Instructions for S-Series Digital Game Cameras
THANK YOU for your purchase of an S-Series Digital Game Camera. Please read this booklet before using the unit. If you should
have any questions about this product or any other Moultrie product, please contact us using the information on the back of
this booklet. Please register your camera at to activate your warranty. www.moultriefeeders.com/warranty
Status Indicator
Infrared LED Flash
Menu Button
Navigation Buttons
SD Card Slot
Camera Lens
TFT Display
Mode Selector Switch
Motion Sensor
Release for
Battery Compartment
www.moultriefeeders.com
FCC Statements
Moultrie Products
MCG-13183
Note: changes and modifications not expressly approved by the party responsible could void the user’s authority to operate this device.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
NOTE: This device complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This device generates,
uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- lncrease the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
10242016 / MCG-13183
S-50i
PRADCO Outdoor Brands • 3280 Highway 31, Ste B • Calera, AL 35040
Light Sensor
Micro USB Port
External Power Port
Important Battery lnformation
- Only use Alkaline or Lithium batteries. We recommend the use of Energizer batteries.
- Do not mix old and new batteries. Always replace ALL the batteries at the same time.
- When the camera is not in use, please remove the batteries.
Moultrie Limited Warranty
This product has been thoroughly tested and inspected before shipment. It is guaranteed from defects in material and workmanship from the
date of purchase for 2 years. Under this limited guarantee we agree to replace or repair free of charge any part or parts which have been found to
be defective in original material or workmanship. Should you require in-warranty service, call our Customer Service Department. If your problem
cannot be addressed over the telephone, we may need you to send us your defective product plus proof of purchase.
You must register your camera at to activate your 2-year warranty. www.moultriefeeders.com/warranty
Troubleshooting
Please visit www.moultriefeeders.com/contact-us for troubleshooting and helpful tips.
Returns and Repairs
Please visit http://www.moultriefeeders.com/return-policy and complete the form or our Service Department will gladly answer any questions
you have. Call 800-653-3334, Monday - Friday, 8:00 AM to 5:00 PM CST.
MOULTRIE MOBILE® COMPATIBILITY
Your camera is compatible with our Moultrie Mobile® cellular service when combined with the Field Modem MV1. Please visit www.moultriemobile.com
for more information.
MOULTRIE S-SERIES
2 15
MAIN MENU
TIMELAPSE
MOTION + TL
GENERAL SETTINGS
DETECTION DELAY
PIR SENSITIVITY
MULTI-SHOT
PHOTO OR VIDEO
RESET OPTIONS
TL INTERVAL
TL PROGRAM #1
TL PROGRAM #2
RESET OPTIONS
PHOTO/VIDEO
SETTINGS
INFOSTRIP SETTINGS
MEMORY SETTINGS
SYSTEM SETTINGS
MOTION DETECT
MENU MAP
314
SYSTEM OPTIONS (cont.)
J
Upgrade Firmware
The firmware version is displayed.
YES - To upgrade rmware.
NO - Keep current firmware.
NOTE: This operation should only be performed when rmware update is required.
Conrm Security Code
Once a Security Code has been entered, the camera will prompt you to verify the code.
This will keep you from mis-entering a code or seting a code inadvertantly.
Reset to Default settings
You can reset your camera to the factory default settings.
Choose either - keep custom settings.YES - all setups restored to factory default or NO
SYSTEM SETTINGS
CONFIRM SECURITY CODE
00000
SYSTEM SETTINGS
FACTORY RESET
X Do Not Reset
Factory Reset
SYSTEM SETTINGS
UPGRADE FIRMWARE
X No
Yes
50S50i-140919
INFOSTRIP SETTINGS
MEMORY SETTINGS
SYSTEM SETTINGS
DATE & TIME
CAMERA NAME
TEMPERATURE F/C
INFOSTRIP ACTIVE
ERASE ALL IMAGES
SECURITY CODE
FACTORY RESET
UPGRADE
FIRMWARE
MOTION FREEZE
PHOTO RESOLUTION
VIDEO RESOLUTION
VIDEO LENGTH
GENERAL SETTINGS
MANAGED
MEMORY
PHOTO/VIDEO
SETTINGS
MODE SWITCH
Aim - When Aim is ON and the PIR Motion Sensor detects motion, the Status Indicator’s red LED on the front of the camera will come on and remain lit
as long as motion is detected. Additionally, a live view from the camera will be displayed on screen to show the area that will be captured in photos
or videos. - set and run camera with custom settings. Custom Start Quick Start - set and run camera with pre-dened settings. Playback - view
recorded photos or videos on the camera’s TFT screen.
