Thanks for purchasing the Nady OHCM-200 Overhead Hang-

ing Condenser Microphone! This microphone is a wide-range

back electret condenser with a cardioid polar pattern. It is very

useful in a variety of overhead hanging mic applications such

as high quality sound reinforcement, professional record-

ing, and many other demanding sound pickup situations. The

microphone is designed to be powered by an external 9-52 V

DC phantom power supply and is enclosed in a rugged die cast

case for long-term reliability.

UNPACKING, INSPECTION, STORAGE AND TRANSPORT

Your OHCM-200 microphone was carefully packed at the fac-

tory, and the shipping carton was designed to protect the unit

during shipping. Please examine your microphone before using

and retain the external shipping package for reuse should you

ever need to return your microphone for servicing.

USING YOUR OHCM-200

The OHCM-200 can be used with any standard mixer, powered mixer/ampliﬁer, or mic

preamp which provides 9-52V phantom power. The optional Nady 48V SMPS-1 Phantom

Power Supply can also be used if your mixer doesn’t supply phantom power. Connect the

supplied mini-XLR to XLR cable directly to your equipment, or use an XLR to XLR bal-

anced low impedance cable as an extension if needed.

The OHCM-200 should be placed at the desired location and aimed at the sound source.

The hanging wire must be attached at an appropriate spot to support the mic and allow

proper stable aim at the source. Experiment with your mic and and its placement and you

will ﬁnd it to be a useful tool in many applications. Although designed primarily for high

quality far ﬁeld pickup of audio, such as for use with choirs and stage plays, the Nady

OHCM-200 can also be used in many creative applications. For example, it can also be used

closed ﬁeld to pickup audio from instruments and percussion. Be aware of the proximity

effect (an increase in bass response) when the mic is placed close to the instrument. This

may or may not be desirable. Experimenting with the position of the mic with respect to the

audio source will ensure the optimum results you are seeking in any given application.

If the microphone is placed too near a speaker during live stage use, an unpleasant howl

ing effect (acoustic feedback) may occur. Although all microphones are prone to feedback

to some extent, those with a unidirectional polar pattern (such as the OHCM-200) are

specially designed to accept only signals from audio sources in front of the mic element.

Thus, the cardioid pattern of the OHCM-200 ensures that it will deliver only the desired

audio in front of the mic, rejecting the unwanted audio from the rear, even in noisy ambient

conditions with high sound pressure levels from the P.A. and monitor speakers. This means

that feedback will be greatly minimized with the OHCM-200 in all live performance miking

applications. Of course, when using this mic in far ﬁeld audio pickup applications, extra

care must be taken to lessen feedback.

Some useful ways in which to totally eliminate annoying feedback in live use include:

experimenting with mic positions with respect to the speakers, decreasing speaker volume

(whenever possible), and adjusting the equalization of the mic audio with the mixer.

OHCM-200

Overhead Hanging Condenser Microphone

USER GUIDE

OHCM200_manual.indd 1 3/9/06 1:43:38 PM
