User Guide

DS50003581A - 1

Introducon

This user guide provides complete information about using the Microchip Radio Test 3 tool (MCHPRT3 tool)

with the Microchip PIC32MZ2051W1 based Wi-Fi

design. The MCHPRT3 tool enables the user to evaluate and

demonstrate the Radio Frequency (RF) performance and functionalities of the PIC32MZ2051W1 SoC-based Wi-Fi

design.

Note: In this user guide, the MCHPRT3 tool with the PIC32 WFI32 2.0 Curiosity Board is only shown as an

example.

Tesng PIC32MZ2051W1 SoC with MCHPRT3 Tool

PIC32MZ2051W1

User Guide

DS50003581A - 2

Table of Contents

Introduction...........................................................................................................................................................................1

1. Quick References...........................................................................................................................................................3

1.1. Reference Documentation................................................................................................................................3

1.2. Hardware Requirements...................................................................................................................................3

1.3. Software Requirements.....................................................................................................................................3

1.4. Test Equiptment................................................................................................................................................. 3

1.5. Acronyms and Abbreviations............................................................................................................................3

2. MCHPRT3 Tool Overview.............................................................................................................................................. 4

3. Testing and Calibration of PIC32MZ2051W1 with Wi-Fi Tester using MCHPRT3 Tool........................................... 5

3.1. MPLAB

X IPE HUT Code Programming Process with In-Circuit Serial Programming

™

Header................ 5

3.2. Getting Started with MCHPRT3 Tool GUI for PIC32MZ2051W1....................................................................7

3.3. Performing RF Test on the PIC32 WFI32 2.0 Curiosity Board with MCHPRT3 Tool.................................. 10

3.4. MCHPRT3 Tool with PIC32MZ2051W1 GUI Demonstration........................................................................14

3.5. PIC32MZ2051W1 Dynamic Link Library (DLL) Gain Table Information..................................................... 25

3.6. PIC32MZ2051W1 Command Line Interface (CLI) Information................................................................... 26

3.7. PIC32MZ2051W1 Python 3 Information........................................................................................................29

4. Document Revision History........................................................................................................................................35

Microchip Information....................................................................................................................................................... 36

The Microchip Website............................................................................................................................................... 36

Product Change Notication Service........................................................................................................................ 36

Customer Support.......................................................................................................................................................36

Microchip Devices Code Protection Feature............................................................................................................ 36

Legal Notice..................................................................................................................................................................36

Trademarks.................................................................................................................................................................. 37

Quality Management System.....................................................................................................................................38

Worldwide Sales and Service..................................................................................................................................... 39
