O S CKLAHOMA OUND ORPORATION

Power Plus Lectern

INSTRUCTION MANUAL

MODEL #111 PLS

For these and other OSC accessories, please contact your dealer, or:

OKLAHOMA SOUND CORP

149 Entin Road,

Clifton,

NJ 07014

Tel: 973-594-9000• Fax: 973-594-9339

eb-Site www

.oklahom

asound.com • e-mail: info@oklahomasound.com

OPTIONAL/ADDITIONAL EQUIPMENT WITH WIRELESS AMPLIFIERS

Your lectern includes two corded microphones. For complete freedom

of movement, use any of these wir

eless systems—

AND-HELD WIRELESS MIC. / LWM-5

his wireless hand-held Mic. Uses a 9-volt battery. Select

channel A or B to eliminate outside frequency interruption.

Move freely up to 200 ft. away!

IE-CLIP LAVELIER WIRELESS MIC. / LWM-6

Includes pocket-size transmitter with a clip-on mic. Uses a 9-

volt battery. Select channel A or B to eliminate outside fre-

quency interruption. Move freely up to 200 ft. away!

HEADSET WIRELESS MIC. / LWM-7

Includes pocket-size transmitter with a headset mic. Uses a

9 volt battery. Select channel A or B to eliminate outside

frequency interruption. Move freely up to 200 ft. away!

USE WITH NON-WIRELESS AMP

or ADDED WIRELESS USERS

TIE CLIP LAVALIER WIRELESS MIC SYSTEM / #WM-190TC

A compact, pocket-size, wireless system with tie-clip,

lavalier type microphone. Includes transmitter, receiver and

tie clip mic. Move freely up to 200 ft. Operates on

tw 9V batteries.o

WIRED-WIRELESS MIC SYSTEM / #WM-100H

Hand-held wireless mic system. Receiver has antenna and

on/off switch. Transmiter is built into mic. Move freely up to

50 ft. Mic uses AA battery; receiver uses AAA battery.

DUAL HAND-HELD WIRELESS MIC SYSTEM / #WM-200H

Offer freedom of movement for tw people, Karaokees o

style or speaker/audience participation; up to 200 ft. away.

Receiver operates on 110V AC. Each mic trans–

mitter uses one 9V batter (not Included).y

12V LANTERN STYLE RECHARGEABLE BATTERY / #PS12V

12V 5 amp rechargeable battery pack w/included cable

connects to an

y of our lecter

ns f

or battery power. 20 hr life.

O S CKLAHOMA OUND ORPORATION

POWER PLUS LECTERN: Model 111PLS

INTRODUCTION

Congratulations! You are now the owner of the Power

Plus Model #111PLS Lectern from Oklahoma Sound

Corporation. Now also includes wireless options built in.

We wish you long-lasting trouble-free usage for years

to come.

If you have any questions or experience any

difficulty with the product, please feel free to call our

Customer Service at 973-594-9000.

IMPORTANT SAFETY INFORMATION

As with any electric/electronic device, care should be

tak Alwen during use. ays turn off amplifier before open-

ing or servicing an of the unit. Please handle yy part our

lectern with the care it deserves.

AMPLIFIER OPERATING INSTRUCTIONS

Operating Precautions

Before operating the amplifier, be sure you fully understand all instructions and

features of the amplifier. DO NOT turn amplifier on until all input and output

connections have been made. NEVER replace fuses unless power is off.

Microphone Input Connection

The microphone input accepts

⁄4" phone jack. Do not position microphone

next to or facing speakers. This may cause acoustic feedback.

Wireless Operation

Turn on the power on both the wireless receiver and wireless mic-1 making sure

both are set to matching chanels, either “A” or “B”.

Auxiliary Input

One auxiliary input is provided for radio tuner, tape recorder, cd player or multi-

media equipment. Output level is adjusted by the auxiliary volume control.

Tone / Equalization Controls

The Low and High frequency controls are similar to the bass and treble controls

found on most stereo systems. Optimum tone is achieved by first setting both

knobs halfway; adjust Low and High frequency controls to suit environment.

Auxiliary / Line Out

Connect speaker line to navy line out connector of the amplifier. For maximum

power transfer and to avoid amplifier overload, be sure that the total imped-

ance of the speaker line matches the output impedance setting on amplifier.

Be sure that speaker terminals are not shorted together by speaker line con-

necting cables. Can also be used for a recording device.

Power Supply 12V DC Operation

Connect a 12 volt rechargeable battery 5 Amp (not included) to the battery

input connector located on the panel of the amplifier (using 6' battery cable).

Be sure that the positive pole of battery is connected to the white wire terminal

(+) and the negative pole to the Brass wire (–). When lectern is plugged into a

standard wall outlet, the battery will automatically recharge. Green indicator

light illuminates during recharge mode.

Precautions

• Set Mic volume control on lowest when turning unit on.

• Insure correct polarity for D.C. supply connections.

• Reverse connection will blow the fuse and may damage internal circuitry.

• Always replace fuse with specified rating.

Removal and Installation of Amplifier

If y

our amplifier has to be removed for servicing — follow these simple steps:

1) Disconnect A/C wall plug.

2) Remove 2 side screws one on each side panel under podium top.

3) Disconnect speaker wire at rear of amplifier card.

4) Remove 4 wood screws holding chassis to podium and remove amplifier.

k it into a str

ong bo

x with ample cushioning and r

eturn to factory.

6) To install new amplifier reverse the above procedure.

MANUFACTURER’S WARRANTY

Our Lecterns undergo the most rigid and exacting tests for superior quality

and performance before leaving the factory. Oklahoma Sound Corporation

warrants this product to be free from defective material and workmanship on

the electronic product speakers and microphones for two years from the date of

resale by an authorized Oklahoma Sound distributor. Oklahoma Sound will

replace defective parts and repair malfunctioning products under this war-

ranty when the defect occurs under normal installation and use, provided the

unit is returned to our factory via prepaid transportation after direct autho-

rization and approval by Oklahoma Sound. This warranty provides that

examination of the returned product must disclose in our judgement, a man-

ufacturing defect. This warranty does not extend to any product which has

been subject to misuse, neglect, accident, improper installation, or where the

serial number has been removed or defected and is given in lieu of any other

warranty implied or expressed and will not cover any consequential damages.
