Specifications
Environment HDMI 1.3a (Supports the 3D feature of HDMI 1.4)
Devices DVD, plasma, projectors, monitors, TV, PC, laptops, servers
supporting HDMI.
Transmission Supports 1x1 point-to-point and up to 1x4 point-to-multipoint.
Transparent to the
user.
Bandwidth
MHz
Signals
HDMI 1.3a protocol
, HDCP
Connectors
Note: HDMI cables not
included.
Two (2) HDMI receptacle (for TX unit).
One (1) HDMI receptacle (for RX unit).
One (1) 3.5mm jack for IR sensor (for RX unit).
One (1) 2.5mm jack for IR emitter (for TX unit).
On
e (1) Mini USB Power Connector.
Switch
Push button for pairing
.
Latency
Less than 500msec
Compression
H.264
Bandwidth
Up to 15Mbps
Maximum Distance
Based on a maximum length
of 6.6ft (2m) of HDMI cable
per end.
Wireless transmission up to 100ft (30m) maximum, with line of sight
between TX & RX, at up to 1080p. Transmission through walls is
possible with reduced distance performance depending on wall
construction. For best performance avoid high density walls, such as
concrete and metal walls, as they may not allow the signal to be
transmitted through them, and place the TX & RX away from other
interfering
wireless
devices
.
IR Frequency
Wideband 3
0
KHz to
60
KHz
Power Supply One (1) 110-240V to 5VDC, 1A Micro USB power supply with
interchangeable blades
per HDMI Wireless Extender unit.
Power Consumption
Transmitter:
4.5
Watt
(Max)
Receiver:
3.5
Watt
(Max)
Temperature Operating: 0° to 40°C Storage: -20° to 85°C
Humidity: Up to 95% non
-
condensing
Enclosure
Plastic
D
imensions
3.3” x 3.3” x 0.5” (84
mm
x 84
mm x 13
m
m)
Weight
1
lb
s (0.45
kg)
Compliance
Regulatory: FCC, CE, RoHS
Flammability: 94V0
Warranty
1
year
Order Information
100503
HDMI Wireless Extender Kit
HDMI Wireless Extender Kit
100503
Quick Installation Guide
Overview
The HDMI Wireless Extender Kit (100503) allows HDMI equipment to be connected wirelessly up
to 100ft (30m) maximum, with line of sight between TX & RX, at up to 1080p in a point-to-point
configuration. In addition up to four Receivers may be paired with one Transmitter for point-to-
multipoint applications (Receivers may be purchased separately). Transmission through walls is
possible with reduced distance performance depending on wall construction. The Transmitter and
Receiver form a private wireless network between both units, and do not require a customer’s
router based wireless network to operate. The kit comes with one (1) Transmitter and one (1)
Receiver as well as an IR Emitter and an IR Sensor for remote control applications.
Applications
Applications include commercial and residential AV systems, classroom projector systems, digital
signage, boardroom systems, collaborative PC systems, Home Theatre, Showroom, and hard to
reach locations.
Installation
1. Identify the connectors on the Transmitter and Receiver as indicated on the product labels,
refer to the product diagram above.
2. Verify that the distance between the Transmitter and Receiver is within MuxLab
specifications (see Specifications table for more details). The Transmitter and Receiver form
a private wireless network between both units, and do not require a customer’s router based
wireless network to operate. Up to four Receivers may be paired with one Transmitter. Note:
The distance specification is for line of sight between TX & RX. Transmission through
walls is possible with reduced distance performance depending on wall construction.
For best performance avoid high density walls, such as concrete and metal walls, as they
may not allow the signal to be transmitted through them, and place the TX & RX away
from other interfering wireless devices.
3. To install the Transmitter:
3a. Connect the Transmitter HDMI-IN port to the HDMI video source with an HDMI
compliant cable.
3b. Connect the Transmitter HDMI-OUT port to the local HDMI display equipment
(optional) with an HDMI compliant cable.
4. To install the Receiver:
3a. Connect the Receiver HDMI-OUT port to the HDMI display equipment with an
© MuxLab Inc. 2019
HDMI compliant cable.
5. Connect the 5 VDC power supply to the Receiver first, and then plug the power supply
into an AC power outlet. Next connect the 5 VDC power supply to the Transmitter, and
then plug the power supply into an AC power outlet. If power is present, the red power
LED of the Transmitter and the Receiver will be illuminated.