NAVIGATION BUTTONS
The Menu Button selects Camera Setup or Main Screen. When camera mode is selected, the LEFT and RIGHT buttons navigate through the menu
options. The Menu Button is also used to wake-up the camera and turn on the display when the camera is in power saving (or sleep) mode. The
OK button selects the item to be changed. The UP/DOWN and LEFT/RIGHT buttons are used to step through and modify the menu options. Pressing
the OK button again, selects the option indicated on the display. The OK button is also used to manually take a picture.
BATTERY COMPARTMENT
The camera is powered by twelve (12) AA alkaline or lithium batteries. Push the battery compartment release button to eject the battery tray.
Install batteries as indicated on the engravings on the battery tray, taking care to note the correct polarity. See Important Battery Information
section on Page 15 of this manual.
SD CARD SLOT
Accepts up to a 32GB SD Card (Class 4 or higher) for photo and video storage. A Class 4 or higher SD Card must be installed for the camera to NOTE:
operate (sold separately). Ultra/turbo SD cards are not recommended.
USB PORT
Download still pictures and video onto your computer by connecting a micro-B to USB cable (not included) to the USB port.
EXTERNAL POWER PORT
Accepts the Moultrie power accessories (sold separately) only. Refer to www.moultriefeeders.com for more information.
NOTE: The use of any other power source will void your warranty and possibly harm your camera.
CAMERA OVERVIEW
A
4 13
SYSTEM OPTIONS
J
Security Code
Select a 5 digit security code for your camera.
NOTE: Please remember your security code. If the code is lost, you can contact Moultrie
customer support to reset the password (charges may apply). Also, use caution when navigating
through the Security Code option as not to set a code by mistake. For no Security Code, the
setting should remain as “00000”.
MEMORY OPTIONS
I
Erase Images
Choose between Yes - erase all images, or - does not change stored images. No
NOTE: This will also format your SD card for use in your camera.
Managed Memory
Selecting the OVERWRITE OLDEST option will cause the oldest les to be overwritten with
new captures when the SD card reaches its capacity. With the DO NOT OVERWRITE option
selected, the camera will cease image capture once the SD card reaches capacity.
MEMORY SETTINGS
ERASE ALL IMAGES
X No
Yes
NOTE:
Erasing images will also
format SD card
MEMORY SETTINGS
MANAGED MEMORY
X Do Not Overwrite
Overwrite Oldest
SYSTEM SETTINGS
SECURITY CODE
00000
QUICK START INSTRUCTIONS
B
Use the steps below as a guide to quickly set up your camera so it will function using the factory default settings.
STEP 1
Open camera cover. Install twelve (12) AA size alkaline or lithium batteries with polarities as indicated in the Battery Tray. Insert your SD card. We
recommend that you erase the SD card (ERASE IMAGES) inside the camera before taking pictures: this will not only erase all images, but will also
format your SD card for use in the camera. Camera will not operate without SD card. Switch camera to Quick Start.
STEP 2
Mount camera in desired location using a mounting strap. The camera also has two Python™
Cable Loops for added security. NOTE: Camera must be attached to a stable object for
motion detection to function properly. Mounting camera on an unstable structure may
result in excess image captures with no subject (false triggers).
STEP 4
Close cover. The camera will operate using Default settings. You may also
customize the settings if desired in Custom Start.
STEP 3
Switch camera to Aim. Aim camera using motion detection to determine target area.
Walk in front of the camera at the desired distance and the camera LED will ash,
showing the covered area which can be seen using Live View on the TFT screen.
Eyelet
Mounting
Strap
512
Setting Run Mode
When you choose Quick Start, the only settings
that you will be able to change will be Date and
Time, allowing for rapid setup. Other settings are:
OPTION SETTING
Mode Motion Detect
Detection Delay 30 seconds
Multi-Shot 3-Triggered
Photo or Video Photo
SETTING PHOTO/VIDEO OPTIONS (cont.)
H
Setting Video Length
Choose between 5 video length settings (5, 10, 30, 60 or 90 seconds).
NOTE: Night videos are limited to a maximum of 30 seconds.
