MDW15GSS,MDW15GBS
USER MANUAL
Warning notices: Before using this product, please read this manual carefully and keep it for future reference.
The design and specifications are subject to change without prior notice for product improvement.
Consult with your dealer or manufacturer for details.
The diagram above is just for reference. Please take the appearance of the actual product as the standard.
Download the app
& activate product
MSmartHome
Dish Washer
THANK YOU LETTER
01
02
16
12
11
30
32
35
39
40
08
10
41
SAFETY INSTRUCTIONS
SPECIFICATIONS
PRODUCT OVERVIEW
QUICK START GUIDE
PRODUCT INSTALLATION
OPERATION INSTRUCTIONS
APP SETUP AND OPERATION
CLEANING AND MAINTENANCE
TROUBLESHOOTING
TRADEMARKS, COPYRIGHTS AND LEGAL STATEMENT
DISPOSAL AND RECYCLING
DATA PROTECTION NOTICE
THANK YOU LETTER
Thank you for choosing Midea! Before using your new Midea product, please read
this manual thoroughly to ensure that you know how to operate the features and
CONTENTS
Intended Use
Explanation of Symbols
SAFETY INSTRUCTIONS
02
The following safety guidelines are intended to
prevent unforeseen risks or damage from unsafe
or incorrect operation of the appliance. Please
check the packaging and appliance on arrival to
make sure everything is intact to ensure safe
operation. If you find any damage, please contact
the retailer or dealer.
Please note modifications or alterations to the
appliance are not allowed for your safety concern.
Unintended use may cause hazards and loss of
warranty claims.
Danger
This symbol indicates that there are dangers
to the life and health of persons due to
extremely flammable gas.
Warning of electrical voltage
This symbol indicates that there is a danger
to life and health of persons due to voltage.
Warning
The signal word indicates a hazard with a
medium level of risk which, if not avoided,
may result in death or serious injury.
Read these operating instructions carefully and
attentively before using/commissioning the unit and
keep them in the immediate vicinity of the installation
site or unit for later use!
03
Caution
The signal word indicates a hazard with a
low degree of risk which, if not avoided,
may result in minor or moderate injury.
Attention
The signal word indicates important
information (e.g. damage to property),
but not danger.
Observe instructions
This symbol indicates that a service
technician should only operate and maintain
this appliance in accordance with the
operating instructions.
04
DANGER: Risk of Fire/Flammable materials
When using your dishwasher, follow the precautions
listed below:
Installation and repair can only be carried out by a
qualified technician.
This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, offices and other
working environments;
-farm houses;
-by clients in hotels, motels and other residential
type environments;
-bed and breakfast type environments.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be done by children
without supervision. (For EN60335-1)
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety. (For IEC60335-1)
Packaging material could be dangerous for children!
Children should be supervised to ensure that they do
not play with the appliance.
This appliance is for indoor household use only.
Earthing Instructions
05
To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
Please unplug before cleaning and maintenance the
appliance. Use a soft cloth moisten with mild soap,
and then use a dry cloth to wipe it again.
If the supply cord is damaged, it must be replaced by
the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the
risk of an electric shock by providing a path of least
resistance of electric current. This appliance is
equipped with an earthing conductor plug.
The plug must be plugged into an appropriate outlet
that is installed and earthed in accordance with all
local codes and ordinances.
Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded.
Do not modify the plug provided with the appliance
if it does not fit the outlet.
Have a proper outlet installed by a qualified
electrician.
Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
Do not operate your dishwasher unless all enclosure
panels are properly in place.
Open the door very carefully if the dishwasher is
06
operating, there is a risk of water squirting out.
Do not place any heavy objects on or stand on the
door when it is open. The appliance could tip
forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal;
2) Warning: Knives and other utensils with sharp
points must be loaded in the basket with their points
facing down or placed in a horizontal position.
Some dishwasher detergents are strongly alkaline.
They can be extremely dangerous if swallowed.
Avoid contact with the skin and eyes and keep
children away from the dishwasher when the door is
open.
Check that there are no detergent residues after
completion of the wash cycle.
Do not wash plastic items unless they are marked
“dishwasher safe” or the equivalent.
For unmarked plastic items not so marked, check the
manufacturer's recommendations.
Use only detergent and rinse agents recommended
for use in an automatic dishwasher.
Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
The door should not be left open, since this could
increase the risk of tripping.
During installation, the power supply must not be
excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance needs to be connected to the main
water valve using new hose sets. Old sets should not
be reused.
Disposal
07
To save energy, in stand by mode, the appliance will
switch of automatically after 15 minutes without any
user interaction.
The maximum number of place settings to be
washed is 15.
The maximum permissible inlet water pressure is
1MPa.
The minimum permissible inlet water pressure is
0.04MPa.
For disposing of package and the appliance please
go to a recycling center.
Therefore cut off the power supply cable and make
the door closing device unusable.
Cardboard packaging is manufactured from recycled
paper and should be disposed in the waste paper
collection for recycling.
