what are built on.great systems
™
96-976 / rev f / 5-18-20
PD Series
slim powe stripsr
high density power strips feat e a s m, ur li
low-profile design d sta ered outlets an gg
to accommodate plug-in power supplies
• UL Listed and CSA certified (PD-2420 NS UL Listed only)SC-
• (1) 15 or 20 p circuit depending on modelam
• Includes SignalSAFE™ power cord ter nated th NEMA 5-15P mi wi
or NEMA 5-20P plug depending on model
• Up to 24 outlets depending on model
• tlets spa d to a ommodate plug-in power suppliesOu ce cc
• Circuit breaker or MOV surge & EMI r & breaker pr ected, filte ot
depending on model
• Mounting hardware included
• S m low-profile gn requires less spaceli desi
• Gray outlets easy to see in rear of enclos esur
• Lightweight ano zed aldi
u num chassismi
* For additional Vertical Power S ips, please see A&E Spec # 96-938tr
High d sity s m power s ip shall be Middle Atl tic Products model # PD-__-__ th __ outlets en li tr an wi
an and __ ps (refer to chart). S m power s ip shall be__” long x 1.25” d p x 1.6” wide am li tr ee d shall
ha gray __ NEMA _ outlets (refer to chart) unique spacing pat rn that allows up to __ ve __ in te
plug- power supplies (refer to chart). S m power s ip includes _ _ p circuit breaker pr ection in li tr am ot
and mounting hardware (refer to ch
art). Terminated th _ (refer to chart) SignalSAFE™ power wi __
cord th NEMA ___ plug (refer to chart). rounding d bonding stud shall be 1/4 - 20 t ea d. wi G an hr de
S m power s ip shall be ETL listed to UL st dards 1149 d 1363 US d to CAN/CSA st dard li tr an an in an an
C22.2 #8 and C22.2 #21 in Canada. Slim power strip shall be manufactured by an ISO 9001
registered company. Slim power strip shall be warrantied to be free from defects in material or
workma hip under r l use d cond ion for perio of 3 ears. ns no ma an it s a d y
Cus mizable specification clips available at middleatl tic.comto an
options:
• Model # PB-XS, rackmounting bracket shall mount
any 8 outlet power strip (PD-815SC, PD-815SC-NS)
between rackrail of any EIA compliant 19” rack.
Includes cable management tie points
• Model # PB-5A mounting brackets shall accommodate
the mounting of vertical power strips to rackrail of any
rack
• Model # PB-DWR mounting bracket shall accommodate
the mounting of vertical power strips to rear rackrail of
Middle Atlantic Products DWR & SR series wall racks
PD-2415SC-NS
PD-815SC-NS
middleatlantic.com | middleatlantic.ca
what are built on.great systems
™
2
Part #
A
Overall Length
B
Outlet
Spacing
C
Outlet
Spacing
# of Plug In
Power Supplies
Accomodated
# Of
Outlets
Outlet
Type
Cord Length/
Termation Circuit
Surge
Protection
Overcurrent
Protection
PD-715SC-NS 13.60 [345] 1.18 [30] N/A 1 7 5-15R 10’ cord w/NEMA 5-15 plug 15 AMP (1) none circuit breaker
PD-815SC 18.60 [472] 1.18 [30] 2.48 [63] 3 8 5-15R 10’ cord w/NEMA 5-15 plug 15 AMP (1) single stage circuit breaker
PD-815SC-20 18.60 [472] 1.18 [30] 2.48 [63] 3 8 5-15R 20’ cord w/NEMA 5-15 plug 15 AMP (1) single stage circuit breaker
PD-815SC-NS 18.60 [472] 1.18 [30] 2.48 [63] 3 8 5-15R 10’ cord w/NEMA 5-15 plug 15 AMP (1) none circuit breaker
PD-815SC-PBSH* 18.60 [472] 1.18 [30] 2.48 [63] 3 8 5-15R 10’ cord w/NEMA 5-15 plug 15 AMP (1) single stage circuit breaker
PD-2415SC 60.60 [1539] 1.77 [45] 2.84 [72] 11 24 5-15R 10’ cord w/NEMA 5-15 plug 15 AMP (1) single stage circuit breaker
PD-2415SC-NS 60.60 [1539] 1.77 [45] 2.84 [72] 11 24 5-15R 10’ cord w/NEMA 5-15 plug 15 AMP (1) none circuit breaker
PD-2420SC-NS 60.60 [1539] 1.77 [45] 2.84 [72] 11 24 5-15R (22), 5-20R (2) 10’ cord w/NEMA 5-20 plug 20 AMP (1) none circuit breaker
all dimensions in inches unless otherwise noted [all dimensions in brackets are in millimeters]
PD Series Slim
basic dimensions
Note:
PD Slim Series Includes Signalsafe™ Power Cord Technology
C
B
B
C
A
A
1.46 [37]
1.71 [43]
B
A
PD-715SC-NSPD-815SC-XXPD-24XXSC-XX
ground
stud
c tircui
breaker
*PD-815SC-PBSH mounts on UXV Series fully vented utility shelves, RC and CAP Series clamping rackshelves, VRS - Vertical Rackmount Shelves, KD Series
ready-to-assemble rackshelves, RSH Series custom face rackmounts
