CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

GMOS-MOST-02

I N S TA L L AT I O N I N S T R U C T I O N S

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Cutting tool • Crimping tool • Tape

• Connectors (example: butt-connectors, bell

caps, etc.) • Small ﬂat-blade screwdriver

TABLE OF CONTENTS

Connections to be made ....................................2-3

Installing the GMOS-MOST-02 ...............................3

Programming the GMOS-MOST-02 .......................4

Adjusting the GMOS-MOST-02 ...............................4

GM MOST® Ampliﬁer Interface 2014-up*

APPLICATIONS

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Retains OnStar / OE Bluetooth

• Retains warning chimes

• Provides NAV outputs (parking brake, reverse, speed sense)

• Pre-wired ASWC-1 harness (ASWC-1 sold separately)

• Retains the factory backup camera

• Used in MOST ® ampliﬁed applications

• Adjustable gain control for overall volume

• High level speaker input

• Retains balance

• Micro “B” USB updatable

CHEVROLET

Corvette 2014-up Impala 2014-up

• GMOS-MOST-02 interface

• GMOST-MOST-02 harness

• 16-pin harness with stripped leads

• Backup camera harness

• 10-pin jumper harness

*Visit AxxessInterfaces.com for up-to-date vehicle speciﬁc applications.

CONNECTIONS TO BE MADE

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the Red wire to the accessory wire.

Note:

If installing an ASWC-1 (sold separately), there will be an accessory wire there to

connect as well.

• Connect the Blue/White wire to the amp turn on wire. This wire must be connected to hear

sound from the factory ampliﬁer.

• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.

• If also installing an ASWC-1 (sold separately), connect the Brown wire to the wire in Brown

the 12-pin pre-wired ASWC-1 harness.

• Connect the Gray wire to the right front positive speaker output.

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the White wire to the left front positive speaker output.

• Connect the White/Black wire to the left front negative speaker output.

• Connect the Green wire to the left rear positive speaker output.

• Connect the Green/Black wire to the left rear negative speaker output.

• Connect the Purple wire to the right rear positive speaker output.

• Connect the Purple/Black wire to the right rear negative speaker output.

The following (3) wires are only for multimedia/navigation radios that require these wires.

• Connect the Blue/Pink wire to the VSS/speed sense wire.

• Connect the Green/Purple wire to the reverse wire.

• Connect the Light Green wire to the parking brake wire.

From the GMOS-MOST-02 harness to the aftermarket radio:

• Connect the Black wire to the ground wire.

• Connect the Yellow wire to the battery wire.

• Disregard the Red wire, it will not be used in this application.

• Disregard the Red & White RCA jacks, they will not be used in this application.

12-pin pre-wired ASWC-1 harness:

• This harness is to be used along with the ASWC-1 (sold separately) to retain steering wheel

audio controls. If the ASWC-1 is not being used, disregard this harness. If it will be used,

please refer to the ASWC-1 instructions for radio connections and programming.

Note: Disregard the harness that comes with the ASWC-1.

• Connect the Red wire to the accessory wire.

• Connect the Brown wire to the Brown wire from the 16-pin harness with stripped leads.

• Connect the Green/Black

wire, to the wire Green/Black

in the 10-pin Black connector

located in the steering

column. (Figure A)

(Figure A)

Green/Black wire

Continued on the next page
