MOTU 828mkII

User’s Guide for Macintosh

1280 Massachusetts Avenue

Cambridge, MA 02138

Business voice: (617) 576-2760

Business fax: (617) 576-3609

Te chnical support: (617) 576-3066

Te ch support fax: (617) 354-3068

Te ch supp o r t e m a i l : techsupport@motu.com

Web s i te : www.motu.com

!828 Manual/Mac Page 1 Tuesday, May 27, 2003 1:45 PM

SAFETY PRECAUTIONS AND ELECTRICAL REQUIREMENTS

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR OTHER MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

WARNING: DO NOT PERMIT FINGERS TO TOUCH THE TERMINALS OF PLUGS WHEN INSTALLING OR REMOVING THE PLUG TO OR FROM THE OUTLET.

WARNING: IF NOT PROPERLY GROUNDED THE MOTU 828mkII COULD CAUSE AN ELECTRICAL SHOCK.

The MOTU 828mkII is equipped with a three-conductor cord and grounding type plug which has a grounding prong, approved by Underwriters' Laboratories and the Canadian Standards Association.

This plug requires a mating three-conductor grounded type outlet as shown in Figure A below.

If the outlet you are planning to use for the MOTU 828mkII is of the two prong type, DO NOT REMOVE OR ALTER THE GROUNDING PRONG IN ANY MANNER. Use an adapter as shown below

and always connect the grounding lug to a known ground. It is recommended that you have a qualiﬁed electrician replace the TWO prong outlet with a properly grounded THREE prong outlet. An

adapter as illustrated below in Figure B is available for connecting plugs to two-prong receptacles.

WARNING: THE GREEN GROUNDING LUG EXTENDING FROM THE ADAPTER MUST BE CONNECTED TO A PERMANENT GROUND SUCH AS TO A

PROPERLY GROUNDED OUTLET BOX. NOT ALL OUTLET BOXES ARE PROPERLY GROUNDED.

If you are not sure that your outlet box is properly grounded, have it checked by a qualiﬁed electrician. NOTE: The adapter illustrated is for use only if you already have a properly grounded two-prong

receptacle. Adapter is not allowed in Canada by the Canadian Electrical Code. Use only three wire extension cords which have three-prong grounding type plugs and three-prong receptacles which

will accept the MOTU 828mkII plug.

IMPORTANT SAFEGUARDS

1. Read instructions - All the safety and operating instructions should be read before operating the MOTU 828mkII.

2. Retain instructions - The safety instructions and owner's manual should be retained for future reference.

3. Heed Warnings - All warnings on the MOTU 828mkII and in the owner's manual should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Cleaning - Unplug the MOTU 828mkII from the computer before cleaning and use a damp cloth. Do not use liquid or aerosol cleaners.

6. Overloading - Do not overload wall outlets and extension cords as this can result in a risk of ﬁre or electrical shock.

7. Power Sources - This MOTU 828mkII should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your location, consult your local power company.

8. Power-Cord Protection - Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to cords and plugs, convenience receptacles, and

the point where they exit from the MOTU 828mkII.

9. Lightning - For added protection for the MOTU 828mkII during a lightning storm, unplug it from the wall outlet. This will prevent damage to the MOTU 828mkII due to lightning and power line surges.

10. Servicing - Do not attempt to service this MOTU 828mkII yourself as opening or removing covers will expose you to dangerous voltage and other hazards. Refer all servicing to qualiﬁed service personnel.

11. Damage Requiring Service - Unplug the MOTU 828mkII from the computer and refer servicing to qualiﬁed service personnel under the following conditions.

a. When the power supply cord or plug is damaged.

b. If liquid has been spilled or objects have fallen into the MOTU 828mkII.

c. If the MOTU 828mkII has been exposed to rain or water.

d. If the MOTU 828mkII does not operate normally by following the operating instructions in the owner's manual.

e. If the MOTU 828mkII has been dropped or the cabinet has been damaged.

f. When the MOTU 828mkII exhibits a distinct change in performance, this indicates a need for service.

12. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts speciﬁed by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions

may result in ﬁre, electric shock or other hazards.

13. Safety Check - Upon completion of any service or repairs to this MOTU 828mkII, ask the service technician to perform safety checks to determine that the product is in safe operating conditions.

ENVIRONMENT

Operating Temperature: 10°C to 40°C (50°F to 104°)

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE

Do not handle the power cord with wet hands. Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.

INPUT

Line Voltage: 100 - 120 volts AC, RMS (US and Japan) or 220 - 250 volts AC, RMS (Europe). Frequency: 47 - 63 Hz single phase. Power: 7 watts maximum.

CAUTION: DANGER OF EXPLOSION IF BATTERY IS REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BYMANUFAC-

TURER. DISPOSE OF USED BATTERY ACCORDING TO MANUFACTURER’S INSTRUCTIONS.

3-prong plug

Grounding prong

Properly grounded 3-prong outlet

Grounding lug
