HM-10 Headmic™

Element: Back electret condenser

Polar pattern: Omni-directional

Frequency Response: 20Hz~20KHz

Sensitivity: -42±3dB

Output impedance: 1KO±5%

SPL max: 130dB

Power Supply: 1.5-10V D.C.

Cable: 1.5mm

Wiring: GND = Pin 1, Hot (+) = Pin 3 ➾ 2KΩ➾

Pin 2

Weight: 1.65 oz. (23g)

Mic Dimension: .197” (5 mm)

Output connector: 3pin mini XLR connector

Congratulations on purchasing the NADY HM-10 ultra small condenser headset

microphone. Optimally designed for singing and speech applications, the HM-10’s small

size and light weight make it ideal for all hands-free use with minimum visibility. Perfect for

singers/musicians (drummers, keyboardists), vocal/dance performers, DJ’s,

television announcers, public speakers, and aerobics instructors.

STANDARD ITEMS SUPPLIED

• HM-10 headmic with small foam windscreen

• Additional medium and large foam windscreens

• Extra boom assembly

• User guide

• Warranty card

OPTIONAL ACCESSORIES

• XM-10

—

Mini-XLR to XLR phantom power adaptor (converts 48V phantom

power to 5V-10V DC)

• HM-CC1 — Plastic headmic carrying case

FEATURES

• Wide bandwidth, omni-directional electret condenser mic ensures clean transparent audio

and enhanced vocal pickup with improved gain before feedback

• Durable, thin metal frame can be easily molded to any user

• Ergonomic design and comfortable fit with or without glasses, hats, or headphones (also

no hairstyle hindrance)

• Tiny capsule with diameter of 5.0 mm for lightest weight and hours of comfortable use

• Three sizes of foam windscreen included to reduce wind and popping noise

• Extendable boom fully adjustable 100 degrees for optimum mic capsule

placement

• Available with Mini-XLR or 3.5mm phono plug for wired and wireless applications (fits

most standard wireless bodypack transmitters)

• Choice of black or beige color

• Low voltage Phantom Power required

USE & CARE

The headset’s arch-shaped rests are placed over each ear and the remainder of the band

extends around the back of the head just above the neck. The tip of the supporting arches

rests on the temple just in front of the ear providing the necessary stability during use. The

mic boom descends from the ear on the left side.

Carefully loosen the boom by unscrewing the assembly one-quarter turn. Place the

microphone capsule close to the mouth to a favorable audio position. Tighten the boom

assembly. Bend the boom and headset slightly for optimum fit.

Connect the Mini-XLR or 3.5mm phono plug of the microphone cable to the input jack of

the bodypack transmitter or power supply adaptor. When using a power supply adaptor,

connect it to the microphone input of an audio preamp that provides phantom power.

The entire HM-10 assembly has been moisture-proofed to guard against deterioration

during use. After use in a high moisture application such as aerobics or a stage

performance, remove the foam screen, wipe the headset with a dry soft cloth and permit it

to air-dry. Do not store the unit in a closed space (e.g., a plastic bag) until all moisture has

evaporated, and avoid conditions of extremely high humidity. This will help maintain the

HM-10’s excellent performance. While the HM-10 is not unusually sensitive to the outside

environment, extremes in temperature can be harmful. Avoid, for example, leaving the

microphone in direct sunlight for long periods of time.

USER

GUIDE

NADY SYSTEMS, Inc.

6701 Shellmound Street

Emeryville, California 94608

Phone: 510.652.2411 • Fax: 510.652.5075

www.nady.com

20 50 100 500

-20

-10

+20

+10

1k 10k 20k

Frequency in Hz

Relative Response in dB

Specifications and design subject to change for

improvement purposes without prior notice.

SERVICE FOR YOUR NADY AUDIO PRODUCT

(U.S.) Should your NADY AUDIO product require service, please contact the Nady

Service Department via telephone at (510) 652-2411, or e-mail to service@nady.com.

(International) For service, please contact the NADY AUDIO distributor in your country

through the dealer from whom you purchased this product.

FREQUENCY RESPONSE &

POLAR PATTERN

SPECIFICATIONS