By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for
the environment and human health, which could
otherwise be caused by inappropriate waste handling
of this product.
For more detailed information about recycling of this
product, please contact your local city office and
your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste separately
for special treatment is necessary.
08
SPECIFICATIONS
845 mmHeight (H)
Width (W)
Depth (D1)
Depth (D2)
598 mm
600 mm (with the door closed)
1175 mm (with the door opened 90°)
W
D1
H
D2
Product information sheet
Manufacturer
Type/Description
Standard place settings
Energy efficiency class
Water consumption class
Standard cleaning cycle
Energy consumption of the standard cleaning cycle
Water consumption of the standard cleaning cycle
Program duration of the standard cleaning cycle
Noise level
Mounting
Could be built-in
Power consumption
Rated voltage/frequency
Water pressure (flow pressure)
MIDEA
MDW15GSS,MDW15GBS
15
ECO
0.75 kWh
12.7liter
190 min
49 dB(A) re 1 pW
Free standing
YES
1760-2100W
AC 220-240V/50Hz
0.04-1.0MPa=0.4-10 bar
3.5
4.5
09
Inner pipe
Dispenser
Lower spray arm
Filter assembly
Top spray arm
Cutlery rack Lower basketUpper basket
Upper spray
arm
Cup rack
Product
PRODUCT OVERVIEW
IMPORTRANT
To get the best performance from your dishwasher, read all operating
instructions before using it for the first time.
NOTE
Pictures are only for reference, different models may be different.
10
Drain Pipenondetachable
Inlet Pipe
Lenght: 1800mm
Connector: 3/4(inch)
Lenght: 1800mm
External diameter35mm
QUICK START GUIDE
Please read the corresponding content in the instruction manual
for detailed operating method.
11
1.Install the dishwasher
3. Load the baskets.
Inside Outside
5. Select a suitable program
and start the dishwasher.
4. Fill the dispenser with
detergent and rinse aid.
2. Remove larger residue
from dishes.
Avoid pre-rinsing.
About Power Connection
Water Supply And Drain
Electrical Shock Hazard
Disconnect electrical power before installing dishwasher.
Failure to do so could result in death or electrical shock.
For personal safety:
Do not use an extension cord or an adapter plug with this appliance.
Do not, under any circumstances, cut or remove the earthing
connection from the power cord.
The installation of the pipes and electrical equipments should
be done by professionals.
Electrical requirements
Please look at the rating label to know the rating voltage and connect the dishwasher
to the appropriate power supply. Use the required fuse 10A/13A/16A, time delay fuse or
circuit breaker recommended and provide separate circuit serving only this appliance.
Cold water connection
Connect the cold water supply hose to a threaded
3/4(inch) connector and make sure that it is fastened
tightly in place.
If the water pipes are new or have not been used for
an extended period of time, let the water run to make
sure that the water is clear. This precaution is needed
to avoid the risk of the water inlet to be blocked and
damage the appliance.
Electrical connection
Ensure the voltage and frequency of the power being corresponds to those on the
rating plate. Only insert the plug into an electrical socket which is earthed properly.
If the electrical socket to which the appliance must be connected is not appropriate
for the plug, replace the socket, rather than using a adaptors or the like as they could
cause overheating and burns.
Ensure that proper earthing exists before use
ordinary supply hose
WARNING
WARNING
Attention
12
PRODUCT INSTALLATION
13
Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into
the sink, making sure to avoid bending or crimping it. The height of drain pipe must be
less than 1000 mm. The free end of the hose must not be immersed in water to avoid
the back flow of it.
How to connect the safety supply hose
1. Pull the safety supply hoses out from storage compartment located at
rear of dishwasher.
2. Tighten the screws of the safety supply hose to the faucet with thread 3/4inch.
3. Turn the water fully on before starting the dishwasher.
How to disconnect the safety supply hose
1. Turn off the water.
2. Unscrew the safety supply hose from the faucet.
Connection Of Drain Hoses
Please securely fix the drain hose in either position A or position B
B
A
MAX 1000 mm
Counter
Drain hose
Back of dishwasher
Water Inlet
Drain Pipe
Mains Cable
40 mm
Drain Pipe
Free Standing Installation
Type 1: Fitting between existing carbinets
The height of the dishwasher, 845 mm, has been
designed in order to allow the machine to be fitted
between existing cabinets of the same height in
modern fitted kitchens. The feet can be adjusted so
that correct height is reached.
The laminated top of the machine does not require
any particular care since it is heatproof, scratchproof
and stainproof.
14
Extension hose
If you need a drain hose extension, make sure to use a similar drain hose.
It must not be longer than 4 meters, otherwise the cleaning effect of the dishwasher
could be reduced.ance.
Positioning The Appliance
Position the appliance in the desired location. The back should rest against the wall
behind it, and the sides, along the adjacent cabinets or walls. The dishwasher is
equipped with water supply and drain hoses that can be positioned either to the
right or the left sides to facilitate proper installation.
