Table of Contents
SAFETY INFORMATION 4
FOREWORD 5
THE BASICS 6
How to Use this Manual 6
Setup and Connections 6
Overview and Features 8
Signal Flow 10
Basic Operation 11
THE COMPONENTS 12
A. The Oscillator Section 12
B. The Filter Section 14
C. The Envelope Generators Section 16
D. The Modulation Section 18
E. The Output Section 19
F. Input/Output Panel 20
G. Interface Panel 21
THE USER INTERFACE 23
Preset Mode 23
Master Mode 26
A. Master Mode Menus 26
B. Advanced Preset menus 36
C. SYSEX (System Exclusive) Menus 42
D. System Utilities Menus 45
Performance Sets 50
Activating the Arpeggiator and Latch 52
How the SP handles MIDI 54
APPENDICES 58
Appendix A - LFO Sync Modes 58
Appendix B - Arpeggiator Clock Source 59
Appendix C - The Calibration Preset 60
Appendix D - Accessories 61
Appendix E - Tutorial 62
Appendix F - MIDI Implementation Chart 67
Appendix G - Service and Support Information 68
Appendix H - Caring for the Slim Phatty 68
Appendix I - Using the CP-251 with the Slim Phatty 69
Appendix J - Specifications 71
GLOSSARY 72
SLIM PHATTY PRESETS 76
SAFETY INFORMATION
*** Important Safety Instructions - Please Read ***
WARNING - When using electric products, basic precautions should always be followed, including the
following:
1) Read all the instructions before using the product.
2) Do not use this product near water – for example, near a bathtub, washbowl, kitchen sink, in a wet
basement, or near a swimming pool or the like.
3) This product should be used only with a cart or stand that is recommended by the manufacturer.
4) This product, in combination with an amplifier and headphones or speakers, may be capable of
producing sound levels that could cause permanent hearing loss. Do not operate for a long period of time
at a high volume level or at a level that is uncomfortable. If you experience any hearing loss or ringing in
your ears, you should consult an audiologist.
5) The product should be located so that its location does not interfere with its proper ventilation.
6) The product should be located away from heat sources such as radiators, heat registers, or other products that
produce heat.
7) The product should be connected to a power supply only of the type described in the operating instructions or as
marked on the product.
8) The power supply cord of the product should be unplugged from the outlet when left unused for a
long period of time.
9) Care should be taken so that objects do not fall upon and liquids are not spilled into the keyboard or
front panel.
10) The product should be serviced by qualified personnel when:
a) The power supply cord or the plug has been damaged
b) Objects have fallen, or liquid has been spilled onto the product
c) The product has been exposed to rain
d) The product does not appear to operate normally or exhibits a marked change in performance
e) The product has been dropped or the enclosure damaged.
11) Do not attempt to service the product beyond that described in the user-maintenance instructions.
All other servicing should be referred to qualified service personnel.
DANGER – INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS:
Do not open the chassis. There are no user serviceable parts inside. Refer all servicing to qualified personnel only.
GROUNDING INSTRUCTIONS: T h i s p r o d uc t m u s t b e g r o u n d e d . I f i t s h o u l d m a l f unct i o n o r
breakdown, grounding provides a path of least resistance for electrical current to reduce the risk
of electric shock. This product is equipped with a cord having an equipment grounding connector and
a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
DANGER – Improper connection of the equipment-grounding connector can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in doubt as to whether the product is properly
grounded. Do not modify the plug provided with this product – if it will not fit in the outlet, have a proper outlet
installed by a qualified electrician.
