Introduction:
Watch over your properties with this new 2.4 GHz digital wireless security camera
system. The 7” LCD monitor can support up to 4 cameras and has an integrated digital
video recorder. The camera oers a very sharp and stable image with night vision and
the technology used improves the image quality even further. The system uses digital
wireless technology and is equipped with advanced frequency signal encryption
capabilities, which reduce interference caused by other applications using the 2.4 GHz
frequency band. This digital technology ensures your privacy and allows you to use it
over an extra long distance. THE BEST THAT WIRELESS HAS TO OFFER.
The monitor and camera are paired by factory default already. When adding the
additional camera CSWL1C20CBK (4 cameras max.) to the system, please refer to the
section PAIRING for adding cameras.
• We recommend that you read this manual before installing/using the camera system.
• Keep this manual in a safe place for future reference.
Technical specications:
Transmitting frequency: 2.4-2.4835 GHz Digital
Modulation: 16QAM, QPSK, BPSK
Range: Indoor ±50 m, open area ±150 m (depending on local
conditions)
Image chip: 1/4” CMOS
Lens: 2.0mm
View angle: 73°
Infrared illumination (LED): 5 M
Protection: IP54
Microphone: mono
Working temperature: -10°C ~ 50°C
Voltage: 5 V DC/400 mA
Dimensions: 132x64x57mm (without bracket)
Weight: 287 g (included cable)
Safety precautions:
• Do not open the camera or monitor in the event of a malfunction. These products
should only be opened by a qualied engineer.
• Do not submerge the camera in liquid.
• Do not expose the monitor to water or humidity.
• Do not expose the monitor or camera to high temperatures (see technical
specications).
• Do not install the system close to strong magnetic elds, such as a speaker. This may
aect the quality.