Syphon connection
The waste connection must be at a height less than 1000 mm (maximum) from the
bottom of the dishwasher.
Levelling the appliance
Once the appliance is positioned for levelling, the height of
the dishwasher may be altered via adjustment of the screwing
level of the feet.
In any case, the appliance should not be inclined more than 2°
How to drain excess water from hoses
If the connection to the drain pipe is positioned higher than 1000 mm, excess water
may remain in the drain hose. It will be necessary to drain excess water from the hose
into a bowl or suitable container that is held outside and lower than the sink.
Water outlet
Connect the water drain hose. The drain hose must be correctly fitted to avoid water
leaks. Ensure that the water drain hose is not kinked or squashed.
Type 2: Underneath existing work top
(When fitting beneath a work top)
In most modern fitted kitchens there is only one single
work top under which cabinets and electrical appliances
are fitted. In this case remove the work top of the
dishwasher by unscrewing the screws under the rear edge
of the top (a).
After removing the work top, the screws must be screwed again under the rear edge
of the top (b).
Attention
a
a
b
b
15
Selecting the best location for the dishwasher
The installation position of the dishwasher should be near the existing inlet and drain
hose and power socket.
Illustrations of cabinet dimensions and installation position of the dishwasher.
1. Less than 5 mm between the top of dishwasher and cabinet and the outer door
aligned to cabinet.
90 °
90 °
580mm
820mm
100
Electrical, drain
and water supply
line connection
Space between cabinet
bottom and floor
600 mm(for 60cm model)
450 mm(for 45cm model)
80
2. If dishwasher is installed at the corner of the cabinet,
there should be some space when the door is opened.
Depending on where your electrical outlet is, you may
need tocut a hole in the opposite cabinet side.
Dishwasher
Door of
dishwasher
Cabinet
Minimum space
of 50mm
Control Panel
OPERATION INSTRUCTIONS
Description
No.1
Press this button to turn on your dishwasher.
16
Power
Press the button to set the delay time.
No.4
Delay
When you have about or less than half of full place
settings dishware to wash, you can choose this
function to save energy and water. (It can not be
used with Rapid.)
Half load
No.6
10
No.2
Wi-Fi
Press the button for more than 3 seconds. After a
shout bleeping and the icon starts to blink slowly,
it's in the network linking status to APP.
Slowly flashing shows DW is waiting for connection.
Quickly flashing shows DW is connecting.
Quickly flashing solid shows DW is connected to
your wireless router.
This option allows you to lock the buttons on the
control panel, except the Power button, so children
cannot accidently start the dishwasher by pressing
the buttons on the panel.
To lock or unlock the buttons on the control panel,
press the button for 3 seconds.
No.7
Child lock
1
Press these buttons to select the appropriate
washing program, the corresponding program
indicator will be lit.
No.3
Program
2 3 3 4 5 6 7 8109 11 12
For better drying result. (It can't not be used with
Rapid)
No.5
Extra drying
17
Description
Rapid
No.9
Program
indicators
A shorter wash for lightly soiled loads that do not
need drying.
Glass
For lightly soiled crockery and glass.
90 min
For normally soiled loads that need quick wash.
This program provides an effective cleaning of the
dishwasher itself.
IntensiveCare+
For the heaviest soiled crockery, and normally soiled
pots, pans, dishes etc. With dried-on food.
MachineCare+
Press the button to select either upper basket or
lower basket loaded, and the corresponding indicator
will light up.
Alt
No.10
Cloud
wash
This is standard program, it is suitable to clean
normally soiled tableware and it is the most efficient
program in terms of its combined energy and water
consumption for that type of tableware.
ECO
Hygienecare+
Use to sanitize your dishes and glassware. The
highest water temperature is 72°C.
Whisper
Lower noise and normally energy consumption, used
for washing in evening.
No.8
Delay time
To show the delay time. (3h/6h/9h/12h)
No.11
Warning
indicators
Program end
when the program is end, the indicator will be lit.
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is
low on dishwasher rinse aid and needs to be refilled.
Water Faucet
If the “ ” indicator is lit, it means the water faucet
closed.
No.12
After completing program and function selection
or delay time setting, press this button to start.
When the washing program is running, after the
program is suspended by opening the door, press
and hold this button for 3 seconds to cancel the
current program and function.
Start/Pause
This button refers to a variety of washing programs
or function that can be selected in the APP.
If the washing program has not been activated in
the APP, the Glass will be activated by default.
Cloud wash
When you select Upper, only the dishes in the upper
rack will be washed. The spray system of the lower
basket will not operate.
Upper
When you select Lower, only the dishes in the lower
rack will be washed. The spray system of the upper
basket will not operate.
Lower
The table below shows which programs are best for the levels of food residue
on them and how much detergent is needed. It also show various information about
the programs. Consumption values and program duration are only indicative except
for the ECO program.
Programs
( )indicates that the program uses rinse aid in the last rinse.
