Side 1/5
miditech Guitarface I
miditech Guitarface I
miditech Guitarface I
miditech Guitarface Imiditech Guitarface II
I
I
I I
"Class Compliant" USB Audio Interface
(WinXP/Vista no drivers necessary)
16 Bit/ 48 kHz resolution LINE stereo interface
2 HI-Z instrument preamps
2 MIC preamps with 48V phantom power
Signal and peak indicator LEDs
Adjustable stereo LINE output
Full duplex with compatible recording software
Incl. Magix Samplitude SE and IK Multimedia Amplitube 2 Duo
Typical applications:
LINE, instruments and MIC recordings
Low latency playing of VST instruments
eMail: Internet: info@miditech.de www.miditech.de
1
Operating Instructions
Thank you for deciding to purchase the Miditech Guitarface II, we are certain you will be delighted
with its performance and advanced features. Guitarface II enables you to easily digitize all your
analog sound sources from any LINE level devices, e.g. music cassette decks or CD players, etc.
With its implemented HI-Z instrument preamps you can easily digitize instruments like electric
guitars and basses. At last the integrated MIC preamp offers you the possibility to make microphone
recordings. In addition to this Guitarface II gives you a switchable phantom power for use with
condenser microphones. Please read the instructions to use this phantom power carefully! If you
use it in the wrong way, it may cause damage to your speaker system! Miditech doesn't take any
responsibilty for damage caused by improper use!
Not only does Guitarface II offer a simple solution to digitizing analogue sounds, it also gives you
the very best HiFi audio quality. The included recording software Magix "Samplitude SE" offers
you the capability to edit previously digitized music or speech. The software “IK Multimedia
Amplitube 2 Duo” gives guitarists some perfect simulated American guitar amps for use as
standalone application or as a VST instrument. The operating instructions will give you some
guidance on how to install and operate your Guitarface functions, also check the section on how to
use the free bundled companion programs - "Magix Samplitude SE" and the amp-simulation from
“IK Multimedia Amplitube 2 Duo”.
Guitarface II Technical data:
Simple computer connection via USB
"Class Compliant" device - NO driver installation necessary, runs directly under Windows
2000 SP4, Windows XP SP2 and Windows Vista
16 Bit AD/DA Converters
Sample rate 32.0 kHz, 44.1 kHz, 48.0 kHz
Frequency response 20 Hz to 20 kHz, ± 1 dB @ 44.1 kHz sample rate - 20 Hz to 22 kHz, ± 1
dB @ 48.0 kHz sample rate
THD 0.05 % typical. @ -10 dBV, 1kHz, Crosstalk -77 dB @ 0 dBV, 1 kHz
Signal-to-noise ratio A/D 89 dB typical. @ 1 kHz, A-weighted - D/A 96 dB typical. @ 1 kHz,
A-weighted
Dynamic range: >86 dB (A)
Adjustable stereo input for LINE,MIC and INSTRUMENT level devices
Stereo output for LINE level devices, left side also for stereo or headphone device
2 HI-Z instrument inputs
2 Balanced MIC inputs and MIC with +48V phantom power input switchable
Adjustable stereo headphone output for headphones
USB Powered, i.e. power supplied via USB connection of the computer
Indicator-LEDs for peak and signal
Connection and operating devices:
The product case is printed with all relevant information! There are two 6,3mm TRS input jack
sockets on the front side and adjustment switches for the input level on the back side of the
Guitarface II. On the front side you find the input switches, they switches between LINE,
instrument and MIC with +48V phantom power. Beside the inputs there are two light-emitting
diodes, the signal (green) and an overdrive (red) LED. On the rear side you find 2 TRS jack sockets
for the output. Connect these LINE out sockets with a regular Phono (RCA) cable to an amplifier.
You can use on the back side of the Guitarface II the left TRS LINE out jack socket, signed with
“S” for “stereo”, as a headphone output, the small wheel adjacent to the socket allows you to adjust
volume.
2
