Side 1/5

Installation instructions for part LC-BMRC-01

REV. 5/13/2016 INSTLC-BMRC-01

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, and V.S.S)

• Retains warning chimes

• For non-amplified models, or when bypassing a factory amplifier

• Retains balance and fade

• Micro “B” USB updatable

FEATURES

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED

LC-BMRC-01

BMW / Mini Chime Retention

2006-2015

APPLICATIONS

• LC-BMRC-01 interface • LC-BMRC-01 harness

• Fuse holder with 96” length of wire

INTERFACE COMPONENTS

BMW

1 Series (without amp) 2008-2013

3 Series (without amp) 2006-2013

M3 (without amp) 2007-2013

MINI

Cooper (without amp) 2007-2015

Connections to be made ................................................... 2

Installing the LC-BMRC-01 ............................................... 3

Initializing the LC-BMRC-01 ............................................. 3

TABLE OF CONTENTS

LC-BMRC-01

From the LC-BMRC-01 harness to the aftermarket radio:

• Connect the Black wire to the ground wire.

• Connect the Yellow wire to the fuse holder with 96” length of wire:

• Remove the fuse from the fuse holder.

• Connect the 6” long wire side of the fuse holder to the vehicles battery.

• Connect the 96” long wire side of the fuse holder to the Yellow wire.

• Connect the Red wire to the accessory wire.

• Connect the Blue wire to the power antenna wire.

• If the aftermarket radio has an illumination wire, connect the wire to it.Orange

• Connect the Gray wire to the right front positive speaker output.

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the White wire to the left front positive speaker output.

• Connect the White/Black wire to the left front negative speaker output.

• Connect the Green wire to the left rear positive speaker output.

• Connect the Green/Black wire to the left rear negative speaker output.

• Connect the Purple wire to the right rear positive speaker output.

• Connect the Purple/Black wire to the right rear negative speaker output.

The following (3) wires are only for multimedia/navigation radios that require these

wires.

• Connect the Blue/Pink wire to the VSS/speed sense wire.

• Connect the Green/Purple wire to the reverse wire.

• Connect the Light Green wire to the parking brake wire.

12-pin pre-wired ASWC-1 harness:

• This harness is to be used along with the optional ASWC-1 (not included) to

retain steering wheel audio controls. If the ASWC-1 is not being used, disregard

this harness. If it will be used, please refer to the ASWC-1 instructions for radio

connections and programming.

Note: Disregard the harness that comes with the ASWC-1.

Connections to be made
