BGR Series

19” gangable enclosures

next generation rack, designed with signiﬁcant

installation and performance beneﬁts

features:

• Provides more rackspace in a smaller overall height than similar racks

• Accepts patent-pending Lever Lock™ tool free and hardware free internal

device and cable management system accessories

• Fully welded construction provides the following weight capacities:

UL Listed load capacity: 3,000 lbs., Seismic certiﬁed capacity: 1,175 lbs.

• Pre-threaded ganging holes allow for rack joining after loading

• Rackrail depth indicators

• 1/2”, 3/4”, 1” & 1-1/2” electrical knockouts and 5/8” and 1/2” D UHF/VHF

antennae knockouts on rear top & bottom, easily removable for cable

pass-through. Top cable management plate (38 space and up) includes 1/2”,

3/4”, 1” 1-1/2” & 3” electrical knockouts and 5/8” and 1/2” D UHF/VHF

antennae knockouts

• 23” OD width, multiple depths

• Two pairs of 11-gauge, 10-32 threaded rackrail with numbered rackspace

increments

• Optional stackable 3” extender bay available for front and rear

• Optional curved and beveled front doors in solid, vented and plexiglass styles

• Attractive interior bevels

• Conﬁgurable open top with vertical cable management entry points

• Durable black textured powder coat ﬁnish

• Seismic certiﬁed (when used with BGR-Z4 or BGR-ISO-Z4 option) with

an Ip value of 1.5

• UL Listed in the US and Canada

BGR shown with curved

door and side panels

BGR shown with beveled

door and side panels

EI A/ TIA COMPLI AN T

SE IS MIC CERTI FI ED

middleatlantic.com | middleatlantic.ca

what are built on.great systems

™

BGR Series

19” gangable enclosures

EIA compliant 19” gangable equipment rack shall be Middle Atlantic Products model #BGR-__-

__(see chart for available models). Overall dimensions of BGR shall be __”H x 23”W x __”D (refer

to chart). Useable height of BGR shall be __ rackspaces, useable depth shall be__” (refer to chart).

BGR shall come equipped with two pairs of fully adjustable steel rackrail with tapped 10-32 mounting

holes in universal EIA spacing, black e-coat ﬁnish and numbered rackspaces. BGR shall have .100”

thick steel along rackrail brackets, .310” thick steel at corners. BGR shall include vented locking

and latching rear door, which shall be capable of accepting up to six 4-1/2” fans. Top and bottom of

BGR shall feature vertical slotted vent pattern for ventilation. BGR shall have two 1” x 7”rear obround

knockouts with 1/2”, 1”, 1-1/4” and 1-1/2” electrical knockouts and 5/8” and 1/2” D UHF/ VHF

antennae knockouts in base and top. BGR shall have a conﬁgurable open top with vertical cable

management entry points. BGR shall accept patent-pending LeverLock™ tool free and hardware free

internal cable and device management system accessories. BGR shall have pre-threaded 5/16”-18

ganging holes. BGR shall be capable of ganging while fully loaded, using bolts only. BGR shall have

marked rackrail depth indicators. BGR shall be of fully welded construction. BGR shall be ﬁnished in

an environmentally friendly, durable black powdercoat. Grounding and bonding studs shall be 1/4-20

threaded, installed in top and base of enclosure (19 and 25 space have stud in bottom only). Fully

welded construction shall provide a static capacity of 12,000 lbs. and a UL Listed load capacity of

3,000 lbs. BGR Series enclosures shall satisfy the 1997 UBC; 2001, 2007 & 2010 CBC; 2000,

2003, 2006 & 2009 IBC; ASCE 7-02, ASCE 7-05, ASCE 7-10 and the 2003, 2006 & 2009 editions

of NFPA 5000 for use in areas of high seismicity, Seismic Use Group III, Zone 4 or Seismic Design

Category (SDC) “D” with lateral force requirements for protecting 1,175 lbs. of essential equipment in

locations with the highest level of seismicity and top ﬂoor or rooftop installations with an Importance

factor (Ip) of 1.5 when used with BGR-Z4 or BGR-ISO-Z4 (isolated) seismic ﬂoor anchor bracket. BGR

shall be OSHPD approved for ﬁxed equipment anchorage in California healthcare facilities. BGR shall

be UL Listed in the US and Canada. BGR shall be GREENGUARD Gold Certiﬁed. BGR enclosure shall

meet the RoHS EU Directive 2011/65/EU. BGR shall be manufactured by an ISO 9001 and ISO

14001 registered company. BGR enclosure shall be warrantied to be free from defects in material or

workmanship under normal use and conditions for the lifetime of the rack.

Customizable speciﬁcation clips available at middleatlantic.com

speciﬁcations:

options:

• Lever Lock™ tool free and hardware free internal

device and cable management system accessories

shall be model # LL-XXYY (XX = type, YY = size,

refer to middleatlantic.com for additional details)

• Curved front doors shall be model # VFD-XXA (vented,

64% open area), PFD-XXA (plexi), (XX= # of rackspaces)

• Beveled front doors shall be model # BFD-XX (solid),

BVFD-XX (vented, 64% open area), BPFD-XX (plexi),

(XX= # of rackspaces)

• Front or Rear Extender, adds 3” of usable depth,

model # BGR-__-EXT3 (41,45)

• Cable entry rear door, shall be model # BGR-RDC__

(19, 25, 38, 41, 45)

• Inner platform base shall be BS-BGR

• Caster kit shall add 1” to overall height, include four

casters with a 1,100 lb. weight capacity, and shall be

model # CBS-BGR

• Rear rail kit shall be model # BGR-RRXX (XX=# of

rackspaces)

• Removable keylocked side panels shall be model

# BSPN-XX-YY (XX=rackspaces, YY=depth)

• Seismic Zone 4, Seismic Use Group III and Seismic

Design Category “D” compliancy kit shall be model

# BGR-Z4

• Seismic Zone 4, Seismic Use Group III and Seismic

Design Category “D” compliancy and isolation kit shall

be model # BGR-ISO-Z4

• Seismic Zone 4, Seismic Use Group III and Seismic

Design Category “D” riser bases shall be

SRB-(1,2,3)-BGR-(32, 38)24

• Isolation kit shall be model # BGR-ISO

• Front decorative trim shall be BGR-TRIM__(45,41,38,

25, 19) and shall include the following colors: Green

(pre-installed), Red, Black, Blue & White

Part # Rackspaces

“A”

Overall Height

“B”

Racking Height

“C”

Depth

“D”

Useable Depth

BGR-1927 19 37.375 [949] 33.375 [848] 27 [686] 24.4 [620]

BGR-2527 25 47.875 [1216] 43.875 [1114] 27 [686] 24.4 [620]

BGR-3827 38 70.625 [1794] 66.625 [1692] 27 [686] 24.4 [620]

BGR-4127 41 75.875 [1927] 71.875 [1826] 27 [686] 24.4 [620]

BGR-4527 82.875 [2105] 78.875 [2003]45 27 [686] 24.4 [620]

BGR-2532 25 47.875 [1216] 43.875 [1114] 29.4 [747]32 [812]

BGR-3832 38 70.625 [1794] 66.625 [1692] 29.4 [747]32 [812]

BGR-4132 41 75.875 [1927] 71.875 [1826] 32 [812] 29.4 [747]

BGR-4532 82.875 [2105] 78.875 [2003] 29.4 [747]45 32 [812]

BGR-4138 41 75.875 [1927] 71.875 [1826] 38 [965] 35.4 [899]

BGR-4538 82.875 [2105] 78.875 [2003] 38 [965] 35.4 [899]45
