Programmable Timer

for NTE4T Series

Set current day and time

Enter “settings” menu Press bottom left button to select “set day/time” menu

The day function should be flashing.

1. Select day by pressing up or down arrow.

2. Press bottom left button to confirm day.

Now do the same to select and confirm hour and minute of current time.

NB: Time is in 24 hour format.

QUICK START GUIDE

This instruction manual will show you how to use the timer on the heater. If you do not want to

use the timer, please simply skip to the “Set current day and time” section to learn how to input

the time. You can control the thermostat with the up and down buttons and turn the heater on

and off with the switch on the side of the heater.

Timer Overview

The timer has two heat modes: one for

“day/peak” and one for “night/off peak”.

You can set a different temperature for

both of these periods, for example,

to keep the room warm during the

day while you are using it and then to

take the chill off the room when you

are sleeping.

The desired temperature for each heat

mode can be set to between 7°C and

30°C. Alternatively, you can just have the

heater turn off in either mode.

The icon in the bottom left of the screen

(either a sun or moon symbol) will denote

the current heat mode (either day/peak

or night/off-peak).

Sometimes, you may want to switch your current heat mode (from the default mode set for the current time) to the

non-current mode e.g. from day/peak to night/off-peak or vice versa.

You may want to do this to allow you to adjust the desired temperature/thermostat of the non-current mode.

Or you may want to apply the other heat mode at this current moment (e.g. you may want to turn up the temperature

temporarily without distorting the pre-programmed settings)

To manually switch heat modes (e.g. from night/off-peak to day/peak or vice versa), simply press the top left button

next to the picture of either the sun or the moon. That icon should now get highlighted with a black background and

the desired temperature in the display screen should also change (assuming the alternative heat mode has a different

temperature).

In the diagram shown, the desired temperature/thermostat has changed from 21 (set for day/peak mode) to 16 degrees

(set for night/off peak mode).

Press the same button again to go back to the default heat mode for the current time.

Note: for safety reasons, at 3am each day, if the heat mode has been manually overridden, the heater will automatically

switch back to the default heat mode for that time. Manual overrides will also end when a new timing setting starts.

To lock the timer (e.g. so children cannot change the settings), press and hold the two left buttons for one

second. A lock icon should show up on the right side of the display screen.

To unlock the timer, again press and hold the two left buttons for one second. The lock icon should disappear

and the regular settings should reappear on the display screen.

Manually Overriding Heat Modes

Heater on light

Key Lock

This light will illuminate when the

heating element is on.

Glen Dimplex Australia Pty Ltd

Unit 1, 21 Lionel Road

Mount Waverley VIC 3149

Ph: 1300 556 816 Fax: 1800 058 900

Email: sales@glendimplex.com.au

www.nobo.com.au

Glen Dimplex New Zealand Ltd

38 Harris Road

East Tamaki, Auckland

Ph: 09 274 8265 Fax: 09 274 8472

Email: sales@glendimplex.co.nz

www.nobo.co.nz

Selects the function shown in the top right of

the display screen. In many menus, this button

will take you back to the previous screen.

Scroll down/decrease

Scroll up/increase

Desired

temperature

for current

heat mode

Press top left button to

manually override the

current heat mode –

see “Manual Override

Heat Mode” section

Current day

and time

Current heat

mode is

“day/peak”

Selects the function shown in the bottom right

of the display screen. In many menus, this

button will confirm your settings.

page 1

Oslo Range

Programme Timing Settings

Press the bottom left button to enter settings.

1. Press the down button until the Timing Settings menu appears.

2. Press the bottom left button to select.

This setting will apply until it gets to a time when a new setting takes over.

Good work. You have now set a time for when you want this heat mode to turn on. You will now need to create another timing

setting that will take over from the previous setting (e.g. for the heater to then turn off or for it to heat at a lower temperature).

If you set the first heat mode as a day/peak mode, you will now need to set the next heat mode that will take over as a night/off-

peak mode (and vice versa).

As an example you may want to set the first mode as a day/peak mode so that it heats your room to 22°C every day of the week,

from 8am onwards. You may then want to create the night/off-peak mode that will take over at 6pm and turn off the heater

(or heat at a lower temperature). Therefore every day from 8am-6pm, the heater will heat the room to 22°C and then turn off

between 6pm and 8am.

To add a new setting, select the “add timing” setting

(you may need to

scroll to select it) and then press the bottom left button to confirm.

1. Select the day(s) you would like this timing setting

to apply for by pressing the up/down buttons.

2. Then press the bottom left button to confirm.

Now do the same for whether you want this heat mode applied as a day/peak

mode or night/off-peak mode.

Then press the bottom left button to confirm.

Scroll to select the hour of the day you want this heat mode to start from.

Then press the bottom left button to confirm.

page 2

Editing an existing timing setting.

Use the up and down arrows to scroll through the timing settings until you find the one you want to change.

Then press the bottom left button to confirm.

Use the up and down arrows to select the edit setting.

Then press the bottom left button to

confirm and edit the setting.

1. Select the day(s) you would like this timing setting to apply for by pressing the

up/ down buttons.

2. Then press the bottom left button to confirm.

You can now edit the day, heat mode (day/peak vs night/off-peak), hour and minute in the same way you did when setting up the

timing setting.

Now do the same for whether you want this timing applied as a day/peak mode or night/off-peak mode. Then press the bottom

left button to confirm.

Select the hour of the day you want this heat mode to start from.

Then press the bottom left button to confirm.

Select the minute within the hour of the day you want this heat mode to start from.

Then press the bottom left button to confirm.

When you have have finished editing timing settings, press the top left button,

to return to the main screen.

page 3

Setting desired temperature/thermostat

Setting temperature for current heat mode To set the desired temperature in

the current heat mode (sun/moon icon in bottom left of screen), press the up/down

arrows till you get the temperature you would like the heater to heat the room to.

Setting temperature for non-current heat mode If the mode you just set the

temperature to was day/peak, then press the top left button to select night/off-peak

mode (and vice versa). This is also known as “Manual Override” (see “Manually

Overriding Heat Modes” section for more information). The icon in the top right

should now be highlighted with a black background.

Now press the up and down buttons to set the desired temperature.

Then press the top left button again to go back to the mode

appropriate for the current time.

Use the up and down arrows to scroll through the timing settings until you find the one

you want to delete. Then press the bottom left button to confirm.

Use the up and down arrows to select the delete setting

Then press the bottom left button to confirm and delete the setting.

When you have have finished deleting timing settings, press the top left button,

return to the main screen.

Deleting an existing timing setting

Scroll to select the minute within the hour of the day you want this heat mode to start from.

Then press the bottom left button to confirm.

Adding a new timing setting.

Adding a new timing setting. continued