: This program is the test cycle. The information for comparability test in
accordance with *AS/NZS 2007.1.
*AS/NZS 2007.1
NOTE
Program
Description
Of Cycle
Running
Time(min)
Energy
(kWh)
Water
(L)
Rinse
Aid
Detergent
Pre/Main Wash
Rapid
Wash (40
°C
)
Rinse
Rinse (45
°C
)
IntensiveCare+
MachineCare+
Prewash
Wash (72
°C
)
Rinse
Rinse (70
°C
)
Drying
11.6
5/28.7g
Or all in 1
5/28.7g
Or all in 1
5/28.7g
Or all in 1
5/28.7g
Or all in 1
5/28.7g
Or all in 1
25g
Or all in 1
15.41.50
11.01.4
12.70.75
1.27
11.40.6
HygieneCare+
Prewash
Wash (72
°C)
Rinse
Rinse (70
°C
)
Drying
Wash (72
°C)
Rinse
Rinse (65
°C
)
Drying
14.51.99159
178
15020
190
90
3025
Whisper
13.61.32165
Prewash(45
°C
)
Wash(55
°C
)
Rinse
Rinse(65
°C
)
Drying
Wash(50
°C
)
Rinse
Rinse(45
°C
)
Drying
Wash(65
°C
)
Rinse
Rinse(65
°C
)
Drying
18
(
*AS/NZS 2007.1
)
Glass
Prewash
Wash (42
°C
)
Rinse
Rinse (60
°C
)
Drying
13.10.86125
90 min
19
Preparing And Loading Dishes
Consider buying utensils which are identified as dishwasher-proof.
For particular items, select a program with the lowest possible temperature.
To prevent damage, do not take glass and cutlery out of the dishwasher immediately
after the program has ended.
For washing the following cutlery/dishes
Are not suitable
Cutlery with wooden, horn china or mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not temperature resistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Very small items should not be washed in the dishwasher as they could easily fall
out of the basket.
NOTE
Are of limited suitability
Some types of glasses can become dull after a large number of washes
Silver and aluminum parts have a tendency to discolor during washing
Glazed patterns may fade if machine washed frequently
Recommendations for loading the dishwasher
Scrape off any large amounts of leftover food. Soften remnants of burnt food in
pans. It is not necessary to rinse the dishes under running water.
For best performance of the dishwasher, follow these loading guidelines.
(Features and appearance of baskets and cutlery baskets may vary from your model.)
Place objects in the dishwasher in the following way:
tems such as cups, glasses, pots, pans, etc. must face downwards.
Curved items, or ones with recesses, should be loaded aslant so that water can run off.
All utensils are stacked securely and can not tip over.
All utensils are placed in the way that the spray arms can rotate freely during washing.
Load hollow items such as cups, glasses, pans etc. With the opening facing downwards
so that water cannot collect in the container or a deep base.
Dishes and items of cutlery must not lie inside one another, or cover each other.
To avoid damage, glasses should not touch one another.
The upper basket is designed to hold more delicate and lighter dishware such as glasses,
coffee and tea cups.
Long bladed knives stored in an upright position are a potential hazard!
Long and sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
Loading the cutlery rack
Cutlery should be placed in the cutlery rack separate from each other in the appropriate
positions. Avoid nesting of the cutlery to prevent insufficient cleaning performance.
Removing the dishes
To prevent water dripping from the upper basket into the lower basket, we
recommend that you empty the lower basket first, followed by the upper basket.
WARNING
Items will be hot! To prevent damage, do not take glass and
cutlery out of the dishwasher for around 15 minutes after the
program has ended.
Loading the upper basket
The upper basket is designed to hold more delicate
and lighter dishware such as glasses, coffee and tea
cups and saucers, as well as plates, small bowls and
shallow pans (as long as they are not too dirty).
Position the dishes and cookware so that they will
not get moved by the spray of water.
Loading the lower basket
We suggest that you place large and difficult to clean
items into the lower basket: such as pots, pans, lids,
serving dishes and bowls, as shown in the figure below.
It is preferable to place serving dishes and lids on the
side of the racks in order to avoid blocking the rotation
of the top spray arm.
The maximum diameter advised for plates in front of
the detergent dispenser is of 19 cm, this not to hamper
the opening of it.
20
LOADING THE BASKETS ACCORDING TO AS/NZS 2007.1:
Number Item
1
2
3
Cups
Saucers
Glasses
Number Item
4
5
6
Soup plates
Dessert plates
Dinner plates
1.Upper basket:
2.Lower basket:
21
5 5 66 4
445
3
1
2
3.Cutlery rack:
Number Item
1
2
3
4
5
Forks
Soup spoons
Dessert spoons
Teaspoons
Knives
Information for comparability tests in accordance with (*AS/NZS 2007.1 )
Capacity: 15 place settings
Position of the upper basket: lower position
Program: ECO
Rinse aid setting: 6
Detergent(Pre/main): 5g/28.7g
Door is open at the end of the drying cycle for the drying performance test
and last 40mins.
