Side 1/3
Multi-Mount Po
EIA Compliant
wer
Designed to optimize space and efficiency in power management,
this rackmount power distribution system provides up to 20 total
outlets within a shallow depth
EXCEPTIONAL SUPPORT & PROTECTION™
Features
US: New Jersey • California • Illinois • Voice: 973-839-1011 Fax: 973-839-1976 • middleatlantic.com
Canada: Ontario • British Columbia • Voice: 613-836-2501 Fax: 613-836-2690 • middleatlantic.ca
Architects’ and Engineers’ Specifications
C U S T O M I ZA B L E S P E C I F I C AT I O N C L I P S A VA I L A B L E AT M I D D L E AT L A N T I C .C O M
96-01095 / rev g / 5-21-20 / Multi-Mount Power
Multi-Mount rackmount power distribution unit shall be Middle Atlantic Products model
# PD-_________ (refer to chart), with __ power capacity (refer to chart). Rackmount
power distribution unit shall operate on 120 volt AC/60Hz current. Rackmount power
distribution unit shall include 9' __(refer to chart) SignalSAFETM power cord with __ plug
(refer to chart), __ (8, 10) rear outlets, 10 front outlets, and 15 Amp power switch located on
the power strip’ s front (PD-2015R-HH-NS only). Rackmount power distribution shall be available
with remote notification of 2-stage surge protection (refer to chart). Rackmount power
distribution shall be available three channels of sequencing (two outlets per channel, six
total), include adjustable sequencing delays of up to six seconds, and the option of local or
remote control (refer to chart). Rackmount power distribution unit shall occupy one rackspace
and be constructed of 18-gauge phosphate pre-treated steel with a black powder coat finish.
Rackmount power distribution unit shall be ETL listed to UL standard 1419, UL 60950-1 and
UL 60065 in the US; CSA standard 60950-1, and CSA C22.2 No. 60065 in Canada.
Rackmount power strip shall be GREENGUARD Indoor Air Quality Certified and GREENGUARD
Gold Certified. Rakmount power strip shall be manufactured by an ISO 9001 registered company.
Rackmount power strip shall be warrantied to be free from defects in materials and
workmanship under normal use and conditions for a period of 3 years.
• Versatile design allows for the unit to be mounted
either horizontally or vertically in the rack
• Shallow 4” depth
• Up to 20 total outlets (on the front and rear)
• Select models include sequencing
• 9’ SignalSAFETM power cord minimizes
the effects of AC magnetic fields
• Select models include 2-stage surge protection
with remote status notification
• Reversible, adjustable mounting ears provide flexible
installation options with either 00 or 900 mounting
• Outlets are oriented in various directions to accommodate
plugs of different shapes, sizes and orientations
front of PD-2015R-HH-NS shown with
deeper set of ears for recessed mounting
front of PD-2015R-NS with
standard mounting ears
PD-2015R-HH-NS with ears rotated
for sideways mounting
Multi-Mount basic dimensions
4.08
[104]
All dimensions in inches unless otherwise noted [All dimensions in brackets are millimeters]
SIDE VIEW
(long ears for
sideways mounting)
Middle Atlantic Products
FRONT VIEW
(PD-2015R-HH-NS)
3.95
[100]
16.13 [410]
15A circuit breaker
19.00 [483]
switch controls
front outlets only
4.62
[117]
1.13 [29]
1.74 [44]
TOP VIEW
9’ 14AWG (SignalSAFETM)
line cord
®
US: New Jersey • California • Illinois • Voice: 973-839-1011 Fax: 973-839-1976 • middleatlantic.com
Canada: Ontario • British Columbia • Voice: 613-836-2501 Fax: 613-836-2690 • middleatlantic.ca
REAR VIEW
TOP VIEW
(long ears on front)
ground screw
pilot light
REAR VIEW
(PD-2015R-NS)
SIDE VIEW
PD-2015R-HH-NS
PD-2015R-NS
TOP VIEW
(short ears on front)
SIDE VIEW
(short ears for
sideways mounting)
3.62
[92] 6.36
[162]
