the left front negative speaker output.

• Connect the Green wire to the left rear positive speaker output.

• Connect the Green/Black wire to the left rear negative speaker output.

• Connect the Purple wire to the right rear positive speaker output.

•

Connect the wire to the right rear negative speaker outputPurple/Black

The following (3) wires are only for multimedia/navigation radios that require

these wires.

• Connect the Blue/Pink wire to the VSS/speed sense wire.

• Connect the Green/Purple wire to the reverse wire.

• Connect the Light Green wire to the parking brake wire.
