Side 1/149

<變數 1> Contents

Contents

Safety Information ........................................................................................... 2

Specifications ...................................................................................................3

Rear I/O Panel .................................................................................................6

LAN Port LED Status Table .................................................................................6

Overview of Components ................................................................................7

CPU Socket .........................................................................................................8

DIMM Slots ..........................................................................................................9

PCI_E1~3: PCIe Expansion Slots ........................................................................9

JFP1, JFP2: Front Panel Connectors ...............................................................10

SATA1~4: SATA 6Gb/s Connectors....................................................................10

ATX_PWR1, CPU_PWR1: Power Connectors....................................................11

JAUD1: Front Audio Connector ......................................................................... 11

JUSB1: USB 2.0 Connector ...............................................................................12

JUSB2: USB 3.1 Gen1 Connector .....................................................................12

JTPM1: TPM Module Connector .......................................................................13

JCOM1: Serial Port Connector .........................................................................13

EZ Debug LED ...................................................................................................13

CPU_FAN1, SYS_FAN1: Fan Connectors ..........................................................14

JBAT1: Clear CMOS (Reset BIOS) Jumper .......................................................15

JCI1: Chassis Intrusion Connector ...................................................................15

BIOS Setup ..................................................................................................... 16

Entering BIOS Setup .........................................................................................16

Resetting BIOS ..................................................................................................17

Updating BIOS ...................................................................................................17

Software Description .....................................................................................18

Installing Windows

10 .....................................................................................18

Installing Drivers ..............................................................................................18

Installing Utilities ..............................................................................................18

Thank you for purchasing the MSI

H310M PRO-VL PLUS/

H310M PRO-VLH PLUS motherboard. This User Guide gives

information about board layout, component overview, BIOS

setup and software installation.

Safety Information

y The components included in this package are prone to damage from electrostatic

discharge (ESD). Please adhere to the following instructions to ensure successful

computer assembly.

y Ensure that all components are securely connected. Loose connections may cause

the computer to not recognize a component or fail to start.

y Hold the motherboard by the edges to avoid touching sensitive components.

y It is recommended to wear an electrostatic discharge (ESD) wrist strap when

handling the motherboard to prevent electrostatic damage. If an ESD wrist strap is

not available, discharge yourself of static electricity by touching another metal object

before handling the motherboard.

y Store the motherboard in an electrostatic shielding container or on an anti-static

pad whenever the motherboard is not installed.

y Before turning on the computer, ensure that there are no loose screws or metal

components on the motherboard or anywhere within the computer case.

y Do not boot the computer before installation is completed. This could cause

permanent damage to the components as well as injury to the user.

y If you need help during any installation step, please consult a certified computer

technician.

y Always turn off the power supply and unplug the power cord from the power outlet

before installing or removing any computer component.

y Keep this user guide for future reference.

y Keep this motherboard away from humidity.

y Make sure that your electrical outlet provides the same voltage as is indicated on

the PSU, before connecting the PSU to the electrical outlet.

y Place the power cord such a way that people can not step on it. Do not place

anything over the power cord.

y All cautions and warnings on the motherboard should be noted.

y If any of the following situations arises, get the motherboard checked by service

personnel:

 Liquid has penetrated into the computer.

 The motherboard has been exposed to moisture.

 The motherboard does not work well or you can not get it work according to

user guide.

 The motherboard has been dropped and damaged.

 The motherboard has obvious sign of breakage.

y Do not leave this motherboard in an environment above 60°C (140°F), it may

damage the motherboard.

Produkt Specifikationer

Mærke:	MSI
Kategori:	Bundkort
Model:	H310M Pro-VLH Plus
Wi-Fi:	Ingen
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	4
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Ethernet LAN:	Ja
Lyd-output kanaler:	7.1 kanaler
Maksimal intern hukommelse:	32 GB
Understøttede Windows-operativsystemer:	Windows 10 x64
Processorproducent:	Intel
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	Gigabit Ethernet
Komponent til:	PC
Antal serielle porte:	1
Processor sokkel:	LGA 1151 (stik H4)
DirectX-version:	12.0
Kompatibel processor serie:	Intel® Core™ i9
Bundkort chipset familie:	Intel
Bundkort chipsæt:	Intel® H310
Lydchip:	Realtek ALC887
Understøttede hukommelsestyper:	DDR4-SDRAM
Antal hukommelsesstik:	2
Hukommelses slots type:	DIMM
Antal SATA III-stik:	4
LAN Kontroller:	Realtek RTL8111H
Hukommelseskanaler:	To-kanals
USB 2.0-stik:	2
USB 3.2 Gen 1 (3.1 Gen 1) stik:	2
Motherboard form faktor:	micro ATX
Understøttede lagerdrev brugerflader:	SATA III
PCI Ekspres x1 slots:	2
Antal parallelle porte:	1
PCI Ekspres x16 (Gen 3.x) slots:	1
TPM-stik:	Ja
Seriel port overskrifter:	1
Understøttet hukommelsesur hastighed (maks.):	2666 MHz
