INSTXSVI-9005-NAV
REV. 6/14/16 © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
INSTXSVI-9005-NAV
1-800-221-0932 metraonline.com
REV. 6/14/16 © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
Connections to be made
• Connect the Yellow wire to the radio’s 12-volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio.
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the wire.Orange
XSVI-9005-NAV
Mercedes accessory and NAV output CAN
Interface 2005-up
APPLICATIONS
FREIGHTLINER
Sprinter 2014-up
MERCEDES
C Class 2005-2011
CLK Class 2005-2009
E Class 2010-up
G Class 2007-2012
GLK Class 2010-2012
R Class 2006-2011
SLK Class 2005-2011
Sprinter 2010-up
FEATURES
• Provides accessory (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems, or when replacing amplified system
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired ASWC-1 harness included (ASWC-1 sold separately)
• High level speaker input
• USB updatable
Caution: Metra recommends disconnecting the negative battery terminal before beginning
any installation. All accessories, switches, and especially air bag indicator lights must be
plugged in before reconnecting the battery or cycling the ignition.
*Note: Refer also to the instructions included with the aftermarket radio.
• Connect the Blue wire to the antenna turn on wire of the
aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following wires are for the aftermarket radios that have navigation built in.
• Connect the Light Green wire to the parking brake wire of the aftermarket
navigation radio (if applicable).
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation
radio (if applicable).
• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to
test the radio.
ASWC-1 (if installing)
After the XSVI is initialized, plug in the ASWC-1 into the 12-pin harness of the
XSVI-9005-NAV and refer to the ASWC-1 instructions.
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