Setting Motion Freeze
This feature maximizes the image clarity during night photos. When this feature is on the
camera will adjust the exposure time to reduce blur associated with motion. Other
adjustments are made to increase the brightness and clarity of the photo. When this
feature is turned o the camera will use a maximum exposure time that will not reduce
blur, but will increase the eective ash range and image brightness of night photos.
Setting Video Quality
Choose between 2 image quality settings:
1. HD: 1280 x 720
2. FULL HD: 1920 x 1080
PHOTO/VIDEO SETTINGS
MOTION FREEZE
X On (Fast Flash)
O (Max. Flash)
NOTE: On (Fast Flash) reduces
image blur, but also reduces
ash range.
PHOTO/VIDEO SETTINGS
VIDEO RESOLUTION
HD (1280 x 720)
X FHD (1920 x 1080)
VIDEO LENGTH
90 seconds
60 seconds
30 seconds
X 10 seconds
5 seconds
PHOTO/VIDEO SETTINGS
Python™ Cable
Loops
CAPTURE MODES
C
Setting Capture Mode
Use the buttons to choose between operating modes. This camera has 3 modes.Up/Down
1. Motion Detect - Capture photo or video when motion or heat is detected.
2. Time Lapse - Capture photo at periodic intervals based on the Time Lapse program setting.
3. Motion + Time Lapse - Uses a combination of Time Lapse and Motion Detect modes at dierent times
of the day. Press the button to move to start motion capture.Right
NOTE: Options for Motion and Time Lapse can be set in their respective option menus.
SETTING MOTION DETECT OPTIONS
D
Setup Selection Setting
From the Default Screen, pressing the Menu button will enter the current capture mode’s Main Screen. Press the Down button 3 times to enter
GENERAL SETTINGS. Press the Left button to move to the next setting. Using this method you can customize your camera’s feature settings.
From this Main Screen, press OK to get to the Test Capture screen. See pages 1 & 2 for the full layout of the camera menu.
For all menu navigation, use UP/DOWN to change and LEFT/RIGHT to navigate between options and OK to lock-in your selection.
6 11
IMAGE REVIEW SOFTWARE INSTALLATION
Download your free Image Review software at www.moultriefeeders.com/imagesoftware
For PC users: Installation and operation instructions are available here, as well.
For Mac users: This software is not Mac-compatible. You can import your image les into a program such as iMovie and iPhoto.
SETTING PHOTO/VIDEO OPTIONS
H
Setting Photo Quality
Choose between 4 image resolution settings:
1. Enhanced: 6080 x 3420
2. High: 4224 x 2376
3. Medium: 2688 x 1512
4. Low: 1920 x 1080
Setting Camera Name
Select an identity for your camera. For example, you can use a name or a location;
the identity you wish to use is up to you.
INFOSTRIP SETTINGS
CAMERA NAME
M O U L T R I E C A M
Temperature
The temperature is imprinted on each photo and can be in degrees Fahrenheit or Celsius.
INFOSTRIP SETTINGS
TEMPERATURE UNITS
X Fahrenheit (F)
Celsius (C)
PHOTO/VIDEO SETTINGS
PHOTO RESOLUTION
Low (2MP)
Medium (4MP)
X High (10MP)
Enhanced (20MP)
Produkt Specifikationer
| Mærke: | Moultrie |
| Kategori: | Kamera |
| Model: | S-50i |
Har du brug for hjælp?
Hvis du har brug for hjælp til Moultrie S-50i stil et spørgsmål nedenfor, og andre brugere vil svare dig
Kamera Moultrie Manualer
5 September 2024
5 September 2024
5 September 2024
5 September 2024
5 September 2024
5 September 2024
5 September 2024
5 September 2024
5 September 2024
5 September 2024
Kamera Manualer
- Kamera Getac
- Kamera Laserliner
- Kamera Minox
- Kamera IOptron
- Kamera Logitech
- Kamera ZeissIkon
- Kamera Ring
- Kamera Velleman
- Kamera Technaxx
- Kamera Cobra
- Kamera Sygonix
- Kamera Spypoint
- Kamera Berger & Schröter
- Kamera Braun
- Kamera PTZ Optics
Nyeste Kamera Manualer
29 Marts 2025
29 Marts 2025
27 Marts 2025
12 Marts 2025
12 Marts 2025
14 Januar 2025
13 Januar 2025
12 Januar 2025
11 Januar 2025
11 Januar 2025