(Door position: Open 50 mm)
22
2 51 4443
4
5
2
1
5
3
3
5
1
2
5
4
Folding back the cup shelves
To make room for taller items in the upper basket, raise the cup rack upwards.
You can then lean the tall glasses against it.
1. To raise the upper basket, just lift
the upper basket at the center of
each side until the basket locks into
place in the upper position. It is not
necessary to lift the adjuster handle.
2. To lower the upper basket, lift the
adjust handles on each side to
release the basket and lower it to
the lower position.
Basket Loading Tips
Adjusting the upper basket
The height of the upper basket can be easily adjusted to accommodate taller dishes in
either the upper or lower basket.
To adjust the height of the upper rack, follow these steps:
Folding back the rack shelves
The spikes of the lower basket are used for holding plates and a platter.
They can be lowered to make more room for large items.
raise upwards fold backwards
23
Cutlery Rack Used Tips
1. Lift the right basket up, both left and right baskets
are flat.
2. Move the right basket from right to left, two basket
are overlapping.
3. Remove the right basket from the tray, only has the
left basket.
23
Easy removal of cutlery
Using the principle of crank slider mechanism, the cutlery are suspended. Convenient
finger goes deep under the knife and fork, and holds several cutlery at a time.
Make the most of space
It can accommodate dishes such as egg beaters, cups, etc., and does not affect the
upper basket.
Adjust the height of the rack
Loosen the four buttons on the tray and press down gently.
23
Function of detergent
The chemical ingredients that compose the detergent are necessary to remove,
crush and dispense all dirt out of the dishwasher. Most of the commercial quality
detergents are suitable for this purpose.
When to refill the rinse aid
The regularity of the dispenser needing to be refilled depends on how often dishes are
washed and the rinse aid setting used.
The Low Rinse Aid indicator ( )will be lit when more rinse aid is needed.
Do not overfill the rinse aid dispenser.
Function Of The Rinse Aid And Detergent
The rinse aid is released during the final rinse to prevent water from forming droplets on
your dishes, which can leave spots and streaks. It also improves drying by allowing water
to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any
other substances (e.g. Dishwasher cleaning agent, liquid detergent). This would damage
the appliance.
Proper Use of Detergent
Use only detergent specifically made for dishwashers use. Keep your detergent
fresh and dry.
Do not fill detergent into the dispenser until you are ready to start the dishwasher.
Dishwasher detergent is corrosive! Keep dishwasher detergent out of the
reach of children.
WARNING
WARNING
26
Filling The Rinse Aid Reservoir
The rinse aid is released during the final rinse to prevent water from forming droplets on
your dishes, which can leave spots and streaks. It also improves drying by allowing water
to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.
3. Close the cap after all.
1. Remove the rinse reservoir cap by
lifting up the handle .
2. Pour the rinse aid into the dispenser,
being careful not to overfill.
Rinse aid level Selector position
d1
d2
d3
d4
d5
Cloud wash Light bright
Rapid Light bright
Rapid, Cloud wash Light bright
90 min Light bright
90 min, Cloud wash Light bright
Adjusting the rinse aid reservoir
To achieve a better drying performance with limited rinse aid, the dishwasher is
designed to adjust the consumption by user. Follow the below steps.
1. Close the door, switch on the appliance.
2. Within 60 seconds after the appliance was switched on press the Program “ ”
button for more than 5 seconds to enter the set model, the rinse aid indication
blinks as 1Hz frequency.
3. Press the Program “ ” button again to select the proper set according to your
using habits, the setting will change in the following sequence:
d3->d4->d5->d1->d2->d3.
The higher the number, the more rinse aid the dishwasher uses.
4. Without operation in 5 seconds or press the Power button to complete the setup
and exit the setting mode.
27
Saving Energy
1. Pre-rinsing of tableware items leads to increased water and energy consumption
and is not recommended.
2. Washing tableware in a household dishwasher usually consumes less energy and
water in the use phase than hand dishwashing when the household dishwasher is
used according to the instructions.
Filling The Detergent Dispenser
Please observe the manufacturer's recommendations on the detergent packaging.
NOTE
1. Open the cap by pressing in the
release latch.
2. Add detergent into the larger cavity
(A) for main wash.
For better cleaning result, especially
if you have very dirt items, pour a small
amount of detergent onto the door.
The additional detergent will activate
during the pre-wash phase.
B
A
3. Close the flap by sliding it to the front
and then pressing it down.
Press in
28
A program can only be changed if it has been running only for a short period of time,
otherwise the detergent may have already been released or the the wash water with
detergent has already been drained. If this is the case, the dishwasher needs to be reset
and the detergent dispenser must be refilled. To reset the dishwasher, follow the
instructions below:
1. Press the Start/Pause button to pause the washing.
2. Press the Start/Pause button for more than 3 seconds - the program will cancel.
3. Press the Program “ < ” or “ > ” button to select the desired program.
4. Press the Start/Pause button, the dishwasher will start after a few seconds.
Forget To Add A Dish?
