Side 1/2

Your excellent helper in cable test!

5.CODE ERROR DISPLAY AND SOLUTIONS

254

255

256

257

203

220

300

6 DIAGRAM OF SERIES PRODUCTS.

3.TECHNICAL PARAMETERS

4 STANDARD PACKING.

OR IG INA L

AU TH ENT IC

OR IG INA L

AU TH ENT IC

Your excellent helper in cable test! Your excellent helper in cable test!Your excellent helper in cable test!

*Avoid to operate in such conditions (such as the environment

light is too strong,or the diffuse coefficient of measuring points

is too large or too small),otherwise,themeasuring accuracy

.will have large error

*Please use the dam-board when in strong sunlight and week

refection condition.

- ℃～ ℃10 60

0.05~40/60m

±2mm

m/ft/in/ft+in

√

0 40℃～ ℃

IP54

80 42 78mm* *

Measurement

range

no operation

with 30s

no operation

with 120s

0.1~3s

Λ=630~670nm,

P 1mW＜

NF-2240:

2x1.5V AAA

NF-2260L:

Lithium battery

240g(no battery)

Measurement

precision

Display type

Unit options

Benchmark

setting

Signal

measurement

Continuous

measurement

Area

measurement

Volume

measurement

Pythagorean

measurement

Beep

Voice function

Tape measurement

range

Bluetooth 4.0

Electronic

level

Au-off time

of the device

Test time

Laser type

Working

temperature

Storage

temperature

The type of

battery

Protection

level

Dimension

Weight

Au-off time

of the laser

FSTN LCD screen

Code

Reasons

Solutions

Exceeding temperature

Low battery

Data overflow

Weak signal or

measuring for long time

Strong signal

Exceeding measuring

range

Hardware error

Use the device under the working

temperature range.

Charge or replace battery

Remeasure after reading the user manual

Test strong reflection ability of target

Test weak reflection ability of target

Use the device under the max measuring

distance range.

Restart,please contact the dealer when

try that fail.

Item

Main tester

Lithium battery

Sponge

Color box

Unit

pcs

QTY

Note

Only for NF-2260L

NF 2050 NF 2330NF 2030 - --

NF 2240 NF 2260L- -

NF 273L eriesS NF 274L eriesS- -

NF 271 Series-

NF 272L Series-

NF-2240/NF-2260L

1 OUTLINE.

m m

Before operating or repairing , please read

and remember the safety precautions.

Thank you for purchasing our 2-in-1 laser distance

measuring tape series products!

Please

manual before operation. Improper operations without complying with

this manual guided could cause damage to the device ,influence on

measurement result or bodily injury to the user.

read all of the operational guide and safety regulations in this

The instrument is not allowed to disassemble or repair on any ways.

it is forbidden to do any illegal modification or performance change

for laser emitter . Please keep it out of reach of children and avoid

using by any irrelevant personnel.

It is strictly prohibited to shoot eyes or other parts of body with the

laser, it is not allowed to take the laser to shoot any objects’ surface

with strong reflecting.

Due to electromagnetic radiation interference to other equipment and

devices , please don't use the meter in the plane or around medical

equipment, don’t use it in inflammable, explosive environment.

Discarded batteries of meter device shall not process just like household

garbage.please handle them in line with related law and regulations.

Any quality issues or any questions on the meter please contact local

distributors or manufacturer in time, we are ready to offer solutions for

you.

①

②

③Laser Emission Port

④Tape

Metal Buckle

Self locking Button

⑤

⑥

⑦Modes/Unit Switch

⑧On/Off/Measuring

Usb Charging Port

Screen

(only for NF-2260L)

①

②

③

④ ⑤

⑥

⑦

⑧

2 INSTRUCTIONS.

1 Turn on Turn off. /

Under off state of the device, press for 1

second to turn on the device.

Under on state of the device, long press

for 3 seconds to turn off the device.

(The Back light will be off if no operation

within 15sec; the laser will be off if no

operation with 30sec. the device will be

auto-off if no operation within 120sec.

2 Single measurement.

Short press to turn on the laser,re-press

for single measurement of distance,

then the measured results will display on

the screen.

3 Continuous measurement.

Short press to turn on the laser, re-press

for1 second to start continuous

measurement.

The Main display screen indicates the very

measured result, and the Max and Min

measurement results will display on the top

two lines of the screen, The main line displays

real-time measured result. Press to exit the

mode.

4 Area measurement.

Turn on the device,then short press to enter the area measurement

mode, the result will show ,one of the edges will flash. Compete The

following operations as bellow:

Short press to measure the first edge(length)

Short press to measure the second edge

(width)

Area. will be calculated automatically by the

device, and the result will show on the main

display screen.

5.Volume measurement

Turn on the device,then short press to enter

the area measurement mode, the result will

show ,one of the edges will flash. Compete

The Following operations as bellow:

Short press to measure the first edge,the L1

data is length Short press to measure the

second edge, the L2 data is width Short press

to measure the second edge,the L3 data is

height Volume will be calculated automatically

by the device, and the result will show on the

main display screen.

6.Unit switching

Under on state of the device, long press for 1

second to set the unit.

(0.000m 0.00m 0.00ft 0´00" 0.0in →

→ → 0.0in 0in)

→ → →

7 Measurement benchmark etting. s

Under on state of the device, simultaneously press and into setting

of switching between front benchmark and end benchmark.

System usually takes end benchmark as default.

8 Settings.

Under off state of the device, press and hold for 5 seconds to enter

the setting mode, the screen flashes:

Set 1: beep/voice switch

Set 2: Calibration settings (adjustable range-9mm~9mm)

Note: Short press to switch the current setting items;

Short press to switch set1 or set 2.

Your excellent helper in cable test! Your excellent helper in cable test!Your excellent helper in cable test! Your excellent helper in cable test! Your excellent helper in cable test!

Front benchmark End benchmark

Set 1 Set 2

2-in-1 Laser distance measuring tape NF-2240/NF-2260L can measure

length,height,width,area and volume,and NF-2260L has voice broadcast

function. Please read this manual carefully for more details. This series

of measuring instruments have 2-in-1 functions: laser ranging measure

and self-locking steel tape measure,which is applied to the measurement

scenes in various occasions.
