O S CKLAHOMA OUND ORPORATION

Orator Adj. Height Lectern

INSTRUCTION MANUAL

MODEL #800/800X

For these and other OSC accessories, please contact your dealer, or:

OKLAHOMA SOUND CORP.

149 Entin Road, Clifton, NJ 07014

Tel: 973-594-9000• Fax: 973-594-9339

Web-Site www.oklahomasound.com • e-mail: info@oklahomasound.com

OPTIONAL/ADDITIONAL EQUIPMENT WITH WIRELESS AMPLIFIERS

Your lectern includes two corded microphones. For complete freedom

of movement, use any of these wir

eless systems—

HAND-HELD WIRELESS MIC. / LWM-5

This wireless hand-held Mic. Uses a 9-volt battery. Select

channel A or B to eliminate outside frequency interruption.

Move freely up to 200 ft. away!

TIE-CLIP LAVELIER WIRELESS MIC. / LWM-6

Includes pocket-size transmitter with a clip-on mic. Uses a 9-

volt battery. Select channel A or B to eliminate outside fre-

quency interruption. Move freely up to 200 ft. away!

HEADSET WIRELESS MIC. / LWM-7

Includes pocket-size transmitter with a headset mic. Uses a

9 volt battery. Select channel A or B to eliminate outside

frequency interruption. Move freely up to 200 ft. away!

USE WITH NON-WIRELESS AMP

or ADDED WIRELESS USERS

TIE CLIP LAVALIER WIRELESS MIC SYSTEM / #WM-190TC

A compact, pocket-size, wireless system with tie-clip,

lavalier type microphone. Includes transmitter, receiver and

tie clip mic. Move freely up to 200 ft. Operates on

two 9V batteries.

WIRED-WIRELESS MIC SYSTEM / #WM-100H

Hand-held wireless mic system. Receiver has antenna and

on/off switch. Transmiter is built into mic. Move freely up to

50 ft. Mic uses AA battery; receiver uses AAA battery.

DUAL HAND-HELD WIRELESS MIC SYSTEM / #WM-200H

Offers freedom of movement for two people, Karaokee

style or speaker/audience participation; up to 200 ft. away.

Receiver operates on 110V AC. Each mic trans–

mitter uses one 9V battery (not Included).

12V LANTERN STYLE RECHARGEABLE BATTERY / #PS12V

12V 5 amp rechargeable battery pack w/included cable

connects to any of our lecterns for battery power. 20 hr life.

08/04

O S CKLAHOMA OUND ORPORATION

ORATOR LECTERN: Model 800 / 800X

INTRODUCTION

Congratulations! You are now the owner of the Orator,

#800X / #800 Height Adjusting Lectern, from Oklahoma

Sound Corporation. Now also includes wireless options

built in. We wish you long-lasting trouble-free usage for

years to come. If you have any questions or experi-

ence any difficulty with the product, please feel free to

call our Customer Service at 973-594-9000.

IMPORTANT SAFETY INFORMATION

As with any electric/electronic device, care should be

taken during use. Always turn off amplifier before

opening or servicing any part of the unit. Please han-

dle your lectern with the care it deserves.

AMPLIFIER OPERATING INSTRUCTIONS

Operating Precautions

Before operating the amplifier, be sure you fully understand all instructions and fea-

tures of the amplifier. DO NOT turn amplifier on until all input and output connec-

tions have been made. NEVER replace fuses unless power is off.

Microphone Input Connection

The microphone input accepts

⁄4" phone jack. Do not position microphone next to

or facing speakers. This may cause acoustic feedback.

Wireless Operation

Turn on the power on both the wireless receiver and wireless mic-1 making sure

both are set to matching chanels, either “A”or “B”.

Auxiliary Input

One auxiliary input is provided for radio tuner, tape recorder, cd player or multi-

media equipment. Output level is adjusted by the auxiliary volume control.

Tone / Equalization Controls

The Low and High frequency controls are similar to the bass and treble controls

found on most stereo systems. Optimum tone is achieved by first setting both knobs

halfway; adjust Low and High frequency controls to suit environment.

Auxiliary / Line Out

Connect speaker line to navy line out connector of the amplifier. For maximum

power transfer and to avoid amplifier overload, be sure that the total impedance

of the speaker line matches the output impedance setting on amplifier.

Be sure

that speaker terminals are not shorted together by speaker line connecting

cables. Can also be used for a recording device.

Power Supply 12V DC Operation

Connect a 12 volt rechargeable battery 5 Amp (not included) to the battery input

connector located on the panel of the amplifier (using 6' battery cable). Be sure

that the positive pole of battery is connected to the white wire terminal (+) and

the negative pole to the Brass wire (–). When lectern is plugged into a standard

wall outlet, the battery will automatically recharge. Green indicator light illuminates

during recharge mode.

Precautions

•Set Mic volume control on lowest when turning unit on.

•Insure correct polarity for D.C. supply connections.

•Reverse connection will blow the fuse and may damage internal circuitry.

•Always replace fuse with specified rating.

Removal and Installation of Amplifier

If your amplifier has to be removed for servicing — follow these simple steps:

1) Disconnect A/C wall plug.

2) Remove 2 side screws one on each side panel under podium top. Model 800

owners, simply loosen height adjustment knob and remove top.

3) Disconnect speaker wire at rear of amplifier card.

4) Remove 4 wood screws holding chassis to podium and remove amplifier.

5) Pack it into a strong box with ample cushioning and return to factory.

6) To install new amplifier reverse the above procedure.

MANUFACTURER’S WARRANTY

Our Lecterns undergo the most rigid and exacting tests for superior quality

and performance before leaving the factory. Oklahoma Sound Corporation

warrants this product to be free from defective material and workmanship on

the electronic product speakers and microphones for two years from the date of

resale by an authorized Oklahoma Sound distributor. Oklahoma Sound will

replace defective parts and repair malfunctioning products under this war-

ranty when the defect occurs under normal installation and use, provided the

unit is returned to our factory via prepaid transportation after direct autho-

rization and approval by Oklahoma Sound. This warranty provides that

examination of the returned product must disclose in our judgement, a man-

ufacturing defect. This warranty does not extend to any product which has

been subject to misuse, neglect, accident, improper installation, or where the

serial number has been removed or defected and is given in lieu of any other

warranty implied or expressed and will not cover any consequential damages.
