Step 1
Evaluate the location of the
speaker. Project the length of
speaker wire you will run.
Note: when purchasing additional
direct burial speaker wire, make sure
the wire gauge is consistent.
Omni speakers reproduce sound in
will cover a large area with sound if
properly placed.
Step 2
Once you have decided on the
location for your in ground
speaker, dig a trench about 5”
leading from the speaker to the
input source for the speaker cables.
For the FORZA850T-LUM omni speaker,
dig a trench hole approximately 16”
in diameter and 5” deep for the
speaker enclosure.
Step 3
Place the omni speaker in the hole
you have dug. Run the direct burial
wire through the trench to the loca-
Please note: When connecting the
additional wire be sure to use water
tight wire connectors.
Step 5
Connect the wires from the omni
Please make sure the polarity on the
cables and the speaker are in sync.
Optional: Using an outdoor volume
control makes it convenient for you
to adjust the volume outside.
Step 4
Use the Tap switch located on the
speaker to select the appropriate
setting best suited for your
application.
Step 6
test the speaker. If the speaker
cover the submerged part of the
speaker.
that provides a minimum of 10 watts per channel.
Tools needed for installation
- Spade or trench tool
- Direct burial rated speaker cable
16AWG..........................................................................................100 ft
14AWG.................................................................................100 - 150 ft
12AWG.................................................................................150 - 200 ft
Design:
sound speaker with built-in LED for
landscape accent lighting.
LED power: 8-10W
LED input voltage: DC12V
LED color temperature: 4000K
Woofer: 8” with a 360 horizontal dispersion
Tweeter: 1” PEI Dome
pattern
Frequency Response: 42 Hz - 20 kHz
Power Handling: 200W
70V Tap: 20W, 40W, 60W
Impedance: 8 Ohm
Sensitivity: 88 dB
Dimensions: (L x W x H) 14” x 14” x 17”
Gross Shipping Weight: 14 lbs
Warranty: 3 Year
Installation
INSTALLATION GU EID
LED Lighting Considerations
Note: We do not provide the low voltage transformer. The choice of
transformer should be decided by the landscape lighting designer or if
you are installing yourself can be sourced directly on-line from sites
like Amazon.
The LED light requires 12 Volts and up to 10 Watts.
The light color or temperature is 4000K, commonly called “Cool”, just
above neutral. The maximum light output is 800 Lumens, similar to a
60-Watt incandescent light bulb. Area of illumination is approx. 1.5'
There are two wires coming from the bottom of the Forza850T-LUM
one is for connecting to an amplifier for sound and the other is for
connecting to a transformer for the LED light and is labeled “LED
Light”.
The wire for the LED light can be extended. A 5% reduction in
brightness can be expected using 14 gauge wire over 190 feet.
If you are partially burying the Forza850T-LUM, please experiment
with the depth and its affect on the lighting effect you are trying to
achieve.
When in doubt, consult a landscape lighting designer.
850T-LUM
OSD Audio
Brea, CA
osdaudio.com
NERO FORZA850T70V-LUM man. 12/22
WARRANTY INFORMATION
All OSD NERO outdoor speaker products have a (3) year Limited Warranty against defects in materials and workmanship. Proof of
purchase must accompany all claims. During the warranty period OSD AUDIO will replace any defective part and correct any defect in
workmanship without charge for either parts or labor OSD AUDIO may replace returned speakers with a product of equal value and
performance. In such cases, some modification to the mounting may be necessary and are not OSD AUDIO’s responsibility.
For this warranty to apply, the unit must be installed and used according to its written instructions. If necessary, repairs must be
performed by OSD AUDIO. The unit must be returned to OSD AUDIO at the owner’s expense and with prior written permission.
Accidental damage and shipping damage are not considered defects, nor is damaged resulting from abuse or from servicing performed
by an agency or person not specifically authorized in writing by OSD Audio
OSD AUDIO sells products only through authorized dealers and distributors to ensure that customers obtain proper support and
service. Any OSD AUDIO product purchased from an unauthorized dealer or other source, including retailers, mail over dealers and
on-line sellers will not be honored or serviced under existing OSD AUDIO warranty policy. Any sale of product by an unauthorized
source or other manner not authorized by OSD AUDIO shall void the warranty on the applicable product.
Damage to or destruction of components due to application of excessive power voids the warranty on those parts. In these cases,
repairs will be made on the basis of the retail value of the parts and labor. To return for repairs, you must email customer service at
RMA@audiogeargroup.com for a Returned Merchandise Authorization (RMA) number# then the unit must be shipped to OSD AUDIO
at the owner’s expense, along with a note explaining the nature of service required. Be sure to pack the speaker(s) in a corrugated
container with at least 3 inches of resilient material to protect the unit from damage in transit.
This Warranty Does Not Cover:
Damage caused by abuse, accident, misuse, negligence, or improper operation (installation) • Any products that have been altered or
modified • Any product whose identifying number of decal, serial #, etc. has been altered, defaced or removed • Normal wear and
maintenance.