A forgotten dish can be added any time before the detergent dispenser opens. If
this is the case, follow the instructions below:
1. Press the Start/Pause button to pause the washing.
2. After the spray arms stopped working, you can open the door completely.
3. Add the forgotten dishes.
4. Close the door.
5. Press the Start/Pause button, the dishwasher will continued to run after 10 seconds.
It is dangerous to open the door mid-cycle,
as hot steam may scald you.
WARNING
After 5 sec
Starting A Program
1. Draw out the lower and upper basket, load the dishes and push them back.
It is commended to load the lower basket first, then the upper one.
2. Pour in the detergent.
3. Insert the plug into the socket. The power supply refer to last page ”Product fiche”.
Make sure that the water supply is turned on to full pressure.
4. Close the door, press the Power button.
5. Choose a program, the response light will turn on. Then press the Start/Pause
button, the dishwasher will start its cycle after a few seconds.
29
Changing The Program Mid-cycle
3 sec
30
APP SETUP AND OPERATION
Download the MSmarthome App
On an app market (Google Play Store, Apple App
MSmartHome app. Download and install it on your
phone. You can also download the app by scanning the
QR code below.
Download the app
& activate product
MSmartHome
Register and log in
Open the MSmartHome app, and create a new account
to start (you can also register through a third-party
account). If you already have an existing account, use
the account to log in.
Connect your devices to MSmarthome
1.
Please make sure your mobile phone is connected
to a wireless network. If it is not, go to Settings
and enable wireless networks and Bluetooth.
2.
Please power on your devices.
3.
Open MSmarthome App on your phone.
4.
If a message of "Smart devices discovered
nearby" appears, click to add.
Washing machine
...
5.
If no message appears, select “+” on the page and
select your device in the list of nearby devices
available. If your device is not listed, please add
your device manually by the device category and
device model.
6.
Connect your device to the wireless network
according to instructions on app. If the
connection fails, please follow the instructions
provided by the app to continue with the
operation.
Add device
8:88
NOTE
31
1.
Make sure your devices are powered on.
2.
Keep your mobile phone close enough to your device when you are connecting
your device to the network.
3.
Connect your mobile phone to the wireless network at home, and make sure
you know the password of the wireless network.
4.
Check if your wireless router supports 2.4 GHz band and turn it on. If you are
not sure whether the router supports 2.4 GHz band, please contact the router
manufacturer.
5.
The device cannot connect to the wireless network that requires authentication,
and it usually appears in public areas such as hotels, restaurants, etc. Please
connect to a wireless network that does not require authentication.
6.
Turn off the WLAN+ (Android) or WLAN Assistant (iOS) function of your
mobile phone when connecting your device to the network.
7.
In the case that your device connected to a wireless network before but it
needs to reconnect, please click “+” on the app Home page, and add your
device again by the device category and model according to the instructions
on app.
External Care
CLEANING AND MAINTENANCE
The door and the door seal
Clean the door seals regularly with a soft damp cloth to remove food deposits.When
the dishwasher is being loaded, food and drink residues may drip onto the sides of
the dishwasher door. These surfaces are outside the wash cabinet and are not
accessed by water from the spray arms. Any deposits should be wiped off before the
door is closed.
Internal Care
Filtering system
The filtering system in the base of the wash cabinet retains coarse debris from the
washing cycle, including foreign objects such as tooth picks or shards. The collected
coarse debris may cause the filters to clog. Check the condition of the filters regularly,
carefully remove foreign objects and clean the parts of the filtering system if necessary
with water. Follow the steps below to clean the filter.
The control panel
If cleaning is required, the control panel should be wiped with a soft damp cloth only.
32
To avoid penetration of water into the door lock and electrical components, do not
use a spray cleaner of any kind.
Never use abrasive cleaners or scouring pads on the outer surfaces because they
may scratch the finish. Some paper towels may also scratch or leave marks on the
surface.
Pictures are only for reference, different models of the filtering system and spray
arms may be different.
1. Hold the coarse filter and rotate
it anticlockwise to unlock the
filter. Lift the filter upwards and
out of the dishwasher.
2. The fine filter can be pulled off the
bottom of the filter assembly. The
coarse filter can be detached from
the main filter by gently squeezing
the tabs at the top and pulling it away.
WARNING
WARNING
Main filter
Coarse filter
Fine filter
33
3. Larger food remnants can be
cleaned by rinsing the filter under
running water. For a more thorough
clean, use a soft cleaning brush.
4. Reassemble the filters in the reverse
order of the disassembly, replace the
filter insert, and rotate clockwise to
the close arrow.
It is necessary to clean the spray arms regularly for hard water chemicals will clog the
spray arm jets and bearings.
To clean the spray arms, follow the instructions below:
Spray arms
EN
Do not over tighten the filters. Put the filters back in sequence securely, otherwise
coarse debris could get into the system and cause a blockage.
