NERO

-MODQ2

-MODQ3

User

Manual

Speciﬁcations:

Warranty:

OSD Audio | Brea, CA | osdaudio.com

- -3

All OSD AUDIO speakers have (10) year Limited Warranty against defects in materials and workmanship. Proof of

purchase must accompany all claims. During the warranty period OSD AUDIO will replace any defective part and correct

any defect in workmanship without charge for either parts or labor

OSD AUDIO may replace returned products with a product of equal value and performance. In such cases, some

modifications to the mounting may be necessary and are not OSD AUDIO’s responsibility.

For this warranty to apply, the unit must be installed and used according to its written instructions. If necessary, repairs

must be performed by OSD AUDIO. The unit must be returned to OSD AUDIO at the owner’s expense and with prior

written permission. Accidental damage and shipping damage are not considered defects, nor is damaged resulting from

abuse or from servicing performed by an agency or person not specifically authorized in writing by OSD Audio

OSD AUDIO sells products only through authorized dealers and distributors to ensure that customers obtain proper

support and service. Any OSD AUDIO product purchased from an unauthorized dealer or other source, including retailers,

mail order dealers and online sellers will not be honored or serviced under existing OSD AUDIO warranty policy. Any sale

of product by an unauthorized source or other manner not authorized by OSD AUDIO shall void the warranty on the

applicable product.

Damage to or destruction of components due to application of excessive power voids the warranty on those parts. In these

cases, repairs will be made on the basis of the retail value of the parts and labor. To return for repairs, you must email

customer service at RMA@audiogeargroup.com for a Returned Merchandise Authorization (RMA) number then the unit

must be shipped to OSD AUDIO at the owner’s expense, along with a note explaining the nature of service required. Be

sure to pack the product(s) in a corrugated container with at least 3 inches of resilient material to protect the unit from

damage in transit.

This Warranty Does Not Cover: Damage caused by abuse, accident, misuse, negligence, or improper operation

(installation) • Any products that have been altered or modified • Any product whose identifying number of decal, serial #,

etc. has been altered, defaced or removed • Normal wear and maintenance.

NERO MODQ2 NERO MODQ3

Woofer 3” (80mm) Fiber-Glass Cone, Rubber Surround 2 X 3” (80mm) Fiber-Glass Cone, Rubber Surround

Tweeter 1” (25mm) Silk Soft Dome 1” (25mm) Silk Soft Dome

Power Handling 50W RMS 100W Peak 60W RMS 120W Peak

Freq Range 101Hz - 20kHz 100Hz - 20kHz

Sensitivity 85dB 85dB

Impedance 8 Ohm 8 Ohm

SPL Max 101 dB - Peak 104 dB Max 103 dB – Peak 106 dB

Termination 4mm Three Way Binding Post 4mm Three Way Binding Post

Grille Perforated Metal Perforated Metal

Cabinet Sealed, Acoustic Suspension, MDF Sealed, Acoustic Suspension, MDF

Mounting Hardware Built-In Key Hole Mounts Built-In Key Hole Mounts

Dimensions HWD 8.11” x 4.76” x 4.84” (206mm x 121mm x 123mm) 11.25” x 4.76” x 4.84 (286mm x 121mm x 123mm)

Accessories:

-MODQ2 x 2 pcs

-MODQ3 x 1 pcs

User Manual x 1 pcs

Adjustable Stand x 1 pcs

Screws x 4 pcs

-MODQ2

-MODQ3

- - - -1 2

Mounting Information:

Rotating aluminum logo on the MODQ3

1. Pull out the logo plate.

2. Rotate the logo as desired.

3. Release into place.

MODQ3 - Magnetic cabinet linking.

MODQ3 Cabinets can be linked together magnetically for center-

channel and stacking applications.

Suggestion: Connect 3 speakers together

as left, center and right. Or stack two on

top of each other and wire in series

(4 Ohm load) for double the acoustic out-

put. If stacking more than two, learn about

wiring in series/parallel.

-MODQ-MOUNT x 1PCS

Instructions for use:

Optional 1/4” Ball-Joint Steel Brackets: NERO-MODQ-MOUNT

The MODQ2 and MODQ3 can be mounted on wall via bracket w -MODQ-MOUNTith part #:
