User Manual
DDR MiVUE 830DC
Got a Question? Visit www.navman.com.au/faq | www.navman.co.nz/faq for more information
Revision: R01
(02/2021)
Trademark
All brand and product names are trademarks or registered trademarks of their respective companies.
Disclaimer
Specifications and documents are subject to change without notice. Navman does not warrant this document is error-free. Navman assumes no liability for damage
incurred directly or indirectly from errors, omissions, or discrepancies between the device and the documents. Visit www.navman.com.au or www.navman.co.nz for
the latest User Manual.
Note
Not all models are available in all regions.
Depending on the specific model purchased, the colour and look of your device and accessories may not exactly match the graphics shown in this document. It is
recommended that you contact a skilled installer (e.g. the service personnel of the vehicle or an authorised auto technician) for assistance and installation.
Regulatory information
For regulatory identification purposes, this Navman device is assigned a model number of N609. Marking labels located on the exterior of your device indicate the
regulations that your model complies with. Please check the marking labels on your device and refer to the corresponding statements in this section. Some notices
apply to specific models only. The user needs to switch off the device when exposed to areas with potentially explosive atmospheres such as petrol stations, chemical
storage depots and blasting operations.
WEEE
This product must not be disposed of as normal household waste, in accordance with the EU directive for
waste electrical and electronic equipment (WEEE – 2012/19/EU). Instead, it should be disposed of by
returning it to the point of sale, or to a municipal recycling collection point.
5615N6090006 R01
1. Product Overview
1
System indicator
2
Microphone
3
LCD screen
4
Power button/Function
keys
5
Mounting socket
6
Camera lens
7
Speaker
8
Mini-USB connector
9
Memory card slot
1
2
3
4
5
8
9
6
7
Power button
Press and hold the Power button ( ) for 2 seconds to turn the dash cam on and off.
Function keys
The four function keys control the corresponding icons displayed on the LCD screen. Key functions may vary
depending on the current screen and features enabled.
(Recording screen)
Activates/deactivates emergency recording
Opens the Menu screen
Adds a safety camera/Enters Parking Mode (if activated)
Switches between the front and rear views
(Menu screen)
Moves to the next item
Selects the current item
Moves to the previous item
Returns to the previous page
System icons
The status bar on the top of the screen contains various system icons to provide status information about your device.
1
Recording indicator
2
Current time
3
Microphone status
4
GPS signal status
5
Driving speed display
1
2 4
5
3
2. Using your dash cam in a vehicle
Note:
The dash cam should be placed near the rear-view mirror to ensure the highest video quality.
For your own safety, do not operate the controls of the product while driving. Using this product does
not exempt the driver from taking full responsibility for his/her driving behaviour, which includes
observing all traffic rules and safety regulations.
Make sure the dash cam is mounted at a location that does not obstruct the driver’s view or airbag
deployment.
Make sure that the camera lens is not blocked and no reflective material appears near the lens. Please
keep the lens clean.
Video quality may degrade if the vehicle's windscreen is tinted.
The system will automatically calibrate the G-sensor during start-up. If the device's viewing angle or
installation position was changed from the original position after start-up, please turn the device off and
on again to recalibrate the G-sensor. Otherwise the G-sensor may malfunction and impact other features
of the device (such as event-driven recording and Parking Mode).
The dash cam is designed to stay connected with the vehicle power adapter to ensure optimal
performance. The internal battery is designed as a backup power source for short-term use only. It allows
the dash cam to save the last recording in case the vehicle's power system fails during an incident. The
internal battery is not to be used as the primary power source for prolonged periods. Battery life may
vary under different conditions.
Mounting the dash cam
The product includes two different mounts, the suction cup mount and the double-sided tape (paired with a static cling
window film). Make sure your vehicle is parked on level ground and follow the instructions below to securely mount your
dash cam.
1. Before attaching the device to the windscreen, it is recommended to clean the windscreen with rubbing alcohol and
make sure that the installation area is free of dust, oil and grease.
2. If using the double-sided tape paired with a static cling window film, make sure there are no air bubbles trapped
under the static cling window film.
Suction CupDouble-sided tape
3. To adjust the dash cam's viewing angle, make sure that the camera’s view is parallel with the level ground and the
ground to sky ratio is about a 50/50 split.
4. Connect the vehicle power adapter to the cigarette lighter. Route the cables through the top ceiling and the A-pillar
so that they do not interfere with driving. Make sure the cable installation does not interfere with the vehicle's airbags
or other safety features.
Note: The installation illustrations are for reference only. Device and cable placement may vary depending on
the vehicle model. If you encounter any problems during installation, contact a skilled installer (such as the service
personnel of the vehicle) for assistance.
Mounting the rear recording camera
To install the rear recording camera, please wipe the surface of the rear windscreen clean with rubbing alcohol. Select a
suitable location for mounting the rear recording camera so that the driver's field of vision is not obscured.
