CAMERA OVERVIEW

Instructions for A-Series

Digital Game Cameras

THANK YOU for your purchase of your A-Series Digital Game Camera. Please read this booklet before

using the unit. If you should have any questions about this product or any other Moultrie product,

please contact us using the information on the back of this booklet. Please register your camera at

www.moultriefeeders.com/warranty to activate your 2-year warranty.

FRONT VIEW

BOTTOM VIEW

LCD Display

OK Button

Down Button

1/4” 20 Mount

LED Flash

Camera Lens

External Power Port

Motion Sensor

Up Button

Micro USB Port

IMPORTANT INFORMATION

Important Battery lnformation

- Only use Alkaline or Lithium batteries. We recommend the use of Energizer™ batteries.

- Do not mix old and new batteries. Always replace ALL the batteries at the same time.

- When the camera is not in use, please remove the batteries.

Moultrie Limited Warranty

This product has been thoroughly tested and inspected before shipment. It is guaranteed from defects in material

and workmanship from the date of purchase for 2 years. Under this limited guarantee we agree to replace or repair

free of charge any part or parts which have been found to be defective in original material or workmanship. Should

you require in-warranty service, call our Customer Service Department. If your problem cannot be addressed over

the telephone, we may need you to send us your defective product plus proof of purchase.

You must register your camera at www.moultriefeeders.com/warranty to activate your 2-year warranty.

Troubleshooting

Please visit www.moultriefeeders.com/contact-us for troubleshooting and helpful tips.

Returns and Repairs

Please visit http://www.moultriefeeders.com/return-policy and complete the form or our Service Department

will gladly answer any questions you have. Call 800-653-3334, Monday - Friday, 8:00 AM to 5:00 PM CST.

www.moultriefeeders.com

FCC Statements

Note: changes and modiﬁcations not expressly approved by the party responsible could void the user’s authority to operate this device.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

NOTE: This device complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable

protection against harmful interference in a residential installation. This device generates,

uses, and can radiate radio frequency energy

and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference

will not occur in a particular installation. If this device does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

- Reorient or relocate the receiving antenna.

- lncrease the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

02172016 • MCG-13129 • MCG-13130

Moultrie Products, LLC

MCG-13129

A-20

PRADCO Outdoor Brands • 3280 Highway 31, Ste B • Cal era, AL 35040

Status Indicator LED

Page 1

A-Series Digital Game Cameras

Moultrie Products, LLC

MCG-13130

A-20i

Push Button Release for battery compartment

SETUP

OFF SD Card Slot

Light Sensor

Page 7

A-Series Digital Game Cameras

Page 2 A-Series Digital Game Cameras

Mounting with a Strap

Close cover and place camera on a tree or pole

approximately 3 ft. high. Thread the mounting strap

through the mounting strap slots on the back of the

camera and secure.

Hint: If you are mounting camera to cover a trail,

face the camera down the trail tilted at a slight

downward angle.

Face the camera North or South to avoid

over exposure from the sun.

Clear brush away from camera front to

avoid false triggers from the wind.

Battery Installation

Open the camera cover and install 8 AA Alkaline or Lithium batteries. Make sure that the

(+ and -) polarities match the polarities indicated inside the battery chamber.

Note: Anytime you load or unload batteries, make sure that the camera is OFF. If using 12V DC

Power Panel Plug, do not remove internal batteries.

Insert SD Card

You will need to open the front cover to insert an

SD memory card. You can insert a SD Card up to 32 GB.

Insert the SD card in the direction indicated on the card,

until you hear an audible click.

Note: Camera will not operate without an SD memory

card installed.

Power ON

Slide the Switch to the position. Mode ON

The battery level will appear on the LCD Display for

~2 seconds. The camera will then begin to countdown.

Upon reaching 0, the camera will enter capture mode

and display will turn o.

Trail

YES

Trail

Moultrie Mobile® Compatibility

Your camera is compatible with our Moultrie Mobile® cellular

service when combined with the Field Modem MV1.

Please visit www.moultriemobile.com for more information.

NOTE: Camera rmware update may be required

for full Moultrie Mobile functionality.

Using the Moultrie Camera Power Panel

Place near the tree where the camera is mounted. Place for best

exposure to sun. To attach to a tripod secure the power panel

to the tripod angled upward for best exposure. Plug the power

panel to the Power Panel Plug. This will extend the life of your

camera in the ﬁeld.

Note: Leave internal batteries in the camera during use.

The Camera Power Panel needs 4 hours of sunlight to fully

power the camera.

Using the Moultrie Battery Box

Extend the eld life of your Moultrie camera with a

long-lasting, rechargeable external power source.

Place near the tree where the camera is mounted.

Plug the Battery Box to the Power Panel Plug.

This will extend the life of your camera in the ﬁeld.

MOULTRIE ACCESSORIES (Sold Separately)

QUICK START INSTRUCTIONS