Never use the dishwasher without filters in place. Improper replacement of the filter
may reduce the performance level of the appliance and damage dishes and utensils.
1. To remove the upper spray
arm, hold the nut in the center
still and rotate the spray arm
counterclockwise to remove it.
2. To remove the lower spray
arm, pull out the spray arm
upward.
3. Wash the arms in soapy and
warm water and use a soft
brush to clean the jets.
WARNING
Frost precaution
Please take frost protection measures on the dishwasher in winter. Every time after
washing cycles, please operate as follows:
1. Cut off the electrical power to the dishwasher at the supply source.
2. Turn off the water supply and disconnect the water inlet pipe from the water valve.
3. Drain the water from the inlet pipe and water valve. (Use a pan to gather the water)
4. Reconnect the water inlet pipe to the water valve.
5. Remove the filter at the bottom of the tub and use a sponge to soak up water in
the sump.
After every wash, turn off the water supply to the appliance and leave the door
slightly open for a while so that moisture and odors are not trapped inside.
Before cleaning or performing maintenance, always remove the plug from the socket.
To clean the exterior and rubber parts of the dishwasher, do not use solvents or
abrasive cleaning products. Only use a cloth with warm soapy water.
To remove spots or stains from the surface of the interior, use a cloth dampened
with water an a little vinegar, or a cleaning product made specifically for dishwashers.
It is recommend that you run a wash cycle with the dishwasher empty and then
remove the plug from the socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door seals to last longer and prevent
odors from forming within the appliance.
If the appliance must be moved, try to keep it in the vertical position. If absolutely
necessary, it can be positioned on its back.
One of the factors that cause odours to form in the dishwasher is food that remains
trapped in the seals. Periodic cleaning with a damp sponge will prevent this from
occurring.
34
Caring For The Dishwasher
After every wash
Remove the plug
No solvents or abrasive cleaning
When not in use for a long time
Moving the appliance
Seals
35
EN
TROUBLESHOOTING
Possible reason SolutionProblem
Dishwasher doesn't
start
Before Calling For Service
Reviewing the charts on the following pages may save you from calling for service.
Replace fuse or reset circuit breaker.
Remove any other appliances sharing
the same circuit with the dishwasher.
Make sure the dishwasher is turned
on and the door is closed securely.
Make sure the power cord is
properly plugged into the wall socket.
Stained tub interior
Spilled rinse aid. Always wipe up rinse aid spills
immediately.
Detergent with
colourant
may have been used.
Make sure that the detergent has no
colourant.
Water not pumped
form dishwasher
Check that the water supply is
connected properly and the water
is turned on.
Door of dishwasher
not properly closed.
Make sure to close the door
properly and latch it.
Twisted or trapped
drain hose.
Check the drain hose.
Filter clogged. Check the filter system.
Foam in the tub
Check the kitchen sink to make sure
it is draining well. If the problem is
the kitchen sink that is not draining ,
you may need a plumber rather than
a serviceman for dishwashers.
Fuse blown, or the
circuit break tripped.
Power supply is not
turned on.
Water pressure is low
Kitchen sink clogged.
Wrong detergent.
Use only the special dishwasher
detergent to avoid suds. If this occurs,
open the dishwasher and let suds
evaporate. Add 1 liter of cold water
to the bottom of the dishwasher.
Close the dishwasher door, then select
any cycle. Initially, the dishwasher will
drain out the water. Open the door
after draining stage is complete and
check if the suds have disappeared.
Repeat if necessary.
36
Possible reason SolutionProblem
There are rust
stains on cutlery
The affected items
are not corrosion resistant.
Avoid washing items that are not
corrosion resistant in the dishwasher.
Items are blocking
the movement of
the spray arms.
Rearrange the items so that the spray
can rotate freely.
The filter combination
is not clean or is not
correctly fitted in the
base of wash cabinet.
This may cause the spray
arm jets to get blocked.
Clean and/or fit the filter correctly.
Clean the spray arm jets.
Knocking noise in
the dishwasher
Rattling noise in
the dishwasher
Interrupt the program and
rearrange the items which are
obstructing the spray arm.
Items of crockery
are loose in the
dishwasher.
Interrupt the program and
rearrange the items of crockery.
Knocking noise in
the water pipes
The dishes
are not clean
This may be caused
by on-site installation
or the cross-section
of the piping.
This has no influence on the
dishwasher function. If in doubt,
contact a qualified plumber.
Select a more intensive program.
Not enough detergent
was dispensed.
Use more detergent, or change
your detergent.
White film on
inside surface
Hard water minerals. To clean the interior, use a damp
sponge with dishwasher detergent
and wear rubber gloves. Never use
any other cleaner than dishwasher
detergent otherwise, it may cause
foaming or suds.
A spray arm is knocking
against an item in a
basket
Cloudiness on
glassware.
Combination of soft
water and too much
detergent.
Use less detergent if you have soft
water and select a shorter cycle to
wash the glassware and to get
them clean.
