Side 1/3

middleatlantic.com | middleatlantic.ca

what are built on.great systems

™

96-01174 / rev e / 3-5-18

RFR Series

reference mobile furniture rack

uniquely styled furniture rack system that is optimized

for easy integration and is ruggedly designed for years

of trouble free room-to-room mobility

features:

• Engineered for professional integration to ensure efﬁcient installation

• Wide-body design allows for handy interior device mounting and cable management

using optional tool-free LeverLock™ system

• Robust construction features bolt-through ﬂoor-friendly casters and internal steel

bracing for years of reliable use

• Unique cable entry rear door and included cable spools allow easy storage of

connecting cable bundle

• Advanced cooling for system reliability

• Optimized for passive ventilation featuring generous front air intake & rear exhaust vents

• Enable energy-saving active cooling with optional thermostatically- controlled DC blower

panel. Quiet and powerful: 50 CFM, 27 dB

• Superior aesthetics complement any public space

• Architectural design incorporates a highly aesthetic and durable new ﬁnish, available

in three ﬁnishes

• Attractive IR-friendly locking glass front door standard

• Available in 16, 20, and 24 rackspace sizes in 3 attractive colors: Black Cascade,

Cherry Cascade, and Teak Cascade

• Optional ﬂat screen mount accommodates most monitors up to 32” (VESA 100)

• UL Listed (structural and tip) for support of audio/video equipment

• Ships fully assembled

EIA compliant 19” mobile furniture equipment rack shall be Middle Atlantic Products model

#RFR-__28__(see chart for available models). Overall dimensions of RFR shall be __”H x 27.3”W

x 27.55”D (refer to chart). Useable height of RFR shall be __rackspaces, useable depth shall

be 23.31”. RFR shall come equipped with one pair of adjustable steel rackrail with tapped 10-32

mounting holes in universal EIA spacing, black e-coat ﬁnish and numbered rackspaces. RFR shall

have bolt through 4” height casters. RFR shall have 4 casters total, with locking front casters. RFR

shall have internal steel bracing. RFR shall be constructed of melamine and have a __ ﬁnish (refer

to chart). RFR shall have an undersized top. RFR shall include a locking and latching IR friendly

tempered glass front door. RFR shall include a locking and latching melamine rear door. RFR shall

have rear venting, cable entry and cable spools. RFR shall have a 60 MM (2.375 in.) cable grommet

on top, that accepts a monitor mount. RFR shall accept patent-pending LeverLock™ tool free and

hardware free internal cable and device management system accessories. RFR shall provide a UL

Listed load capacity of 350 lbs. mounted in the rack, 50 lbs. on top of the rack and 35 lbs. on the

optional monitor mount. RFR shall be UL Listed in the US and Canada. RFR shall be GREENGUARD

Gold Certiﬁed. RFR shall be manufactured by an ISO 9001 and ISO 14001 registered company. RFR

enclosure shall be warrantied to be free from defects in material or workmanship under normal use

and conditions 7 years.

Customizable speciﬁcation clips available at middleatlantic.com

speciﬁcations:

options:

• Rear Rackrail Kits shall be model # RFR-ERRK- __

(16, 20, 24), # equals rackspaces, which must match

number of rackspaces in rack.

• Monitor mount shall be model # MMB-1X1-12BLK,

shall have a VESA 75 and 100 pattern, and have a

17.6 lb. weight capacity

• LeverLock™ mounts shall be model number LL-RFR

• Rear blower kit shall be model # RFR-CABCOOL50

and provide 50 CFM of cooling with 27 dB of noise

EI A/ TIA CO MP LIANT

Produkt Specifikationer

Mærke:	Middle Atlantic
Kategori:	Hardwarekoeling
Model:	IDCFANKIT-4
Bredde:	483 mm
Dybde:	31 mm
Højde:	89 mm
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Indbygget skærm:	Ingen
Pakkevægt:	1392.53 g
Kølekapacitet i watt (maks.):	- W
Indgangseffekt:	- W
Certificering:	Greenguard
Harmoniseret systemkode (HS):	85389099
Bæredygtighedscertifikater:	RoHS
Indgangsspænding:	220 V
Husets farve:	Sort
Antal blæsere:	4 blæser(e)
Maksimal luftstrøm:	100 kubikfod/min.
