Side 1/4

PRE 1

STEREO PRE AMPLIFIER INSTALL GUIDE

POWER

MIC

MIC LEVEL BASS MID TREBLE LOUDNESS BALANCE

VOLUME

CD/DVD

MONOTAPE

LOW FILTER MUTE

AUX1 AUX2

PHONO

INPUT SELECT

Min Max Min Max Min Max Min Max Min Max

Min Max

Left Right

STEREO PRE-AMP

1PRE

STEREO PRE-AMP

CD/DVD AUX1 AUX2

STER EO PRE-AMP

1PRE

STER EO PRE-AMP

PRE 1 INSTALL GUIDE

Front Panel Description

Back Panel Description

1. Power ON / OFF

2. Microphone Jack Input

3. Mic Level Control

4. To boost or attenuate low frequency sound.Bass Control:

5. To boost or attenuate midrange frequency sound.Midrange Control:

6. Treble Control: To boost or attenuate high frequency sound.

7. To compensate for the non-linear response of the human ear at low volume.Loudness:

8. Controls the relative volume between the left/right speakers and headphone.Balance:

9. Master Volume: Adjusts the main output volume level of speakers and headphones.

10. Switch between multiple input sources.Input Selector:

11. Tape: Input for an analog tape deck

12. Switch between mono or stereo signalMono:

13. Eliminates low frequency distortion from a turntable or warped record.Low Frequency Filter:

14. Reduce the volume level by 20dB. Useful when changing records, tapes or changing sources.Mute:

1. Connect to Left/Right output from a turntable.Phono Inputs:

2. Auxiliary source input.Aux Input 2:

3. Auxiliary source input.Aux Input 1:

4. Connect to Left/Right output from a CD or DVD player.CD/DVD Input:

5. Tape Play: Connect to a tape decks output jacks.

6. Tape Rec: Connect to a tape decks input jacks.

7. Used to connect to a signal processing unit, such as a graphic equalizer or can be connected to a power Output:

amplier with higher output power.

8. Connect the ground wire from a turntable here to avoid hum or feedback from the speakers.Ground Screw:

9. Switch between 110V-220V AC.AC Selector:

10. Contains primary AC fuse If fuse blows replace only with the same amperage fuse.Fuse Holder:

11. Plug the AC cord into a nearby AC outlet or surge protector.AC Power Cord:

1. 2. 3. 4. 5. 6. 7. 8. 9. 10.

9.8.7.6.5.4.3.2.1.

11.

14.

11.

12.

13.

10.