Note: Power the HDMI Wireless Extender only after all connections are made.
6. Power the HDMI equipment, and pair the Transmitter and Receiver:
6a. Press the “Pair” button of the Receiver. You will see the message “Connecting through
Pairing…” on the screen.
6b. Press the “Pair” button of the Transmitter. You will see the message “Connecting…”
and then “Connected…”. The connection is now made.
6c. Verify the image quality.
7. This product supports unidirectional IR control. If infrared remote control is needed to control
the Source equipment from the Display, connect the IR Sensor to the 3.5mm Stereo Jack of
the Receiver and the IR Emitter to the 2.5mm Mono Jack of the Transmitter.
Note: You can differentiate the IR Sensor and the IR Emitter by looking at the 3.5mm and
2.5mm plugs. The IR Sensor is using a 3.5mm Stereo Plug (3 Contacts) and the IR
Emitter a 2.5mm mono plug (2 Contacts).
8. Position the IR Sensor so that it is directed to the hand-held remote control. For a clear IR
signal reception, aim the hand-held remote control at the top of the IR Sensor enclosure.
9. Position the IR Emitter as close as possible to the source’s IR Sensor (i.e. DVD player). For a
clear IR signal reception, the IR Emitter can be glued on the source’s IR Sensor. The IR
Emitter’s signal is transmitted from the side of the enclosure.
10. Do not cover the TX or the RX devices as not to block air circulation.
11. The following diagram shows the final configuration.
Troubleshooting
The following table describes some of the symptoms, probable causes and possible solutions in regard to
the installation of the HDMI Wireless Extender Kit:
Symptom TX
LED
RX
LED
Probable
Cause
Possible
Solutions
No Image
OFF
OFF
No power
•
Check power connections
No Image
ON
OFF
No
power
•
Check RX power c
onnection
No Image
OFF
ON
No power
•
Check TX power connection
No Image ON ON Wireless interference • Move the TX and RX devices away
from the wireless source
.
Symptom TX
LED
RX
LED
Probable
Cause
Possible
Solutions
No Image
ON
ON
HDMI Cable
•
Check the HDMI Cable.
No Image
ON
ON
Syn
chronization
•
Check dis
tance between TX and RX.
Flickering
ON ON Synchronization • Check distance between TX and RX.
• Check the HDMI Cable Quality.
• Change the position of TX and/or RX to
get
a
better reception
.
No Sound
ON
ON
Display not proper
ly
set.
•
Adjust
display
volume
.
Choppy sound ON ON Synchronization • Check distance between TX and RX.
•
Check the HDMI Cable Quality.
Green or pink
hue
ON ON DDC communication • Cycle power of the HDMI Extenders.
•
Check distance between TX and RX.
Image flickers
when powering
up nearby
equipment
ON ON Interference • Move the TX and RX devices away
from the interfering source.
IR not
functioning
ON ON Remote control not
directed to the IR Sensor
or IR Emitter not
directed to the source.
• Make sure the IR Sensor is directed
towards the remote and the IR Emitter
to the source equipment.
IR not
functioning
ON ON Interference from
sunlight, Fluorescent,
Neon or Halogen lights
.
• Place the IR equipment away for the
interfering light source.
IR not
functi
oning
ON ON Interference from RF
radiation from the TV
• Place the IR equipment away for the
RF radiation
.
If you still cannot diagnose the problem, please call MuxLab Customer Technical Support at 877-689-
5228 (toll-free in North America) or (+1) 514-905-0588 (International).
Statements
FCC and Industry Canada:
This device complies with FCC Part 15 and Industry Canada license exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement
Industry Canada:
This device complies with Health Canada’s Safety Code. The installer of this device should ensure
that RF radiation is not emitted in excess of the Health Canada’s requirement.
Cet appareil est conforme avec Santé Canada Code de sécurité 6. L’installateur de cet appareil doit
s’assurer que les rayonnements RF ne sont pas émis au-delà de l’exigence de Santé Canada.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Les changements ou modifications non expressément approuvés par la partie responsable de la
conformité pourraient annuler l'autorité de l'utilisateur à utiliser cet équipement.
