ET1S-G

Media Server

Appearance

Front Panel

Rear Panel

Applications

USB Pos

Connect the mouse, keyboard or USB drive.

Power Button

Power on or power o the device.

* The product pictures shown in this guide are for illustration purpose only. Actual product may vary.

RJ45 Ethernet Po

Connect the device to the network .

Power Switch

Output Connectors

Audio Connectors

USB Pos

Connect the mouse, keyboard or USB drive.

Power Connec tor

HDMI Connector

Connect the monitor for displaying the software UI.

Monitor

Keyboard

Mouse

Media Files

Laser Pointer

VICP

Router

Software Operations

The ET1S-G integrates Kompass FX1 multimedia playback software, with various operations

such as adding media, editing and playing programs.

3 1 Add Media Files.

Kompass FX1 supports batch file

import and folder import. You can

import the media files via the following

methods:

Directly drag single media file,

•

multiple media files or folders into

Media Library to automatically

add the media.

Click in the lower-left corner

•

of Media Library, then select to

add a local file or folder to

proceed with the import.

Add media files or folders

Drag media here

Note

The user interface and functionality may vary depending on the actual

version of Kompass FX1 you have obtained.

3.2 Edit Programs

1. Select the target media file in Media

Library and drag it to the desired

layer in a program or the stage

editing area.

2. Drag and drop the layers in the

stage editing area to quickly adjust

their position. Drag the eight dots at

the edges of the layers to quickly

resize them.

3. Click the layer and set its playback properties in

the Properties area on the right.

4. Edit the remaining layers of the program one by

one to complete the editing of the current

program.

Pause the program playback.

Play the program.

Stop playing all the programs.

After completing the layer editing, click the button to

the left of the program name to play the program as

you like.

3.3 Play Programs

PPla

lalayb

ybybac

acack Co

k Co

k Cok Cont

ntntro

rorol

3.4 App Control

1. In Kompass FX1, navigate to Settings External >

Control to open the external control window.

2. Select the Network tab and check the box in front of

TCP/IP.

3. Enter the listening port number in the text box next

to Port.

The value ranges from 1024 to 65535.

4. Click Listen to enable the listening.

You can pause and play of individual layers in the

Playback area on the right.

Click to the right of the layer to pause the

playback.

The ET1S-G supports control via an App named Visual

Intelligent Control Platform (VICP), you need to enable

the listening port for the external control.

PProg

rog

rogrogra

raram

m m J

JJu

uum

mmp

Right click a program to open the context menu and

select After Program Ends where you can set the action

after the current program ends to manually sort the

playback order.

Main Media: Set which layer is used as the main media.

The playback timing and program switching are all based

on the main media.

*The software pictures given in this guide are used for illustration purposes only. The actual user inteace may va slightly due

to product enhancement. The content of the pictures can be slightly dierent from reality, such as the media les, form and

position of software windows and more.

Note

For operation methods when using the App, please refer

to the user manual of the App in advance.
