Item # 12-2026MAP $1990.00

NanliteUS.com

• Monolight style COB LED

• Output 11950 Lux of 5600K

daylight-balanced light at 1 meter

• Weighs only 5.7 lbs

• Flicker-Free Dimming from 100% to 1%

up to 25,000 fps

• High CRI/TLCI of 95/96

• Includes Light, Power Adapter, Reflector

& Carry Case

Lightweight,

Compact Design

Created to eliminate the difficulties of

traveling with large light fixtures the

Forza 500 weights only 5.7 lbs and is

compact enough to be easily packed into

most gear cases.

Bowens Style Light

Modifier Mount

By utilizing the near-universal Bowens

style light modifier mount, the Forza 500

is compatible with a massive selection of

light modifiers. Including, but not limited to

NanLite’s line of softboxes and umbrellas.

Practical Effects

With pre-programmed special effects in a

simple-to-master menu system, the Forza

makes it easy to imitate lighting scenarios

that can otherwise be tricky to recreate. At

the touch of a button, you can simulate the

lighting effects of lightning, a TV screen, a

flash, and a malfunctioning light bulb.

FL-20 Fresnel Lens for

Forza 300/500

RC-1 Remote Control

Nanlink App

Control System

SB-PR-90

Para 90 Softbox with

Bowens Mount (35in)

SB-PR-120

Para 120 Softbox with

Bowens Mount (47in)

SB-PR-150

Para 150 Softbox with

Bowens Mount (59in)

Additional Accessories:

Technical Data

Power Consumption 500W

Power Supply DC48V / 12.5A 100-240V AC

Battery Compatibility Sony V-Mount 26v Battery (Not Included)

Charge Time to Full Battery Dependent

Runtime @ 100% Brightness

(2x) 26V Sony V-Mount Style 230WH: 1.5 hours

Lumen Output 5600K 46613

CRI (Ra) 98

TLCI 95

Color Temperature 5600K

Dimming 0 to 100% continuous

Control Dimming, 2.4G wireless control, Wifi control, DMX

Dimensions 12.2 x 8.1 x 5.6 In

Weight

Light 5.5 Lbs

Light + Adapter +

Power Box

10.6Lbs

Cooling System Active Silent Fan

DMX Control Yes

Mount 5/8" reciever with rotating yoke/Bowns S Style

Warranty Limited 1-Year

Distance 1M 3M

With Standard

Reflector

66300 lux lux6257

6159 fc fc582

Without Lens

19820 lux lux2217

1841 fc fc205

With Fresnel lens

Spot 10°

N/A lux lux25090

N/A fc fc2330

With Fresnel lens

Flood 45°

48810 lux lux13520

4534 fc fc1256

Produkt Specifikationer

Mærke:	Nanlite
Kategori:	Lys
Model:	Forza 500
Vekselstrømsindgangsspænding:	100 - 240 V
Bredde:	310 mm
Dybde:	206 mm
Vægt:	2495 g
Produktfarve:	Sort
Antal:	1
Lampetype:	LED
Bæretaske:	Ja
Lysstrøm:	46613 lm
Pære levetid:	- t
Dæmpbar:	Ja
Antal lyskilder:	- pære(r )
Total effekt:	500 W
Højde (maks.):	142 mm
Farvetemperatur (min.):	5600 K
Farve-gengivelse (CRI):	98
Energiforbrug pr. 1000 timer:	- kWh