1
2
3
4
5
Follow the illustration below to connect the data and power cables:
To rear cam
To 12V auxiliary
power outlet
Note:
The device's Mini-USB port does not support hot-swapping. When installing the rear recording camera,
please connect the data cable prior to connecting the power cable. The device must be off before
disconnecting the rear recording camera.
3. Using a memory card
In order to record video footage, Navman MiVUE dash cameras need a microSD. It is very important to use a microSD
card specifically designed to be used in dash cameras. It will ensure the card will be more reliable and last longer; the
wrong type of card has a greater chance of failing, even after a short period of time. Please visit www.navman.com.au/
memory-card for more information on recommended SD cards.
To insert the SD card, hold the card by the edges and gently insert it into the slot as shown
in the illustration.
To remove a card, gently push the top edge of the card inwards to release it and pull it out of
the slot.
Formatting a card
To format the memory card (all data will be erased), press > Format.
Note:
l
DO NOT apply pressure to the centre of the memory card.
l
Navman cannot guarantee product compatibility with memory cards from all manufacturers. Please always
check the specifications/warranty to ensure the memory card can be used in dash cameras and loop recording
devices.
l
Please format the memory card to avoid recording errors caused by missing system files or folders.
l
You may need to format your memory card periodically to ensure it remains in good working condition.
l
You should use separate MicroSD cards for the dash cam and other electronic products (such as a digital
camera).
l
You are advised to turn the device off before removing the memory card.
4. Turning the dash cam on/off
Complete the installation according to the instructions in the “Using your dash cam in a vehicle” section. Once the
vehicle engine is started, the dash cam will turn on automatically.
Shutting down the dash cam
Occasionally you may need to perform a hardware reset when the dash cam stops responding or if it appears to be
“frozen” or unresponsive. To shut down the dash cam, press and hold the Power button until the system powers off.
If you cannot turn the dash cam off by using the Power button, insert a small pin (such as a
straightened paper clip) into the Shutdown button to shut down the dash cam.
5. Setting the date and time
The system date and time must be correct in order for the videos to display accurate timestamps. The date and time can
be configured by pressing > System > Date / Time and selecting::
Use GPS Time: Select the appropriate Time Zone and Daylight Saving Time settings for your location.
Manual: Press / to adjust the highlighted value and press to navigate to the next field. Press
to save the settings.
6. Recording videos while driving
Continuous recording
Continuous recording will automatically commence shortly after the system is powered up. The system indicator will flash
while recording is in progress. Recording can be paused by pressing . Press to return to the recording screen and
resume recording.
Videos taken during continuous recording are divided into multiple clips and saved under the "Normal" folder,
but recording will not stop between video clips. Once the folder has reached its allocated capacity, the system will
automatically record over the oldest video saved under this folder.
Event-driven recording
During continuous recording, if a sudden event has been detected, such as running over a road bump, vehicle collision,
high-speed driving, or making a sharp turn, the G-sensor will prompt the dash cam to record the event.
Note: The sensitivity level of the G-sensor can be adjusted by going to > Video Recording > G-sensor
Sensitivity.
The actual recording will begin three seconds before and end 12 seconds after the event has taken place. Video recording
will continue if the sensor is triggered again while recording an event. Event-driven recordings are saved in the "Event"
folder. Once the folder has reached its allocated capacity, the system will automatically record over the oldest video saved
under this folder. You can also press to manually activate event-driven or emergency recording while continuous
recording is in progress.
7. Recording videos while parked
Note: The dash cam cannot operate in Parking Mode by relying on its internal battery power. An additional accessory
such as an uninterruptible power cable or the Smart Box is required. Please visit www.navman.com.au or www.navman.
co.nz for purchasing information.
Parking Mode is disabled by default. Before enabling Parking Mode, please check your device memory storage allocation.
Go to > System > Storage Allocation to set a proper allocation for parking recording. Changing memory
allocation will erase the contents on the memory card, so save any videos or photos to your computer first.
You can enable the function by selecting > Parking Mode > Detection > On (the icon will appear on the
recording screen). When movements or vibrations are detected during Parking Mode, the system will save the duration
from three seconds before the event until 12 seconds after the event. The saved recording can last up to 1 minute
if the sensor is triggered again during the recording. Parking Mode recordings are saved in the "Parking" folder. Once
the folder has reached its allocated capacity, the system will automatically record over the oldest video saved under this
folder.
Note:
You can press to enter Parking Mode while continuous recording is in progress.
Parking Mode recording is triggered by the G-sensor and motion detection. You can change the sensitivity level by
selecting > Parking mode > Motion Detection > G-Sensor Sensitivity.
To exit Parking Mode (and resume continuous recording), press . You will be prompted to view any saved recordings.
8. Camera mode
The dash cam can also be used as a camera to take photographs. Access Camera Mode by going to > Camera and
pressing to capture a still image. Photos captured by the dash cam are stored in the “Photo” folder.
9. Viewing videos and photos
To view a video or photo captured by the dash cam:
1. Press > File Playback.
2. Select a folder.
3. Select a video or image then press to view the file.
4. While viewing a file, you can:
l
Press to return to the file list.
l
While playing a video, press / to play the previous/next video.
