Mikrotik RB260GS Manual

Mikrotik bryter RB260GS

Læs gratis den danske manual til Mikrotik RB260GS (21 sider) i kategorien bryter. Denne vejledning er vurderet som hjælpsom af 28 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 14.5 anmeldelser. Har du et spørgsmål om Mikrotik RB260GS, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/21

EN - English -Quick Guide

EN - English -Quick GuideEN - English -Quick Guide:

This is a Network Device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um

The most important technical specifications for this product can be found on the last page of this Quick Guide.

Technical specifications, brochures, and more info about products at Full EU Declaration of Conformity, https://mikrotik.com/products

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants

First steps:

First steps:First steps:

Make sure your ISP is accepting hardware changes and will automatically assign an IP address.

Connect your ISP cable to the first Ethernet port.

Connect your PC to the Ethernet2 port.

Set your computer IP configuration to automatic (DHCP).

Open in your web browser to start configuration, there is no password by default, user name: adminhttps://192.168.88.1 (or, for some models, check user and

wireless passwords on the sticker).

To find the device if the IP is not available for example "CRS" models, download Winbox from our webpage and use it to connect through MAC address.

Update RouterOS software to the latest version, make sure that the device has an internet connection.

If the device does not have an internet connection update software by downloading the latest version from our webpage and uploading it to the Winbox, Files

menu, and rebooting the device.

Choose your country, apply country regulation settings and set up your password.

For"RBM11G, RBM33G" models install your desired modem into miniPCIe slot and then connect to the first Ethernet port with MAC Winbox.

To access the Model 260GS, which operates on the SwOS operating system, you need to set your computer's IP address to 192.168.88.2 and use a web

browser.

Safety Information:

Safety Information:Safety Information:

Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing

accidents. The installer should be familiar with network structures, terms, and concepts.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the

Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.

This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own

risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.

Only applicable

Only applicable Only applicable for RB4011iGS+RM,

for RB4011iGS+RM,

for RB4011iGS+RM, for RB4011iGS+RM, CCR1009-7G-1C-PC and

CCR1009-7G-1C-PC and

CCR1009-7G-1C-PC and CCR1009-7G-1C-PC and CRS309-1G-8S+IN devi

CRS309-1G-8S+IN devi

CRS309-1G-8S+IN deviCRS309-1G-8S+IN devices

ces

cesces. This is a Class A product. In a domestic environment, this product

might cause radio interference in which case the user might be required to take adequate measures.

Manufacturer: Mikrotikls SIA, Unijas 2, Riga, Latvia, LV1039.

This device needs to be upgraded to RouterOS v7.10 or the latest version to ensure compliance with local authority regulations! For the CSS-products,

download the latest version of SwitchOS software from https://mikrotik.com/download

It is the end users' responsibility to follow local country regulations. All MikroTik devices must be professionally installed.

Produkt Specifikationer

Mærke:	Mikrotik
Kategori:	bryter
Model:	RB260GS
Bredde:	113 mm
Dybde:	139 mm
Højde:	28 mm
Vægt:	212 g
Produktfarve:	Hvid
Strømforbrug (typisk):	6 W
Driftstemperatur (T-T):	-25 - 65 °C
LED-indikatorer:	Ja
Harmoniseret systemkode (HS):	85176990
Indgangsspænding:	6 - 31 V
Strøm over Ethernet (PoE):	Ja
10G understøttelse:	Ingen
Basis omskiftning RJ-45 Ethernet porte, antal:	5
Basis omskiftning RJ-45 Ethernet porttype:	Gigabit Ethernet (10/100/1000)
MAC adresselabel:	- entries
Switch kapacitet:	- Gbit/sek.
Stativ-montering:	Ingen
Antal SFP modulslots:	1
Strømstik:	DC-in-stik
Power over Ethernet (PoE) porte, antal:	1
