Installation Guide

Overview

The APS350W, APS600Wv2, APS920W, and APS2000W auxiliary power supplies (APSs)

are supported in the following M4350 series switch models:

• M4350-24F4V (SKU number XSM4328FV)

• M4350-24X4V (SKU number XSM4328CV)

• M4350-44M4X4V (SKU number MSM4352)

• M4350-24G4XF (SKU number GSM4328)

• M4350-48G4XF (SKU number GSM4352)

Each APS provides two bi-colored LEDs (DC OK LED and AC OK LED), which work

together to indicate the power supply status, as described in the following table.

DC OK LED

(Left LED)

AC OK LED

(Right LED)

Condition

Solid green Solid green DC output is present and voltage is good.

Blinking green Solid green AC power is present but DC output is for standby only.

Solid Red Solid green A power supply failure occurred and the APS will be

shut down.

Solid green Loss of AC power occurred or AC power is not present.Blinking red

Install an APS

In models with more than one power supply bay, you can install an additional APS.

1. Pull out the cover plate from the power module bay in which you want to insert the

additional APS.

2. Insert the APS into the power module bay, and gently push the APS into the bay.

CAUTION: When inserting the APS, do not use unnecessary force. Doing so

can damage the connectors on the back of the APS and on the midplane.

3. Connect the end of the power cord to the power receptacle on the APS.

4. Plug the AC power cord into a power source such as a wall socket or power strip.

When you apply power, the AC OK LED ands the DC OK LED on the APS lights. The

LED on the switch for the power supply bay also lights. If these LEDs do not light,

make sure that the power cord is plugged in and that the power source is good.

Auxiliary Power Supplies for the

M4350 Series Fully Managed Switches

APS350W, APS600Wv2, APS920W, and APS2000W

Package contents

• Auxiliary power supply

• Power cord (varies by region)

• Installation guide

Replace an APS

In models with more than one APS, the APSs are hot-pluggable.

1. If your switch functions with a single APS only, disconnect the power cord from the

APS and let the switch power down.

If your switch functions with more than one APS, you do not need to power down the

switch and you can perform a hot swap.

2. Remove the APS from the power module bay by doing the following:

a. Position the extraction handle perpendicular to the APS.

b. Insert your left index nger into the extraction handle.

c. Use your left thumb to move the orange release latch to the left and keep it in the

release position.

d. Pull the extraction handle.

We recommend that you use your right hand to support the APS.

3. Insert the replacement APS into the power module bay, and gently push the APS into

the bay until the latch locks.

CAUTION: When inserting the APS, do not use unnecessary force. Doing so

can damage the connectors on the back of the APS and on the midplane.

4. Connect the end of the power cord to the power receptacle on the APS.

5. Plug the AC power cord into a power source such as a wall socket or power strip.

When you apply power, the AC OK LED ands the DC OK LED on the APS lights. The

LED on the switch for the power supply bay also lights. If these LEDs do not light,

make sure that the power cord is plugged in and that the power source is good.

May 2023
