www.moxa.com

AWK-1137C Series

Industrial 802.11a/b/g/n wireless client

Features and Benefits

• IEEE 802.11a/b/g/n compliant client

• Comprehensive interfaces with one serial port and two Ethernet LAN ports

• Millisecond-level Client-based Turbo Roaming

• Easy setup and deployment with AeroMag

• 2x2 MIMO future-proof technology

• Easy network setup with Network Address Translation (NAT)

• Integrated robust antenna and power isolation

• Anti-vibration design

• Compact size for your industrial applications

Certifications

Introduction

The AWK-1137C is an ideal client solution for industrial wireless mobile applications. It enables WLAN connections for both Ethernet and serial

devices, and is compliant with industrial standards and approvals covering operating temperature, power input voltage, surge, ESD, and vibration.

The AWK-1137C can operate on either the 2.4 or 5 GHz bands, and is backwards-compatible with existing 802.11a/b/g deployments to future-

proof your wireless investments. The Wireless add-on for the MXview network management utility visualizes the AWK's invisible wireless

connections to ensure wall-to-wall Wi-Fi connectivity.

Industrial Ruggedness

• Integrated antenna and power isolation designed to provide 500 V insulation protection against external electrical interference

• -40 to 75°C wide operating temperature models (-T) available for smooth wireless communication in harsh environments

Mobility-oriented Design

• Client-based Turbo Roaming

for < 150 ms roaming recovery time between APs

• MIMO technology to ensure transmitting and receiving capability while on the move

• Anti-vibration performance (with reference to IEC 60068-2-6)

Easy Integration

• Semi-automatically configurable to reduce deployment cost

• AeroMag support for error-free setup of your industrial applications’ basic WLAN settings

• Various communication interfaces for connecting to different types of devices

• One-to-many NAT to simplify your machine setup

Wireless Network Management With MXview Wireless

• Dynamic topology view shows the status of wireless links and connection changes at a glance

• Visual, interactive roaming playback function to review the roaming history of clients

• Detailed device information and performance indicator charts for individual AP and client devices

1. The Turbo Roaming recovery time indicated herein is an average of test results documented, in optimized conditions, across APs configured with interference-free

20-MHz RF channels, WPA2-PSK security, and default Turbo Roaming parameters. The clients are configured with 3-channel roaming at 100 Kbps traffic load.

Other conditions may also impact roaming performance. For more information about Turbo Roaming parameter settings, refer to the product manual.

Produkt Specifikationer

Mærke:	Moxa
Kategori:	Adgangspunkt
Model:	AWK-1137C-US
Kode for international beskyttelse (IP):	IP30
Vekselstrømsindgangsspænding:	9 - 30 V
Bredde:	77.1 mm
Dybde:	115.5 mm
Højde:	26 mm
Vægt:	407 g
Produktfarve:	Sort
Opbevaringstemperatur (T-T):	-40 - 85 °C
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Ethernet LAN-porte (RJ-45):	2
Driftstemperatur (T-T):	0 - 60 °C
Ethernet LAN-datahastigheder:	10, 100 Mbit/s
Sikkerhedsalgoritmer:	AES, HTTPS, SSH, SSL/TLS, WPA-TKIP
Husmateriale:	Metal
Hurtig start guide:	Ja
Pakketype:	Kasse
Frekvensområde:	20 MHz
Certificering:	EMC, EMI, EMS
Strømforbrug (maks.):	11.7 W
Placering:	Væg
Kabelteknologi:	10/100/1000Base-T(X)
Netværksstandarder:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Modtager, følsomhed:	Typ. -90 @ 6 Mbps\nTyp. -88 @ 9 Mbps\nTyp. -87 @ 12 Mbps\nTyp. -85 @ 18 Mbps\nTyp. -81 @ 24 Mbps\nTyp. -78 @ 36 Mbps\nTyp. -74 @ 48 Mbps\nTyp. -73 @ 54 Mbps
DC-in-stik:	Ja
DHCP-klient:	Ja
DHCP-server:	Ja
Antenner, antal:	2
Knap til nulstilling:	Ja
IP-adresse filtrering:	Ja
LED-indikatorer:	Fault, LAN, Link, Power, Status, WAN
Frekvensbånd:	2.412 - 5.700 GHz
Maksimal dataoverførselshastighed:	300 Mbit/s
Antenne type:	Ekstern
Strøm over Ethernet (PoE):	Ingen
Monteringssæt:	Ja
Antal kanaler:	13 kanaler
MIMO:	Ja
VLAN understøttelse:	Ja
Filtrering af MAC-adresser:	Ja
Administrationsprotokoller:	DHCP Server/Client, HTTP, IPv4, LLDP, SMTP, SNMPv1/v2c/v3, Syslog, TCP/IP, Telnet, UDP, Proxy ARP, VLAN, Wireless Search Utility, MXview, MXview Wireless, MXconfig
2.4 GHz:	Ja
5 GHz:	Ja
Antennefunktioner:	Aftagelig antenne
Niveau for antennestyrke (maks.):	2 dBi
Maksimal dataoverførselshastighed (5 GHz):	- Mbit/s
Maksimal dataoverførselshastighed (2,4 GHz):	54 Mbit/s
Remote Authentication Dial-In User Service (RADIUS):	Ja
Syslog:	Ja
MIMO type:	Multi User MIMO
Transmissionseffekt:	23 dBmW
Antenneretningstype:	Omniretningsbestemt
RS-232 grænseflade:	Ja
Antal forbindelser:	2
Antennestik type:	RP-SMA
Spread-spectrum-metode:	DSSS, OFDM
6 GHz:	Ingen
