Side 1/4

CCR1036-12G-4S-series

CCR1036-12G-4S-EM

CCR1036-12G-4S

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents.

Ultimate disposal of this product should be handled according to all national laws and regulations.

The Installation of the equipment must comply with local and national electrical codes.

This unit is intended to be installed in the rackmount. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system.

This product is intended to be installed indoors. Keep this product away from water, fire, humidity or hot environments.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

Read the installation instructions before connecting the system to the power source.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your

own risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

It is the customer's responsibility to follow local country regulations. All Mikrotik devices must be professionally installed.

This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take

adequate measures.

First Use

The device comes preinstalled with RouterOS and is ready to use. The ETH1 port has a default IP address for connecting: 192.168.88.1. The username is

admin and there is no password Please connect with your web browser to this IP (or, for some models, check user and wireless passwords on the sticker).

address and choose Webfig to configure it. In case the IP connection is not available, the Winbox tool ( ) can be used to connect to the https://mt.lv/winbox

MAC address of the device.

The device doesn't have any other configuration or firewall rules applied by default, please connect to it, and set up IP addresses, users, passwords,

firewall, etc. Please ensure you have prevented unauthorized access from public networks by use of the firewall filters and restrictions available in the IP

services menu in RouterOS.Detailed info on how to upgrade the device ;https://mt.lv/upgrade

See this page for connection and configuration guides: +https://mt.lv/help+

Powering

The device accepts powering from two redundant power supplies, each accepts 100-240 V AC power. You can use either, or both at the same time. Up to

60 W power consumption.

Extension Slots and Ports

12x 10/100/1000 Ethernet ports.

4x SFP cage

USB 2.0 type A

One M.2 slot, type PCIe x4

RJ45 console port

Etherboot / Netinstall is available on port ETH12.

Produkt Specifikationer

Mærke:	Mikrotik
Kategori:	Router
Model:	CCR1036-12G-4S
Vekselstrømsindgangsspænding:	110 - 220 V
Bredde:	355 mm
Dybde:	145 mm
Højde:	55 mm
Vægt:	- g
Ethernet LAN-porte (RJ-45):	12
Ethernet LAN:	Ja
Processorkerner:	36
Strømforbrug (typisk):	60 W
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Intern hukommelse:	4096 MB
Kabler inkluderet:	Vekselstrøm
Ethernet WAN:	Ja
Kabelteknologi:	10/100/1000Base-T(X)
LED-indikatorer:	Ja
AC-adapter inkluderet:	Ja
Harmoniseret systemkode (HS):	85176990
Processorfrekvens:	1200 MHz
Processormodel:	Tilera TLR4-03680CG-12CE-A3b
Flashhukommelse:	1024 MB
Ethernet-grænsefladetype:	Gigabit Ethernet
Indbygget processer:	Ja
I/O-porte:	micro USB
Stativ-montering:	Ja
RS-232-porte:	1
Rackkapacitet:	1U
Dual-band:	Ingen