The dishes were not
loaded correctly.
The program was
not powerful enough.
Black or grey
marks on dishes
Detergent left in
dispenser
Aluminium utensils
have rubbed against
dishes
Use a mild abrasive cleaner to
eliminate those marks.
Dishes block
detergent dispenser
Re-loading the dishes properly.
See the “Preparing And Loading
Dishes”.
Possible reason SolutionProblem
The Cloud Wash
light flicker fleetly
The Cloud Wash
and Rapid light
flicker fleetly
The 90 min light
flicker fleetly
Faucets is not opened, or water
intake is restricted, or water
pressure is too low.
Not reaching required
temperature.
Malfunction of heating element.
Overflow. Some element of dishwasher leaks.
Longer inlet time.
ERROR CODES
If there is a malfunction the dishwasher will display an error code. The following table
shows possible error codes and their causes.
The Cloud Wash,
ECO and 90 min
light flicker fleetly
Failure of communication
between main circuit board
with display circuit board.
Open circuit or break wiring for
the communication.
If overflow occurs, turn off the main water supply before calling a service.
If there is water in the base pan because of an overfill or small leak, the water should
be removed before restarting the dishwasher.
If there is an error code that cannot be solved, please request professional assistance.
WARNING
37
Possible reason SolutionProblem
The dishes aren't
drying
Use gloves if detergent residue can
be found on dishes to avoid skin
irritations.
With a short program, the
washing temperature is lower,
decreasing cleaning performance.
Choose a program with a long
washing time.
Improper loading
Dishes are removed
too soon
Wrong program has
been selected.
Use of cutlery with a
low-quality coating.
Self-repair or non-professional repair may cause serious risks to the safety of the user
of the appliance and impact warranty.
Water drainage is more difficult with
these items. Cutlery or dishes of this
type are not suitable for washing in
the dishwasher.
Do not empty your dishwasher
immediately after washing. Open
the door slightly so that the steam
can come out. Take out the dishes
until the inside temperature is safe
to touch. Unload the lower basket
first to prevent the dropping water
from the upper basket.
WARNING
39
logo, word marks, trade name, trade dress and all versions thereof are
trademarks, copyrights and other intellectual property rights, and all goodwill derived
from using any part of an Midea trademark. Use of Midea trademark for commercial
purposes without the prior written consent of Midea may constitute trademark
infringement or unfair competition in violation of relevant laws.
This manual is created by Midea and Midea reserves all copyrights thereof. No entity or
individual may use, duplicate, modify, distribute in whole or in part this manual, or
bundle or sell with other products without the prior written consent of Midea.
All the described functions and instructions were up to date at the time of printing this
manual. However, the actual product may vary due to improved functions and designs.
TRADEMARKS, COPYRIGHTS
AND LEGAL STATEMENT
Important instructions for environment
Compliance with RoHS Directive
Package information
40
DISPOSAL AND RECYCLING
Compliance with the WEEE Directive and Disposing of the Waster Product:
This product complies with EU WEEE Directive (2012/19/EU). This product bears a
classification symbol for waster electrical and electronic equipment (WEEE).
This symbol indicates that this product shall not be disposed
with other household wastes at the end of its service life. Used
recycling of electrical electronic devices. To find these
collection systems please contact to your local authorities or
retailer where the product was purchased. Each household
performs important role in recovering and recycling of old
appliance. Appropriate disposal of used appliance helps
prevent potential negative consequences for the environment
and human health.
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does
not contain harmful and prohibited materials specified in the Directive.
Packaging materials of the product are manufactured from
recyclable materials in accordance with our National Environ-
ment Regulations. Do not dispose of the packaging materials
together with the domestic or other wastes. Take them to the
packaging material collection points designated by the local
authorities.
41
DATA PROTECTION NOTICE
For the provision of the services agreed with the customer,
we agree to comply without restriction with all stipulations of applicable data protection
law, in line with agreed countries within which services to the customer will be delivered,
as well as, where applicable, the EU General Data Protection Regulation (GDPR).
Generally, our data processing is to fulfil our obligation under contract with you and for
product safety reasons, to safeguard your rights in connection with warranty and
product registration questions. In some cases, but only if appropriate data protection is
ensured, personal data might be transferred to recipients located outside of the
European Economic Area.
Further information are provided on request. You can contact our Data Protection
MideaDPO@midea.com. To exercise your rights such as right to object your
personal date being processed for direct marketing purposes, please contact us via
MideaDPO@midea.com. To find further information, please follow the QR Code.


Produkt Specifikationer

Mærke: Midea
Kategori: Opvaskemaskine
Model: MDW15GWH

Har du brug for hjælp?

Hvis du har brug for hjælp til Midea MDW15GWH stil et spørgsmål nedenfor, og andre brugere vil svare dig




Opvaskemaskine Midea Manualer

Opvaskemaskine Manualer

Nyeste Opvaskemaskine Manualer
