Installation instructions for part LC-GMRC-LAN-03
REV. 8/15/2016 INSTLC-GMRC-LAN-03
axxessinterfaces.com • metraonline.com © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
Axxess Integrate
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking
brake, reverse, and speed sense)
• Used in non-amplified models, or when bypassing a factory amplifier
•
Used in models without OnStar
• Retains all warning chimes
• High level speaker input
• Retains balance and fade
• Micro “B” USB updatable
05;,9-(*,-,(;<9,:
• Wire cutter • Crimping tool • Tape • Solder gun
• Connectors (butt-connectors, bell caps, etc.)
;663:9,8<09,+
LC-GMRC-LAN-03
GM data bus interface
2006-2012
• LC-GMRC-LAN-03 interface
• LC-GMRC-LAN-03 harness
05;,9-(*,*64765,5;:
Note: This interface will not retain OnStar.
Connections to be made 2 ........................................
Installing the Axxess Interface ............................. 3
Initializing the Axxess Interface ........................... 3
Table of Contents
(7730*(;065:
CHEVROLET
Cobalt 2007-2010
HHR 2006-2011
Malibu 2008-2012
PONTIAC
G5 2007-2009
G6 2010
G6 (5th digit of VIN must
be a J, K, or L) 2009
Solstice 2006-2009
SATURN
Aura 2007-2009
Sky 2007-2009
LC-GMRC-LAN-03
2
From the LC-GMRC-LAN-03 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
• Connect the Blue wire to the power antenna wire.
• If the aftermarket radio has an illumination wire, connect the wire to it.Orange/White
• Tape off and disregard the (2) Orange wires, they will not be used in this
application
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative speaker output.
The following (3) wires are only for multimedia/navigation radios that require these
wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
Connections to be made