Press to display a pop-up menu to perform the following actions:
l
Play: Resumes video playback.
l
Play front/rear video: Plays the corresponding rear/front video.
l
Move to Event: Moves the file to the “Event” folder.
l
Delete: Deletes the current file (the corresponding front/rear video is also deleted).
l
While viewing a photo, press / to display the previous/next photo. Press to delete the file.
10. Safety camera alerts
The system can issue alerts if the vehicle is approaching a safety/speed camera to help drivers monitor their speed.
The driver will receive a visual alert on the screen as well as an audio warning (Beep/Voice) when there is a safety
camera ahead.
If the Safety Cam > Alert Sound setting is set to Beep:
The dash cam will beep once to alert the driver of the safety camera ahead.
If the vehicle is travelling over the speed limit while approaching a safety camera, the driver will hear continuous
beeping until the driver slows down to the proper speed.
The dash cam will beep again once the vehicle has passed the safety camera.
Adding a safety camera
Note: A custom safety camera can only be added after a GPS fix is established and while Parking Mode is
disabled.
Up to 100 custom safety camera locations can be added to the built-in database. To add a custom safety camera at the
vehicle's current location, press on the recording screen. After a location has been added, the dash cam will issue
alerts the next time you pass through this location.
To view detailed information on a custom safety camera, press > Safety Cam > Custom Safety Cam, use
/ to select a location, then press to view its GPS coordinates and timestamp; press to delete the record.
Updating safety camera data
Navman does not warrant that all types and locations of safety camera data are available as cameras may be added,
removed, or relocated. Your MiVue dash cam may come with monthly safety camera updates via the Navman website
(for selected models only). Visit www.navman.com.au/faq | www.navman.co.nz/faq for more information.
11. The Menu screen
Press to access the Menu screen that includes the following device settings:
File playback
Plays recorded videos and photos.
Camera
Activates Camera Mode for capturing still images.
Sound Recording
Enables/disables audio recording during video capture.
SafetyCam
Detection: Enables/disables safety camera alerts.
Alert Sound: Selects Beep/Voice or turns off (Mute) audio alerts.
Alert Distance: The system will alert you at a preset distance (Short/Medium/Long) when your vehicle is
approaching a safety camera.
Alert Method
Smart Alert: Sets the alert distance function according to the current GPS car speed.
Standard Alert: Sets the alert distance function according to the speed limit.
Threshold: Sets the speed value for the dash cam to start offering alerts.
Cruise Speed Alert: Sets the cruise speed limit. When you drive at a cruise speed over the set value, you will
receive alerts from the dash cam.
Custom Safety Cam: Lists all custom safety cameras sorted by creation timestamp.
Parking Mode
Detection: Enables/disables Parking Mode.
Detection Method: Sets the detection method to Only G-sensor/Only Motion/Both.
Note: G-sensor detection is based on movements/vibrations of the vehicle detected by the gravity sensor;
motion detection captures movements in the camera's field of view.
Auto Entry: Sets the G-sensor’s sensitivity level (Easy/Medium/Difficult/Manual) for activating Parking
Mode. For example, when the option is set to Easy, the G-sensor will have a low sensitivity level and Parking Mode is
activated much easier.
Motion Detection: Sets the sensitivity level (Low/Medium/High) of motion detection that triggers video
recording during Parking Mode.
G-Sensor Sensitivity: Sets the sensitivity level (Low/Medium/High) of the G-sensor for triggering video
recording during Parking Mode.
Video Recording
l
Video Clip Length: Sets the length of each video clip for a continuous recording.
l
WDR: Enables or disables the Wide Dynamic Range (WDR) function of the device to provide better images with
higher contrast of light and dark.
l
EV: Sets the proper exposure level to adjust the brightness of the image.
l
Frequency: Sets the frequency (50 Hz or 60 Hz) for the camera to avoid problems caused by artificial light sources
that are not constant.
l
G-Sensor Sensitivity: Sets the sensitivity level of the G-sensor that triggers the event recording during continuous
recording.
l
Stamps: Sets the information (Coordinates or G-Sensor) that will be displayed on the recorded video.
l
Speed Stamp: Displays the driving speed on the recorded video.
l
Text Stamp: Displays the customised information on the recorded video.
System
l
Satellites: Displays the status of the GPS signal reception.
l
Date/Time: Sets the system date and time.
l
System Sound: Enables or disables system notification sounds.
l
Volume: Adjusts the volume level.
l
LCD Standby
l
Always On: Keeps the LCD on.
l
HUD: Activates Driving Speed Display Mode where the LCD only displays current time and vehicle speed.
l
10 sec/1 min/3 min: Sets the timer for the LCD to turn off automatically after recording starts.
l
Language: Sets the language.
l
Distance Unit: Sets the preferred distance unit.
l
Storage Allocation: The system provides 3 memory configurations to store the videos and photos. Select the
proper configuration based on your usage.
l
Restore to Defaults: Restores the system settings to factory defaults.
l
Version: Displays the software information.
