INTRODUCTION
If you experience any difficulty with the
installation or operation of your new
showerhead, please refer to ‘Fault Diagnosis’,
before contacting Kohler Mira Ltd. Our contact
details can be found on the back cover of
this guide.
Introduction
Thank you for purchasing a quality Mira product. To
enjoy the full potential of your new product, please
take time to read this guide thoroughly, having
done so, keep it handy for future reference.
Mira showerheads are designed to give a
satisfactory shower over a range of pressures.
These showerheads are suitable for pressures
between 0.1 and 5.0 bar.
General
1. Installations must comply with Water
Regulations (Bye-Laws, Scotland), and
any other Local Regulations and Building
Re gula tio ns in f o rce a t the ti me of
installation.
2. Before installation carefully inspect the product
for any signs of damage.
Guarantee
For domestic installations, Mira Showers
guarantee the products listed in this guide against
any defect in materials or workmanship for a
period of one year from the date of purchase.
For terms and conditions refer to the back cover
of this guide.
Patents and Design Registration
Patent Applications:
UK: 0715612.8, 0804172.5
World: PCT/GB2008/002703
Design Registration:
Europe: 001004022
FLOW RATES
The ow rates for the Mira 360 showerheads are
listed below.
Spray Pattern Inlet Pressure
0.5 bar
Inlet Pressure
0.1 bar
Rain 12.3 l/min 5.4 l/min
Storm 11.5 l/min 5 l/min
Burst 7 l/min 3.3 l/min
Cloud 4.2 l/min
Cloud LC 2.7 l/min
USER MAINTENANCE
If you require a Mira trained service engineer or
agent, refer to section: ‘Customer Services’.
Fault Diagnosis
Symptom:
Sprayplate assembly blocked.•
Cause / Rectication:
Clean the sprayplate.•
—————————————
Symptom:
Drip from sprayplate assembly.•
Cause / Rectication:
A small amount of water may be retained •
in the showerhead after the shower control
has been turned off. This may drain over
a few minutes. Changing the angle of the
showerhead may vary the draining time.
—————————————
Symptom:
Poor spray pattern from the Cloud sprayplate •
assembly.
Cause / Rectication:
Change the Cloud sprayplate assembly for •
the LC (Low Capacity) version.
Caution! The LC sprayplate must not be used
on electric showers
—————————————
