2
CONTENTS
Introduction 2
Type 2 Valves 2
Guarantee 3
Recommended Usage 3
Patents and Design Registration 3
Safety Warnings 3
Pack Contents 4
Exposed Thermostatic Mixers 4
Built-in Thermostatic Mixers 5
Valve Combinations 6
Specications 7
Installation 9
Suitable Plumbing Systems 9
General 9
Exposed Thermostatic Mixers 10
Adjustable Elbow Installation 13
Flow Regulators 19
Operation 22
Commissioning 23
Maximum Temperature Setting 23
Fault Diagnosis 24
User Maintenance 24
Filter Replacement 24
Lubricants 25
Cleaning 25
Accessories 25
Spare Parts 26
If you experience any difficulty with the
installation or operation of your new
thermostatic mixer, please refer to ‘Fault
Diagnosis’, before contacting Kohler Mira Ltd.
Our contact details can be found on the back
cover of this guide.
INTRODUCTION
Thank you for purchasing a quality Mira product. To
enjoy the full potential of your new product, please
take time to read this guide thoroughly, having
done so, keep it handy for future reference.
The Mira Moto, Mira Minilite and Mira Minilite Eco
are thermostatic mixers with a single control lever
for on/off and temperature control.
The Mira Pace, Mira Pace with Eco Showerhead,
Mira Pace with Adjustable Inlet Elbows, Mira
Miniduo and Mira Miniduo with Eco Showerhead
are thermostatic mixers with separate on/off and
temperature controls.
The thermostatic mixers incorporate a wax
capsule temperature sensing unit, which provides
an almost immediate response to changes in
pressures or temperature of the incoming water
supplies to maintain the selected temperature. An
adjustable maximum temperature stop is provided
which limits the temperature to a safe level.
Inlet lters are tted to protect the thermostatic
cartridge.
Type 2 Valves
These products have been certied as Type 2
valves under the BUILDCERT TMV2 scheme.
They also comply with the Water Supply (water
ttings) Regulations 1999.
For Type 2 Valves refer to the TMV2 Requirements
Manual.
Application
The approved designations for Type 2 Valves
are as follows:
Models Designation
Moto, Minilite LP-S, HP-S, HP-SE
#
#
the economy designation is achieved with the
tting of the outlet ow regulator.
Models Designation
Pace, Miniduo LP-S, HP-S
Important!Thettingofanyowregulatorto
Pace or Miniduo models will invalidate TMV2
compliance due to the minimum ow rate
requirements. Do not t ow regulators in
TMV2 applications to these models.
